Topdon Phoenix Lite 2 User Manual

Topdon Phoenix Lite 2 User Manual

Smart automotive diagnostic system
Hide thumbs
Table of Contents

Advertisement

Quick Links

For Services and Support
TEL
EMAIL
WEBSITE
FACEBOOK
TWITTER
86-755-21612590
1-833-629-4832 (North America)
SUPPORT@TOPDON. COM
WWW.TOPDON. COM
@TOPDONOFFICIAL
@TOPDONOFFICIAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Phoenix Lite 2 and is the answer not in the manual?

Questions and answers

Related Manuals for Topdon Phoenix Lite 2

Summary of Contents for Topdon Phoenix Lite 2

  • Page 1 For Services and Support 86-755-21612590 1-833-629-4832 (North America) EMAIL SUPPORT@TOPDON. COM WEBSITE WWW.TOPDON. COM FACEBOOK @TOPDONOFFICIAL TWITTER @TOPDONOFFICIAL...
  • Page 2 Phoenix Lite 2 Smart Automotive Diagnostic System USER MANUAL...

  • Page 4: Table Of Contents

    Contents Welcome ....................3 About ....................... 3 Package List ................... 3 Compatibility ..................3 Notice ...................... 4 General Information of OBDII (On-Board Diagnostics II) ..... 4 Diagnostic Trouble Codes (DTCs) ............4 Product Descriptions ................5 Preparation & Connection ..............7 Operation Introduction ................

  • Page 6: Welcome

    Welcome Thank you for purchasing TOPDON's Smart Automotive Diagnostic System Phoenix Lite 2. Please read and understand this user manual prior to the operation. About TOPDON's Phoenix Lite 2 features comprehensive diagnostic capabilities. The accuracy of test readings, expanded vehicle coverage, improved speed and an abundance of user- friendly nature make this diagnostic tablet stand out in its class and give mechanics and professionals a great deal of help in their diagnostic work.

  • Page 7: Notice

    Notice Phoenix Lite 2 may automatically reset while being disturbed by strong static electricity. THIS IS A NORMAL REACTION. This user manual is subject to change without written notice. Read the instruction carefully and use the unit properly before operating. Failure to do so may cause damage and/or personal injury, which will void the product warranty.

  • Page 8: Product Descriptions

    Product Descriptions Name Descriptions • Hold the button for 3 seconds to turn the tablet on, or off. Power Button • Hold the button for 10 seconds for a forced restart. Type-C Charging Slot For charging the tablet. USB Port Can be used to charge 5V electronic devices.
  • Page 9 Name Descriptions Three LED indicators are provided on each side, and the prompts are as follows: • Power: Green light indicates power on. Indicator Light • Connect:Blue light means that it has been connected to the device by bluetooth. • Vehicle: Blue flashing shows that it is communicating with the vehicle.

  • Page 10: Preparation & Connection

    Preparation & Connection 1. Turn the ignition off. 2. Locate the vehicle’s DLC port. 3. Plug the TOPDON Phoenix MDCI Lite dongle into the vehicle’s DLC port.
  • Page 11 4. Turn the ignition on. The engine can be off or running. 5. Hold the power button for 3 seconds to turn the tablet on. (The tablet must be charged.) The tablet will start initializing and enter the following interface: Note: Don’t connect or disconnect any test equipment with the ignition on or engine running.
  • Page 12 7. Connect Wi-Fi The system will automatically search all available Wi-Fi networks. Please connect to the trusted Wi-Fi accounts. 8. Choose Time Zone Choose the time zone of your current location. The system will automatically confi gure the time.
  • Page 13 Please read all the terms and conditions of the user agreement carefully. Select “Agree with above terms”. Tap “Next” to log in. The following page will appear: 10. Create an Account You can log in with an available TOPDON account, or register a new account with a valid e-mail address.
  • Page 14 Both the serial number and the activation code are available in the “Password Letter”. The activation procedure is necessary for using the Phoenix Lite 2 properly. Tap “Activate” to fi nish the procedure, and get started with Phoenix Lite 2.

  • Page 15: Operation Introduction

    Operation Introduction TOPDON's Phoenix Lite 2 features an array of practical functions, including Scan, AutoScan, Services, Tester, Support, Update, Library, History, Feedback, Coverage List and User Info. TOPDON's Phoenix Lite 2 supports AutoScan and Scan covering OBDII diagnosis, full system diagnosis for most modern vehicle models worldwide.
  • Page 16 Not all cars support the AutoScan function due to auto manufacturers' settings. 2. Scan(Manual Diagnosis) If Phoenix Lite 2 fails to get access to the vehicle VIN data automatically, tap “Scan” on the Home Menu. The following page will appear: There are two ways in this module to get access to vehicle diagnostic functions.
  • Page 17 2.1.1 Tap “Camera Scan”. The following page will appear If the VIN barcode cannot be recognized, please tap to manually input the VIN. After scanning, the following page will appear:...
  • Page 18 Note: the VIN code in yellow can be modifi ed if it isn’t correct. 2.1.2 Or, tap “Enter VIN”, the following page will appear: You need to input the vehicle’s VIN manually. Note: VIN characters need to be capital letters A through Z and numbers 1 through 0.
  • Page 19 Tap "OK", the tablet will automatically navigate to the Show Menu: 2.2.1 Health Report It enables you to quickly access all the electronic control units of the vehicle and generate a detailed report about vehicle health. (This function varies from vehicle to vehicle.) "Health Report", the system will start scanning Electronic Control Units to see if there are fault code and displays the specifi c results.
  • Page 20 Click "Report" to generate a vehicle health report.
  • Page 21 2.2.2 System Scan This function will automatically scan all systems of the vehicle. Scan the manually selected vehicle electric control system. Tap “PCM” --- as an example to demonstrate. The following page shows the selection interface. Note: This function will be available only when the diagnostic software supports it. A.
  • Page 22 B. Diagnostic Trouble Code This function can read the Diagnostic Trouble Codes (DTCs) in the ECU memory, helping quickly identify the cause of the vehicle breakdown. Tap “Read Fault Code”. The screen will display diagnostic results. *Explanation of terms: • Freeze Frame: Take a snapshot of specifi c data streams for verifi cation when the DTC occurs.
  • Page 23 Select the data stream and tap “OK”: The system can display data streams in three modes: 1) Value (default): Shows parameters with numbers and lists. 2) Graph: Displays parameters with wave patterns. 3) Combine: The graphs can be merged for easier comparisons. *Explanation of terms: •...
  • Page 24 Once the recording process is complete, tap “ ” to end the recording. The following page will appear: You can change the Min or Max value, and tap “Save” to save it as a Data Stream Sample. All Data Stream Sample fi les are stored in “User Info -> Data Stream Sample”.
  • Page 25 Tap the fi le you need. The following page will appear: The Standard Range column will show the corresponding Data Stream Sample values for your comparison and analysis. • Graph: To have the selected data streams (12 max items) displayed in waveform.
  • Page 26 Tap “<“ on the right side of the screen. The following page will appear: Tap “Value” to view the data displayed in values. Tap “Combine” to merge graphs for easier comparisons (max 4 values can be merged). You can select specifi c data stream options to be viewed on the left. Note: A maximum of 12 data streams can be displayed in this module.
  • Page 27 Tap “Min/Max” to defi ne the maximum/minimum value. Once the value goes beyond the specifi ed value, the data will be shown in red. Tap “<“ on the right side of the screen. The following page will appear: You can select specifi c data stream options to be viewed on the left. Note: A maximum of 4 data streams can be displayed in this module.
  • Page 28 Tap "System Selection", and the screen will enter selection interface. 3. Services TOPDON Phoenix Lite 2 is equipped with maintenance services to be very benefi cial for technicians and mechanics working in the automotive repair industry. 3.1 OIL (Maintenance Light Reset)
  • Page 29 It needs to be performed in the following cases: • After replacing the electronic control unit, the relevant characteristics of the throttle operation have not been stored in the electronic control unit. After the electric control unit is powered off, the memory of the electric control unit is •...
  • Page 30 3.6 BRAKE (Electronic Parking Brake Reset) This function helps you to replace and reset the brake pads. It needs to be performed in the following cases: • The brake pads and brake pad wear sensor are replaced. The brake pads indicator lamp is on. •...
  • Page 31 3.12 SUS (Suspension Level Calibration) This function is required to calibrate the level of the vehicle when the level sensor or control module in the air suspension system is replaced or when the level of the vehicle is incorrect. 3.13 AFS (Adaptive Front-lighting System Reset) This function enables you to initialize the adaptive headlamp system.
  • Page 32 It needs to be performed in the following cases: • When the following functions disabled including limiting the vehicle speed, not waking up the door opening network, and disabling the remote control key, etc. in order to reduce the power consumption. 3.20 A/F (A/F Reset) This function can set or learn Air/Fuel ratio parameters.
  • Page 33 ID number to the remote technician or after-sales personnel, you can authorize the other party to remotely operate the Phoenix Lite 2 device, so as to guide you to the problems encountered in the process of using the device.
  • Page 34 6. Update This module allows you to update the diagnostic software & App to the latest version. Tap “Update” on the Home Menu. The following page will appear: Tap “Update” to upgrade the selected software. 7. Library Tap “Library” on the Home Menu. The following page will appear:...
  • Page 35 7.1 OBD Fault Code Library: To view the defi nition of DTCs (Diagnostic Trouble Codes). 7.2 Learning Materials: To view the playback of operating functions on specific vehicle models. 7.3 Chrome: chrome browser. 8. History This module can record and establish the file of the diagnosed vehicles, including all diagnostic-related data such as diagnostic reports, data stream records, and screenshots.
  • Page 36 Tap “OK” to enter the vehicle diagnostic feedback selection menu. *Explanation of terms: • Diagnostic Feedback: To show the tested vehicle model list. History: To view all diagnostic feedback and check the processes. • • Offline List: To display all diagnostic feedback logs which have not been submitted successfully yet due to the network failure.
  • Page 37 10. Coverage List To view the supported functions and car systems after selecting the vehicle make, model, year, and inputting information required on the following page: 11. User Info You can modify or add related information in this module, or make settings. 11.1 Phoenix MDCI This option allows you to choose the suitable MDCI dongle if there are several dongles registered on this tablet.
  • Page 38 11.2 Activate MDCI This option can activate a new MDCI dongle. Input the Serial Number and Activation Code, and then tap “Activate” to activate the MDCI dongle. Its serial number will be displayed in the list after the procedure. 11.3 Fix MDCI Firmware/System This option can repair the MDCI fi rmware.

  • Page 39: Technical Specification

    Technical Specifi cation Operating System: Android 10.0 Screen: 8” Touchable; 1280 * 800 Memory: 2G Storage: 64G Battery Capacity: 12,600mAh/3.7V Camera: Rear 8.0MP Network: Wi-Fi, WLAN 802.11b/g/n Bluetooth: Bluetooth 5.0 Working Temperature: 32 F~122 F (0 C~50 Storage Temperature: 14 F~140 F (-10 C~60...

  • Page 40: Warnings

    DO NOT connect or disconnect any test equipment while the ignition is on or the engine is running. DO NOT disassemble the Phoenix Lite 2. Engine parts will become hot when the engine is running. To prevent severe burns, avoid contact with hot engine parts.

  • Page 41: Faq

    The tablet has been standby for too Charge it for over 2 hours before long, and the battery drains. turning it on. Please contact the dealer or TOPDON Problem of the Charger. after-sale service for timely support. Q: Why cannot register?
  • Page 42 (serial number 12 digits, activation code 8 digits).· Contact TOPDON after-sales service The activation code is invalid. to get support. Contact TOPDON after-sales service The confi guration is empty.
  • Page 43 Firmware/System” to fi x the fi rmware. Q: Can I use other chargers to charge the tablet? A: No, please use the original charger provided by TOPDON. Any damage and economic loss caused by using the improper battery charger will not be our responsibility.
  • Page 44 • Whether the ignition switch is ON. Q: The MDCI Lite dongle is missing. A: Please contact the dealer or TOPDON after-sale service for timely support. Q: Error of the diagnostic software. A: Please operate as follows: Tap “Feedback” to send specifi c problems to us for technical support.
  • Page 45 TOPDON shall not be liable for any incidental or consequential damages arising from the device's use, misuse, or mounting. If there is any confl ict between the TOPDON warranty policy and local laws, the local laws shall prevail. This limited warranty is void under the following conditions: •...
  • Page 46 FCC Requirement Changes or modifi cations not expressly approved by the party responsible for compliance could void the user’ s authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause...
