P-51D Mustang 89"
Specification:
Wing Span: 2260mm/89in
Length: 1965mm/77.4in
Flying Weight: ~11.2kg
Wing area: 90.2dm2
Engine: 50-60cc, rear exhaust
R/C System: 8+ channel radio system
Servo: 10
C.G: 170mm back from the leading edge at wing root
SAFETY PRECAUTIONS

INSTRUCTION MANUAL

This R/C airplane is not a toy!
(The people under 18 years old is forbidden from flying this model)
First-time builders should seek advice from people having building
experience.If misused or abused,it can cause serious bodily injury
and damage to property.
Fly only in open areas and preferably at a dedicated R/C flying site.
We suggest having a qualified instructor carefully inspect your
airplane before its first flight.Please carefully read and follow all
instructions included with this airplane,your radio control system
and any other components purchased separately.
