Nilfisk-Advance Clarke CA60 Use And Maintenance

Use and maintenance
Operating guidelines Clarke CA60 automatic scrubbers
1. Turn on the key and verify
there is enough battery power
to complete the work. Charge
batteries as required.
5. Disc: Lift the brush/pad driver to engage the rush/pad holder
and rotate clockwise as viewed from above. BOOST: Simply press
the pad onto the pad driver face material.
8. Use the squeegee raise/lower handle to
lower the squeegee to the floor.
Adjust the squeegee pitch as required.
11. Pressing either yellow palm buttons
and the white reverse button together will
put the machine into reverse.
September 2018 - Copyright © Nilfisk Group 2018 - www.clarkeus.com
Nilfisk, Inc.
9435 Winnetka Avenue North
Brooklyn Park, MN 55445
Phone: 800.253.0367
Fax: 800.825.2753
www.clarkeus.com
2. Install the squeegee us-
ing the thumb nuts. Attach
squeegee hose.
9. Press left, right or both yellow palm
switches to move the machine forward.
12. Press the + or – solution buttons to
increase or decrease the water flow rate
and to turn water off.
Nilfisk Canada Co.
240 Superior Boulevard
Mississauga, Ontario, Canada L5T 2L2
Phone: 800.668.8400
Fax: 800.263.5111
www.nilfisk-advance.ca
3. Remove the black cover on
the front and fill to desired lev-
el. Machine holds 16 gallons/61
liters maximum.
6. Lower the brush deck by
pushing on the pedal to the
right and lift it up.
10. Use the rabbit/turtle knob to control
the speed.
Push
on the
button
13. On disc machines, the brush/pad
holder can be removed automatically.
Raise the deck and press the click off brush
button.
4. Check the water level indica-
tor on the right side of the
machine. Add appropriate
chemical.
7. Press the OneTouch TM scrub
button to enable scrubbing.
The vacuum will start. Push
on one of the two switches
½ second to install the brush.
Brush will automatically install.
by Nilfisk
