- Page 1 4 Port USB 3.1 Gen1 Isolated Hub with 15KV ESD Surge Protection Product Manual Coolgear, Inc. Version 1.1 September 2017 Model Number: CG-U31iS4PH www.coolgear.com...
- Page 2 CG-U31iS4PH – Product Manual Revision History Revision Date Author Comments 3/20/2017 Coolgear Original format 10/9/2017 Coolgear New Manual Format About this document This product manual outlines installation and features of the 4 Port USB 3.1 Gen1 Isolated Hub with 15KV ESD Surge Protection.
- Page 3 CG-U31iS4PH – Product Manual Table of Contents 1. Introduction ......................4 Features ........................4 Connector Layout ....................5 Supported USB Devices ................... 5 I/O Hardware ......................6 Environmental Specifications ................. 6 2. Notes, Tips, Warnings, and Safety ................. 7 3. Supporting References ..................8 Table of Figures Figure 1 –...
- Page 4 CG-U31iS4PH – Product Manual 1. Introduction The new CG-U31iS4PH USB 3.1 4 port hub isolates the four downstream ports from the upstream host port giving you valued circuit protection. With a small footprint, the hub supports 5Gbps super-speed data and backwards compatibility down to USB 1.0 1.5Mbps.
- Page 5 CG-U31iS4PH – Product Manual 1.2 Connector Layout Figure 1 USB A Downstream Port USB B Upstream Port 5V DC Power Input 3KVrms isolated 3KVrms isolated Upstream 5V AC/DC power adapter Downstream Port Domain Port for USB 3.1 Type-B to for downstream ports. It...
- Page 6 CG-U31iS4PH – Product Manual Figure 2 1.4 I/O Hardware • Supports 4 external USB3.1 Gen 1 Type-A connectors and 1 USB3.1 Gen 1 Type-B Upstream connector. • Supports a DC-Jack Connector (on the Downstream Port Domain) for external power input from AC/DC power adapter.
- Page 7 CG-U31iS4PH – Product Manual 2. Notes, Tips, Warnings, and Safety Note For Systems with USB3.1 Gen 1, USB2.0, or USB1.1 Ports Warning • Read the entire Product Manual before implementing this product for your application. This manual contains important information about electrical connections that must be followed for safe and proper operation.
- Page 8 © 2017 Coolgear, Inc. All Rights Reserved. All products and accompanying digital documentation including images are the property and / or trademarks of Coolgear Inc. Coolgear Inc. are continuously improving upon its products. Product specifications are subject to change without notice.
