Page 2: Table Of Contents
CONTENTS Brief introduction ..................1 Main specifications ..................1 Main configuration...................1 Products constitution..................1 Assemble processes...................2 Adjustment steps..................4 Safety precautions..................5 Charging method and cautions..............5 Caution and Notice for Li-po batter y .............6 Caution and notice for ESC ..............6 Spare parts......................7 Statement: 1.Please read this manual carefully and follow the instruction of the manual before you use this products;... -
Page 3: Brief Introduction
Brief introduction Thank you for purchasing the “ Hurricane MKIIB ” remote control model airplanes from Top RC, and we hope this plane will bring endless joy to you after you choose it. ★ It can finish the inverted flight, inside loops, outside loops, axial rolls and other aerobatic actions fluently. Stable flight and easy to control, it also can climb with wide-angel continuously;... -
Page 4: Assemble Processes
Assemble processes 1.Assembly the landing gear. Take of the wing &main landing gear and screws (PWA2 8mm) from the package. Assemble the landing gear into the slot of the fuselage, please don't make it reverse. Then lock them by the screws (PA2*8MM). 2.Assembly of the main wings. - Page 5 Take of the auxiliary oil tank package, tear off the stick surface, then stick it to the mounting groove of auxiliary oil tank on the surface of wing. 6.Assembly the antenna Take of the antenna,then set it to the mounting groove at the back of fuselage. 7.Finished the assembly of “ ”. Hurricane MKIIB...
-
Page 6: Adjustment Steps
Adjustment steps 1.Turn on the transmitter and please make sure that there is enough power for the transmitter. Push the joystick for the throttle and throttle trim switch to the lowest position, and keep other trim switch be in the neutral position. 2.Please connect the battery to the ESC plug, and put the battery into the battery case well, than close the battery cover. -
Page 7: Safety Precautions
45-50mm 6.Finished the adjustment for “Hurricane MKIIB” Safety precautions 1.If you have the simulator, we suggest that you can practise your skill by the simulator before you fly this model, which will bring some help for you. -
Page 8: Caution And Notice For Li-Po Batter Y
Operating Then plug cigarette into its socket in car (Adapter should be connected if charge at home: connect the adapter to home power socket, then plug the adapter' DC end to charger). The LED will turn green indicating it is ready for charging. 2.Connect the battery to charger per its interface mark. -
Page 9: Spare Parts
Spare parts top 01301 top01302 top01303 Fuselage Main wing Horizontal wing reen) reen) reen) top01304 top01305 top01806 Landing Gear Vertical Wing( reen) reen) Auxiliary oil tank( reen) top01807 top 01308 top01309 Spinner Fuselage Main wing reen) (yellow) (yellow) top01311 top01312 top01310 Landing Gear Vertical Wing(yellow) - Page 10 Spare parts top01316 top503 top30204 Controlling steel 7.4v,1000mah Lipo Battery 9g Servo（Wire:150mm） top30205 top201 top401 9g Servo（Wire:150mm） 12A Brushless ESC Motor(DST-1300)
