Summary of Contents for Topdon Phoenix XLink

  • Page 1 For Services and Support 86-755-2 1612590 1-833-629-4832 (North America) EMAIL SUPPORT@TOPDON.COM WEBSITE WWW.TOPDON.COM FACEBOOK @TOPDONOFFICIAL TWITTER @TOPDONOFFICIAL...
  • Page 2 Phoenix XLink Smart Automotive Diagnostic System USER MANUAL...
  • Page 4: Table Of Contents

    Contents Welcome ....................3 About ....................... 3 Package List ................... 3 Compatibility ..................3 Notice ...................... 4 General Information of OBDII (On-Board Diagnostics II) ..... 4 Diagnostic Trouble Codes (DTCs) ............4 Product Descriptions ................5 Preparation & Connection ..............7 Operation Introduction ................
  • Page 6: Welcome

    Welcome Thank you for purchasing TOPDON's Smart Automotive Diagnostic System Phoenix XLink. Please read and understand this user manual prior to the operation. About TOPDON's Phoenix XLink features comprehensive diagnostic capabilities. The accuracy of test readings, expanded vehicle coverage, improved speed and an abundance of user- friendly features make this diagnostic tablet stand out in its class and give mechanics and professionals a great deal of help in their diagnostic work.
  • Page 7: Notice

    Notice Phoenix XLink may automatically reset while being disturbed by strong static electricity. THIS IS A NORMAL REACTION. This user manual is subject to change without written notice. Read the instructions carefully before operating and use the unit properly according to the guide.
  • Page 8: Product Descriptions

    Product Descriptions Name Descriptions • Hold the button for 3 seconds to turn the tablet on or off. Power Button • Hold the button for 2 seconds for a forced shutdown. • Press the button to wake up the screen or turn off the screen. Plug in the diagnostic cable whose 0BD 16-bin connector is linked the DLC of Diagnosis interface the vehicle.
  • Page 9: Preparation & Connection

    Preparation & Connection 1. Turn the ignition off. 2. Locate the vehicle’s DLC port. 3. Plug the TOPDON Phoenix XLink into the vehicle’s DLC port.
  • Page 10 4. Turn the ignition on. The engine does not need to be running. 5. Hold the power button for 3 seconds to turn the tablet on. (The tablet must be charged.) The tablet will start initializing and enter the following interface: Note: Do not connect or disconnect any test equipment with the ignition on or engine running.
  • Page 11 7. Connect Wi-Fi The system will automatically search all available Wi-Fi networks. Select the Wi-Fi network you want to connect to. 8. Choose Time Zone Choose the time zone of your current location. The system will automatically confi gure the time.
  • Page 12 9. User Agreement Please read all the terms and conditions of the user agreement carefully. Select “Agree with above terms." Tap “Next” to log in. The following page will appear: 10. Activate Please enter your email and tap the CAPTCHA button to obtain the Validation Code. After entering the Validation Code, tap the OK button.
  • Page 13: Operation Introduction

    Operation Introduction TOPDON's Pheonix XLink features an array of practical functions, including Scan, AutoScan, Services, ADAS, Module, Update, Support, Library, History, Feedback and User Info. TOPDON's Pheonix XLink supports AutoScan and Scan covering OBDII diagnosis, full system diagnosis for most modern vehicle models worldwide.
  • Page 14 Note: If the AutoScan can not identify the vehicle, please try to reconnect to the network. Not all cars support the AutoScan function due to auto manufacturers settings. 2. Scan(Manual Diagnosis) If Pheonix XLink fails to get access to the vehicle VIN data automatically, tap “Scan” on the Home Menu.
  • Page 15 2.1.1 Tap “Camera Scan." The following page will appear: After scanning, the following page will appear: Note: the VIN code in yellow can be modifi ed if it isn’t correct. If the VIN barcode cannot be recognized, please tap to manually input the VIN.
  • Page 16 2.1.2 After selecting “ ," the following page will appear: You will need to input the vehicle’s VIN manually. Note: VIN characters need to be capital letters A through Z and numbers 1 through 0. However, the letters I, O, and Q won't be used in order to avoid misreading. No symbols or spaces are allowed in the VIN.
  • Page 17 Select “Demo” as an example and the following page will appear: Tap “OK." Select “Demo" from the pop-up Notes. Then select a vehicle make. The tablet will automatically navigate to the Show Menu: The interface has two display modes, one of system topology and one of system list, both with the same functions.
  • Page 18 2.2.1 Smart Scan This function is used to quickly detect vehicles and view vehicle health reports (this item will only be displayed if the vehicle's model diagnosis software supports this function). Tap “Smart Scan," the system starts to scan fault codes in each system and displays specifi...
  • Page 19 2.2.2 System Scan This function will scan all systems of the vehicle. 2.2.3 Choose to Scan Scan the manually selected vehicle electronic control system. As an example, tap “PCM," then tap “Choose to Scan" to scan the system. Tap “PCM" and tap “Enter." The following page will appear.
  • Page 20 B. Diagnostic Trouble Code This function can read the Diagnostic Trouble Codes (DTCs) in the ECU memory, helping quickly identify the cause of the vehicle breakdown. Tap “Read Fault Code." The screen will display diagnostic results. *Explanation of terms: • Freeze Frame: Take a snapshot of specifi...
  • Page 21 Select the data stream and tap “OK”: The system can display data streams in three modes: 1) Value (default): Shows parameters with numbers and lists. 2) Graph: Displays parameters as wave patterns. 3) Combine: Both Values and Graphs can be merged for easier comparisons. *Explanation of terms: •...
  • Page 22 Once the recording process is complete, tap “ ” to end the recording. The following page will appear: You can change the Min or Max value and tap “Save” to save it as a Data Stream Sample. All Data Stream Sample fi les are stored in “User Info -> Data Stream Sample."...
  • Page 23 Select the fi le you need. The following page will appear: The Standard Range column will show the corresponding Data Stream Sample values for your comparison and analysis. • Graph: To have the selected data streams (max 12 items) displayed in waveform.
  • Page 24 Tap “<“ on the right side of the screen. The following page will appear: Tap “Value” to view the data displayed in values. Tap “Combine” to merge graphs for easier comparisons (A maximum of 4 values can be merged). You can select specific data stream options to be viewed on the left. Note: A maximum of 12 data streams can be displayed in this module.
  • Page 25 Tap “Min/Max” to defi ne the maximum/minimum values. Once the value goes beyond the specifi ed values, the data will be shown in red. Tap “<“ on the right side of the screen. The following page will appear: You can select specifi c data stream options to view in the chart. Note: A maximum of 4 data streams can be displayed in this module.
  • Page 26 2.2.4 ADAS Calibration Tap “ADAS Calibration," and the screen will enter the selection interface. 3. Services TOPDON Pheonix XLink is equipped with benefi cial maintenance services for technicians and mechanics working in the automotive repair industry. 3.1 OIL (Maintenance Light Reset)
  • Page 27 Use cases: • After replacing the electronic control unit, the relevant characteristics of the throttle operation have not been stored in the electronic control unit. • After the electric control unit is powered off, the memory of the electric control unit is lost.
  • Page 28 3.6 BRAKE (Electronic Parking Brake Reset) This function helps you to replace and reset the brake pads. Use cases: • The brake pads and brake pad wear sensor are replaced. The brake pads indicator lamp is on. • • The brake pads sensor circuit is short, which is recovered. •...
  • Page 29 3.12 SUS (Suspension Level Calibration) This function is required to calibrate the level of the vehicle when the level sensor or control module in the air suspension system is replaced or when the level of the vehicle is incorrect. 3.13 AFS (Adaptive Front-Lighting System Reset) This function enables you to initialize the adaptive headlamp system.
  • Page 30 3.20 A/F (A/F Reset) This function can set or learn Air/Fuel ratio parameters. 3.21 STOP/START (Stop/Start Reset) This function can open or close the automatic start-stop function by setting the hidden function in ECU (provided that the vehicle has a corresponding hidden function supported by hardware).
  • Page 31 3.30 AC System Relearn/Initialization If the ECU or actuator of the vehicle air conditioner is replaced, or the memory of the ECU memory is lost, air conditioner initialization learning is needed. 3.31 Engine Power Balance Monitoring At the power stroke of each cylinder, power balance monitors crankshaft acceleration, thus determining the relative power provided by each cylinder.
  • Page 32 system of the vehicle. After matching, it is used to clear the short circuit fault of the light. Damage to the FRM module can occur when replacing the battery, if the start switch is not turned off, if the battery terminal is grounded, or other non-professional battery operations occur.
  • Page 33 Notes: ADAS function requires additional hardware (optional), which needs to be purchased. 5. Module This module displays extended functions that can be used with external devices. Notes: These functions require additional hardware (optional), which needs to be purchased. 6. Update This module allows you to update the diagnostic software &...
  • Page 34 In this function, you can request remote assistance through third-party software. By sending your device ID number to the remote technician or after-sales personnel, you can authorize the other party to remotely operate the Phoenix XLink device, to guide you through the problems encountered in the process of using the device.
  • Page 35 8.1 OBD Fault Code Library: To view the definition of DTCs (Diagnostic Trouble Codes). 8.2 Coverage List: To view the supported functions and car systems after selecting the vehicle make. 8.3 Learning Materials: To view the playback of operating functions on specifi c vehicle models.
  • Page 36 Tap “OK” to enter the vehicle diagnostic feedback selection menu. *Explanation of terms: Feedback: To show the tested vehicle model list. • • History: To view all diagnostic feedback and check the processes. • Offline-list: To display all diagnostic feedback logs which have not been submitted successfully yet due to the network failure.
  • Page 37 11. User Info You can modify or add related information in this module or adjust settings. 11.1 Phoenix Device This option allows you to choose the suitable Device if there are several Device registered on the tablet. 11.2 Fix MDCI Firmware/System This option can repair the MDCI fi...
  • Page 38 11.8 Business Information This option can add information about the workshop which will be displayed in the diagnostic report. 11.9 Customer Management This option manages the information and data of clients. 11.10 Photo Album This module saves the screenshots. 11.11 Screen Recorder This module saves the screen recordings.
  • Page 39: Technical Specifi Cation

    Technical Specifi cation Operating System: Android 10.0 Screen: 10” Touchable; 1280 * 800 Memory: 4G Storage: 128G Battery Capacity: 12,000mAh/3.8V Camera: Rear 13.0MP Network: Wi-Fi, WLAN 802.11b/g/n Bluetooth: Bluetooth 5.0 Working Temperature: 32 F~122 F (0 C~50 Storage Temperature: -4 F~140 F (-20 C~60...
  • Page 40: Warnings

    Warnings Always perform automotive testing in a safe environment. DO NOT smoke near the vehicle during testing. DO NOT place the diagnostic tool near the engine or exhaust pipe to avoid damage from high temperatures. DO NOT wear loose clothing or jewelry when working on an engine. DO NOT connect or disconnect any test equipment while the ignition is on or the engine is running.
  • Page 41: Faq

    The tablet has been standby for too Charge it for over 2 hours before long, and the battery drains. turning it on. Please contact the dealer or TOPDON Problem of the Charger. after-sale service for timely support. Q: Why can't I register?
  • Page 42 Serial number and activation code input (the serial number consists of 12 digits, is incorrect and the activation code consists of 8 digits) Contact TOPDON after-sales service Activation code is valid to get support. Contact TOPDON after-sales service It prompts the setting is omitted to get support.
  • Page 43 Q: Can I use other chargers to charge the tablet? A: No, please use the original charger provided by TOPDON. Any damage and economic loss caused by using the improper battery charger will not be our responsibility. Q: How to save the battery power? A: Please switch off the screen while the tablet is idle, or set a short standby time, or reduce the brightness of the screen.
  • Page 44: Warranty

    TOPDON shall not be liable for any incidental or consequential damages arising from the device's use, misuse, or mounting. If there is any confl ict between the TOPDON warranty policy and local laws, the local laws shall prevail. This limited warranty is void under the following conditions: •...
  • Page 45 FCC Statement Any changes or modifi cations not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause...
  • Page 46 for sale to the public, it must be tested and certifi ed to the FCC that it does not exceed the limit established by the government adopted requirement for safe exposure. The tests are performed in positions and locations (e.g., at the ear and worn on the body) as required by the FCC for each model.
