- Page 1 If you have any questions or doubts, please contact us via Hotline (+86)0755-23576169 Email support@topdon.com Website www.topdon.com Facebook @TopdonOfficial Twitter @TopdonOfficial MADE IN CHINA Phoenix Plus Professional Diagnostic Tool USER MANUAL...
- Page 2 Content Welcome ....................3 About ....................... 3 Package List ................... 3 Compatibility ..................3 Notice ...................... 4 General Information of OBDII (On-Board Diagnostics II) ..... 4 Diagnostic Trouble Codes (DTCs) ............4 Product Descriptions ................5 Preparation & Connection ..............7 Operation Introduction ................
- Page 3 Welcome Thank you for purchasing TOPDON automotive diagnostic tool Phoenix Plus. Please read and understand this user manual prior to the operation. About TOPDON Phoenix Plus features a full line of high-performance functionality. The accuracy of test readings, the expanded vehicle coverage, the improved speed, and an abundance of user- friendly nature, place the diagnostic tablet in a class of its own, being a great assistance for mechanics and professionals to have more efficient diagnostic work ever.
- Page 4 Notice Product Descriptions Phoenix Plus may automatically reset while being disturbed by strong static electricity. THIS IS A NORMAL REACTION. This user manual is subject to change without written notice. Read the instruction carefully and use the unit properly before operating. Failure to do so may cause damage and/or personal injury, which will void the product warranty.
- Page 5 Keep the tablet standing at the desk, or use it to hang Adjustable Stand the tablet on the steering wheel. 3. Plug the TOPDON Phoenix Plus VCI dongle into the vehicle’s DLC port. Rubber Corner Secure the tablet from shock and accidental dropping.
- Page 6 7. Connect Wi-Fi The system will automatically search all available Wi-Fi networks. You can choose the Wi-Fi 5. Fully charge the Phoenix Plus, and hold the power button for 3 seconds to turn the tablet needed. on. The tablet will start initializing and enter the following interface: Note: Don’t connect or disconnect any test equipment with the ignition on or engine running.
- Page 7 The activation procedure is necessary for using the Phoenix Plus properly. 10. Create an Account You can log in with an available TOPDON account, or register a new account with a valid e-mail address. Tap “Activate” to finish the procedure, and get started to use Phoenix Plus.
- Page 8 Operation Introduction TOPDON Phoenix Plus features an array of practical functions, including Local Diagnosis, Intelligent Diagnosis, Maintenance, Remote Diagnosis, Upgrade, ArtiFolder, Repair Info, Feedback, and User Info. TOPDON Phoenix Plus supports Intelligent Diagnosis and Local Diagnosis covering OBDII diagnosis, full system diagnosis for most modern vehicle models worldwide.
- Page 9 Note: A highly stable and solid network connection is required for successful VIN access. 2. Local Diagnosis If Phoenix Plus fails to get access to the vehicle VIN data automatically, tap “Local Diagnosis” on the Home Menu. The following page will appear: to scan the VIN barcode.
- Page 10 You need to input the vehicle’s VIN data manually. to scan the VIN character. If the VIN character cannot be recognized, Note: VIN characters need to be capital letters A through Z and numbers 1 through please manually input the VIN. 0.
- Page 11 2.3 Health Report This function can quickly reveal the vehicle's health status. Tap “Health Report”. The system will start scanning DTCs and show the test results. Select the diagnostic software version to continue. The tablet will automatically navigate to the function selection menu: The systems with DTC(s) will be shown in red, with the specific definition(s).
- Page 12 2.4 System Scan This function will automatically scan all systems of the vehicle. 2.5.1 Module Information This function reads the current version information of ECU. 2.5.2 Read DTC 2.5 System Selection This function can read the Diagnostic Trouble Codes (DTCs) in the ECU memory, This function allows you to manually choose the automotive electronic control system helping quickly identify the cause of the vehicle breakdown.
- Page 13 *Explanation of terms: • Freeze Frame: Take a snapshot of specific data streams for verification when the DTC occurs. • Report: Save the current diagnosis result as a diagnosis report. 2.5.3 Clear Fault Code This function can clear the DTC of the ECU memory of the tested system. 2.5.4 Read Data Stream This function can read and display real-time data and parameters.
- Page 14 Once the recording process is complete, tap “ ” to end the recording. The Tap the file you need. The following page will appear: following page will appear: The Standard Range column will show the corresponding Data Stream Sample You can change the Min or Max value, and tap “Save” to save it as a Data values for your comparison and analysis.
- Page 15 You can select specific data stream options to be viewed on the left. You can select specific data stream options to be viewed on the left. Note: A maximum of 12 data streams can be displayed in this module. Note: A maximum of 4 data streams can be displayed in this module. Report: To save the number of current data streams.
- Page 16 3. Maintenance Services 3.4 Battery Matching TOPDON Phoenix Plus is loaded with maintenance services to be very beneficial for This function can reset the monitoring unit of the car battery, by clearing the original technicians and mechanics working in the automotive repair industry.
- Page 17 3.8 Tooth Learning 3.16 EGR Adaption This function can perform tooth learning for the car, to turn off the MIL This function can learn the EGR (Exhaust Gas Recirculation) valve after it is cleaned or replaced. It needs to be performed in the following cases: After the engine ECU, crankshaft position sensor, or crankshaft flywheel is replaced.
- Page 18 3.23 AdBlue Reset (Diesel Engine Exhaust Gas Filter) Tap “OK” to enter the vehicle diagnostic feedback selection menu. After the diesel exhaust treatment fluid (car urea) is replaced or filled up, urea reset operation is required. 3.24 Seat Calibration This function can match the seats with memory function that are replaced and repaired. 3.25 Coolant Bleeding This function can activate the electronic water pump before venting the cooling system.
- Page 19 5. Repair Info 6. ArtiFolder Tap “Repair Info” on the Home Menu. The following page will appear: This module can record and establish the file of the diagnosed vehicles, including all diagnostic-related data such as diagnostic reports, data stream records, and screenshots. 5.1 OBD Fault Code Library: To view the definition of DTCs (Diagnostic Trouble Codes).
- Page 20 8. User Info 8.7 Wi-Fi You can modify or add related information in this module, or make settings. This option sets up Wi-Fi networks that can be connected. 8.8 Diagnostic Software Clear This option can clear some cache files and free up the storage space. 8.9 Business Information This option can add information about the workshop, which will be displayed in the diagnostic report.
- Page 21 Technical Specification Warnings Operating System: Android 10.0 Always perform automotive testing in a safe environment. Screen: 10” Touchable; 1280 * 800 DO NOT smoke near the vehicle during testing. Memory: 4G DO NOT place the diagnostic tool near the engine or exhaust pipe to avoid damage from Storage: 64G high temperatures.
- Page 22 The serial number and activation code and make sure they are correct Please contact the dealer or TOPDON code are not correct. (serial number 12 digits, activation code Problem of the Charger. after-sale service for timely support.
- Page 23 Whether the system is available in the vehicle. • • Whether the VCI dongle is correctly connected. • Whether the ignition switch is ON. Q: The VCI dongle is missing. A: Please contact the dealer or TOPDON after-sale service for timely support.
- Page 24 Q: Error of the diagnostic software. A: Please operate as follows: • Tap “Feedback” to send specific problems to us for technical support. • Tap the vehicle software icon, and hold it to uninstall the corresponding software, and then enter the upgrade center to download and install the new version. Q: The downloaded diagnostic software is inconsistent with the serial number.
