SDC Z7200R Installation Instructions

Cylindrical lock

Advertisement

Quick Links

801 Avenida Acaso, Camarillo, Ca. 93012 • (805) 494-0622 • Fax: (805) 494-8861
www.sdcsecurity.com • E-mail: service@sdcsecurity.com
TOOLS REQUIRED FOR NEW INSTALLATION:
1 philips head screwdriver
1 1" (25.4mm) drill bit
1 chisel
INSIDE
LEVER
LEVER
CATCH
TOOL
INSIDE MOUNTING
PLATE
LATCH
1. MARK DOOR
a. Mark centerline on door face and door edge
b. Select backset 2-3/8" or 2-3/4" and mark hole
NOTE: BACKSET ON DOOR FACE MUST BE
c
a
c. Mark two holes for screw post.
b
P:\INSTALLATION INST\ELECTRIFIED LOCKSET\Z7200\INST-Z7200R.vsd

INSTALLATION INSTRUCTIONS

CYLINDRICAL LOCK Z7200R
FOR USE ON DOORS 1-3/8" ~ 2" (35mm ~ 51mm) THICK
1 2-1/8" (54MM) hole saw
1 5/16" (8mm) drill bit
1 file
INSIDE
ROSE w/LINER
LOCK BODY
ASSEMBLY
OUTSIDE
LEVER
(usually 38" from finished floor)
center on door face
THE SAME AS BACKSET OF YOUR
LOCK.
Fold template for High or
Low Bevel positioning
(reference template)
REV -
OPTIONAL:
DOOR CORE DRILLING GUIDE #7000-DG &
CORING DRILL BIT #7000-DB
OUTSIDE
MOUNTING
PLATE
OUTSIDE
ROSE
2-1/8" (54mm)
Hole for lockset
03-17
Page 1
2. DRILL HOLES
5/16" (8mm) hole for
screw post
1" or 31/32"
(24.6mm or 25.4mm)
hole for latch
Any suggestions or comments to this instruction or
product are welcome. Please contact us through
our website or email engineer@sdcsecurity.com
