Topdon FCA US SGW Manual

INTRODUCTION OF FCA US SGW
What's FCA US SGW?
FCA vehicles (Fiat Chrysler Automobiles) have been protected with an SGW
security module (Secure since 2017 Gateway) to prevent unauthorized
diagnostics and security attacks.
This module limits diagnostic capabilities without authorized diagnostic tools.
This limits functions ranging from Bi-directional testing to DTC clearing. The
vehicle's SGW will need to be "unlocked" by the authenticated tester, and the
Diagnostic tools.
Now FCA US is using the Automatic Authentication Authority (AutoAuth) to
manage user accounts for access to SGW vehicles.
If you are a shop owner, you will first need to register a user account as a
technician, then register your shop. (There is an annual $50 fee per shop).
1. This membership covers up to 6 users (this includes the owner).
2. Each additional user is $2/year.
3. There is a maximum of 100 users per shop.
4. There is a maximum of 100 scan tools per shop.
Note: There are multiple packages on AutoAuth's website, and the shop owner
can choose the one that best suits their needs. The payment is charged by
AutoAuth directly. TOPDON is not involved in any transaction process.
If you are a technician, you can create an account using the AutoAuth
software application for free, and then provide your username to the shop you
work at, the shop's account owner, and add it to your workplace's membership
list. This way, you can use all of the tools registered under your shop's account.
Applicable Area
The United States, Mexico, and Canada.
Which vehicles equiped with FCA SGW?
Make Model
Chrysler 300
Chrysler Pacifica
Dodge Challenger
Dodge Charger
Dodge Durango
Dodge Journey
Year
2018-2022
2018-2022
2018-2022
2018-2022
2018-2022
2018-2020
