Page 4
3. Epoxy the wood block to the servo tray base on the Accessory part lists for wing installation. mark line. 1. Ready for assemble the wing servos. 4. Epoxy the wood block to the servo tray tightly. 2. Put the wood block to appropriate position base on the servo tray, mark out with red.
Page 5
9. Before glue the arm to the slot, put masking tape 6. Assemble the servo to the wing around the slot to keep clean. 7. Drag the servo line out of the wing. 10. Glue the arm to the slot and wait it dry. 11.Connect the arm of the flap and servo arm with push 8.
Page 6
12.The scketch map of the servo for the wing assembly 14.Prepare the parts for assembly the stab servo. finished. 15.Measure the deepth and mark out where the servo Accessories part list for the stabilizer installation. would location. 13.Sanding the fiber horn. 16.Trim a lot for the stab servo arm.
Page 7
17.Glue the horn to the elevator and assemble the servo to 19.Apply instand type AB glue to the slots in the rudder. the stabilizer. 18.Connect the arm of servo to the horn with push rod. 20.Apply instand type AB glue to the slots in vertical fin. 21.Assemble the rudder to the vertical fin and make sure Accessories part lists for the rudder installation.
Page 8
22.Apply instand type AB glue to the slots in the tail cone. 25.Mark it out at the outer side of the vertical. 23.Assemble the tail cone to the vertical fine tightly. 26.Trim a slot for the servo arm. 27.Assemble the servo into the vertical fin with screw 24.Measure the deepth of the rudder servo position.
Page 9
28.The sketch map after the servo of rudder assembly. 31.Glue the fiber horn to the slot tightly. 29. Trim a slot at the appropriate position in the rudder. 32.Remove the masking tape after the glue dried. 30.Put masking tape around the slot to keep the plane body clean after work done.
Page 10
Accessory part lists for retract installation(Optional and 36.The sketch map after the main retracts assembled need purchased separately). completely. 34.The sketch map of the electric retract system (Optional 37.The sketch map of the nose gear and nose gear servo and need purchased separately) parts.
Page 11
39. Bending the push rod to a propriate angle and assemble 42.Connect the clevis to the hatch hinge with screws and them to the retainers . nuts. 43.Connect the clevis to the hatch hinge with screws and 40.Assemble the nose gear completely. nuts.
Page 12
45.Assemble the nylon horn to the air brake inner side, assemble the air brake servo to appropriate position in the 48.Put the fin bolt into the vertical fin. fuselage, connect the horn to the servo arm with push rod. 46.Glue the tube to the vertical fin tightly. 49.Glue the vertical tail parts to the main fuselage tightly.
Page 13
50.Assemble the turbine and tail pipe to the fuselage. 53.Prepare the tail pipe mount. 51.Fuel tank ready. 54.Fix the tail pipe to the tail pipe mount. EDF installation steps for reference (All the devices and accessories need purchased by customer 52.Fix the fuel tank to the fuselage.
Page 14
55.The sketch map when the PVC sheet glue up. 58.The sketch map when after the position hollowed 56. Seal the PVC tube to the EDF and assemble them to 59.The sketch map after the ESC and battery the air intake. installation.
Page 15
61.Add some glue to the holes of stab. 64.Add some glue to the holes of wing. 62.Fix the stab tube to the holes tightly. 65.Fix the wing tube to the holes tightly. 63.Assemble the stab to the fuselage and lock it to the 66.Assemble the wing to the fuselage and lock it to fuselage with screws.
Page 16
The schetch map once the model completely assembly. 67. Adjust the travel of each control surface to the values in 69. Adjust the travel of each control surface to the the diagrams. These values fit general flight values in the diagrams. These values fit general flight capabilities.Readjust according to your needs and flight capabilities.Readjust according to your needs and level.
