- Page 1 Linde 115 & OM Pimespo Thesi series System Manual Manual no. 0993650 A 01 01/2014 English Set Article No. 0401432...
-
Page 2: Table Of Contents
Orlaco Products BV Service department. The camera and monitor systems from Orlaco comply with the latest CE, ADR, EMC and mirror-directive regulations. All products are manufac- tured in accordance with the ISO 9001 quality management, IATF 16949 quality automotive and ISO 14001 environmental management. -
Page 3: Introduction
System Manual Camera-monitor systems on Linde 115 and OM Pimespo Thesi series reachtrucks. Important Roll out the mastcable entirely to remove kinks before installing it in the mast of the truck. 1. Introduction The Linde 115 series reachtruck and the OM Pimespo Thesi series reachtruck have a special mast design that is quite different from any other reachtruck mast. -
Page 4: Top Of Mast
System Manual 3. Top of mast The second pulley does not need to be modified and is installed hanging from the traverse of the middle mast section as shown in figure 5. Make sure that the pulley is placed in line with the chain and that the pulley does not touch the forkcarriage. - Page 5 System Manual On the second mastconfiguration, the clearance between the traverse and 0403330 with adjusted Pulley Conversion Kit 0404750 the next crossmember is larger. Bracket from 0404750 (Pulley Conversion Kit) The standard M8 x 35 centerbolt is replaced by an M8 x 40 bolt. This is cut in half.
-
Page 6: Installing The Camera
System Manual Cut 23 mm and bend approx. 90° Model no. Serial no. ORLACO C a m e r a M o n i t o r S y s t e m s ∅6,5 ∅4,0 70,0 93,5 90° 188,5... -
Page 7: Overview
System Manual 6. Overview of mastcable routing Pulley in 3 th mast section See page 4 Fig. 5 Fixation of cable on the fork carriage Pulley on traverse See page 4-5 Fig. 6 + 8 Fix spring set to cross member Modified Pully on free lift cylinder See page 3 Fig. - Page 8 ORLACO Orlaco is a Manufacturing company that specializes in making cameras and monitor systems for commercial vehicles, fork-lift trucks, cranes, off shore and maritime. Our objective is to design and produce camera systems for the profes- sional market that improve the drivers view and increase operating efficiency.
