Summary of Contents for Topdon Phoenix Plus 2
- Page 1 For Services and Support 86-755-2 1612590 1-833-629-4832 (North America) EMAIL SUPPORT@TOPDON.COM WEBSITE WWW.TOPDON.COM FACEBOOK @TOPDONOFFICIAL TWITTER @TOPDONOFFICIAL...
- Page 2 Phoenix Plus 2 Smart Automotive Diagnostic System USER MANUAL...
-
Page 4: Table Of Contents
Contents Welcome ....................3 About ....................... 3 Package List ................... 3 Compatibility ..................3 Notice ...................... 4 General Information of OBDII (On-Board Diagnostics II) ..... 4 Diagnostic Trouble Codes (DTCs) ............4 Product Descriptions ................5 Preparation & Connection ..............7 Operation Introduction ................ -
Page 6: Welcome
Welcome Thank you for purchasing TOPDON's Smart Automotive Diagnostic System Phoenix Plus 2. Please read and understand this user manual prior to the operation. About TOPDON's Phoenix Plus 2 features comprehensive diagnostic capabilities. The accuracy of test readings, expanded vehicle coverage, improved speed and an abundance of user- friendly features make this diagnostic tablet stand out in its class and give mechanics and professionals a great deal of help in their diagnostic work. -
Page 7: Notice
Notice Phoenix Plus 2 may automatically reset while being disturbed by strong static electricity. THIS IS A NORMAL REACTION. This user manual is subject to change without written notice. Read the instructions carefully before operating and use the unit properly according to the guide. -
Page 8: Product Descriptions
Product Descriptions Name Descriptions 10” Touchable Screen Show test results. Hold the button for 3 seconds to turn the tablet on • or off. Power Button Hold the button for 2 seconds for a forced shutdown. • • Press the button to wake up the screen or turn off the screen. - Page 9 Backplane Remove and install added modules on the backend. Used for communication between the function module and the tablet. Keep the tablet standing on a surface or hang the Adjustable Stand tablet on the steering wheel. Rubber Corner Secure the tablet from shock and accidental dropping. Protections Name Descriptions...
-
Page 10: Preparation & Connection
Preparation & Connection 1. Turn the ignition off. 2. Locate the vehicle’s DLC port. 3. Plug the TOPDON Phoenix MDCI dongle into the vehicle’s DLC port. - Page 11 4. Turn the ignition on. The engine does not need to be running. 5. Hold the power button for 3 seconds to turn the tablet on. (The tablet must be charged.) The tablet will start initializing and enter the following interface: Note: Do not connect or disconnect any test equipment with the ignition on or engine running.
- Page 12 7. Connect Wi-Fi The system will automatically search all available Wi-Fi networks. Select the Wi-Fi network you want to connect to. 8. Choose Time Zone Choose the time zone of your current location. The system will automatically confi gure the time.
- Page 13 9. User Agreement Please read all the terms and conditions of the user agreement carefully. Select “Agree with above terms." Tap “Next” to log in. The following page will appear: 10. Activate Please enter your email and tap the CAPTCHA button to obtain the Validation Code. After entering the Validation Code, tap the OK button.
-
Page 14: Operation Introduction
Operation Introduction TOPDON's Phoenix Plus 2 features an array of practical functions, including Scan, AutoScan, Services, ADAS, Module, Update, Support, Library, History, Feedback and User Info. TOPDON's Phoenix Plus 2 supports AutoScan and Scan covering OBDII diagnosis, full system diagnosis for most modern vehicle models worldwide. - Page 15 Not all cars support the AutoScan function due to auto manufacturers settings. 2. Scan(Manual Diagnosis) If Phoenix Plus 2 fails to get access to the vehicle VIN data automatically, tap “Scan” on the Home Menu. The following page will appear: There are two ways to get access to vehicle diagnostic functions.
- Page 16 2.1.1 Tap “Camera Scan." The following page will appear: After scanning, the following page will appear: Note: the VIN code in yellow can be modifi ed if it isn’t correct. If the VIN barcode cannot be recognized, please tap to manually input the VIN.
- Page 17 2.1.2 After selecting “ ," the following page will appear: You will need to input the vehicle’s VIN manually. Note: VIN characters need to be capital letters A through Z and numbers 1 through 0. However, the letters I, O, and Q won't be used in order to avoid misreading. No symbols or spaces are allowed in the VIN.
- Page 18 Select “Demo” as an example and the following page will appear: Tap “OK." Select “Demo" from the pop-up Notes. Then select a vehicle make. The tablet will automatically navigate to the Show Menu: The interface has two display modes, one of system topology and one of system list, both with the same functions.
- Page 19 2.2.1 Smart Scan This function is used to quickly detect vehicles and view vehicle health reports (this item will only be displayed if the vehicle's model diagnosis software supports this function). Tap “Smart Scan," the system starts to scan fault codes in each system and displays specifi c scan results.
- Page 20 2.2.2 System Scan This function will scan all systems of the vehicle. 2.2.3 Choose to Scan Scan the manually selected vehicle electronic control system. As an example, tap “PCM," then tap “Choose to Scan" to scan the system. Tap “PCM" and tap “Enter." The following page will appear.
- Page 21 B. Diagnostic Trouble Code This function can read the Diagnostic Trouble Codes (DTCs) in the ECU memory, helping quickly identify the cause of the vehicle breakdown. Tap “Read Fault Code." The screen will display diagnostic results. *Explanation of terms: • Freeze Frame: Take a snapshot of specifi c data streams for verifi cation when the DTC occurs.
- Page 22 Select the data stream and tap “OK”: The system can display data streams in three modes: 1) Value (default): Shows parameters with numbers and lists. 2) Graph: Displays parameters as wave patterns. 3) Combine: Both Values and Graphs can be merged for easier comparisons. *Explanation of terms: •...
- Page 23 Once the recording process is complete, tap “ ” to end the recording. The following page will appear: You can change the Min or Max value and tap “Save” to save it as a Data Stream Sample. All Data Stream Sample fi les are stored in “User Info -> Data Stream Sample."...
- Page 24 Select the fi le you need. The following page will appear: The Standard Range column will show the corresponding Data Stream Sample values for your comparison and analysis. Graph: To have the selected data streams (max 12 items) displayed in •...
- Page 25 Tap “<“ on the right side of the screen. The following page will appear: Tap “Value” to view the data displayed in values. Tap “Combine” to merge graphs for easier comparisons (A maximum of 4 values can be merged). You can select specific data stream options to be viewed on the left. Note: A maximum of 12 data streams can be displayed in this module.
- Page 26 Tap “Min/Max” to defi ne the maximum/minimum values. Once the value goes beyond the specifi ed values, the data will be shown in red. Tap “<“ on the right side of the screen. The following page will appear: You can select specifi c data stream options to view in the chart. Note: A maximum of 4 data streams can be displayed in this module.
- Page 27 2.2.4 ADAS Calibration Tap “ADAS Calibration," and the screen will enter the selection interface. 3. Services TOPDON Phoenix Plus 2 is equipped with benefi cial maintenance services for technicians and mechanics working in the automotive repair industry. 3.1 OIL (Maintenance Light Reset)
- Page 28 Use cases: • After replacing the electronic control unit, the relevant characteristics of the throttle operation have not been stored in the electronic control unit. After the electric control unit is powered off, the memory of the electric control unit is •...
- Page 29 3.6 BRAKE (Electronic Parking Brake Reset) This function helps you to replace and reset the brake pads. Use cases: The brake pads and brake pad wear sensor are replaced. • • The brake pads indicator lamp is on. The brake pads sensor circuit is short, which is recovered. •...
- Page 30 3.12 SUS (Suspension Level Calibration) This function is required to calibrate the level of the vehicle when the level sensor or control module in the air suspension system is replaced or when the level of the vehicle is incorrect. 3.13 AFS (Adaptive Front-Lighting System Reset) This function enables you to initialize the adaptive headlamp system.
- Page 31 3.20 A/F (A/F Reset) This function can set or learn Air/Fuel ratio parameters. 3.21 STOP/START (Stop/Start Reset) This function can open or close the automatic start-stop function by setting the hidden function in ECU (provided that the vehicle has a corresponding hidden function supported by hardware).
- Page 32 3.30 CODAGE ECU After performing the encoding function of some systems, the control unit needs to be reset. Sometimes bad driving habit data can also be eliminated by resetting the ECU. The ECU reset service can command the ECU to perform self-reset through diagnostic commands.
- Page 33 3.35 IMMO PROG The anti-theft programmer supports car key chip reading/writing, EEPROM chip reading/writing, and MCU chip reading/writing. 4. ADAS The Advanced Driver Assistance System (ADAS) is an electronic component in vehicles that includes a variety of vehicle safety functions such as automatic emergency braking (AEB), lane departure warning (LDW), lane keeping assistance, blind spot elimination, night vision cameras, and self-adaptive lighting.
- Page 34 ID number to the remote technician or after-sales personnel, you can authorize the other party to remotely operate the Phoenix Plus 2 device, to guide you through the problems encountered in the process of using the device.
- Page 35 8.1 OBD Fault Code Library: To view the definition of DTCs (Diagnostic Trouble Codes). 8.2 Coverage List: To view the supported functions and car systems after selecting the vehicle make. 8.3 Learning Materials: To view the playback of operating functions on specific vehicle models.
- Page 36 10. Feedback If you encounter any unsolved problems in the diagnostic process, you can send the last 20 test records to us by using the “Feedback” feature for timely technical EN assistance. Tap “Feedback” on the Home Menu. The following page will appear: Tap “OK”...
- Page 37 *Explanation of terms: • Feedback: To show the tested vehicle model list. History: To view all diagnostic feedback and check the processes. • • Offline-list: To display all diagnostic feedback logs which have not been submitted successfully yet due to the network failure. The failed logs will be re-uploaded automatically once the tablet gets a stable network signal.
- Page 38 11.4 Profi le Sets and manages personal information. 11.5 Wi-Fi This option sets up Wi-Fi networks to be connected. 11.6 Diagnostic Software Clear This option can clear unused diagnostic software and free up the storage space. 11.7 Business Information This option can add information about the workshop which will be displayed in the diagnostic report.
-
Page 39: Technical Specification
Technical Specifi cation Operating System: Android 10.0 Screen: 10” Touchable; 1280 * 800 Memory: 4G Storage: 64G Battery Capacity: 12600 mAh/3.8 V Camera: Rear 8.0MP Network: Wi-Fi, WLAN 802.11b/g/n Bluetooth: Bluetooth 5.0 Working Temperature: 32 F~122 F (0 C~50 Storage Temperature: -4 F~140 F (-20 C~60... -
Page 40: Warnings
DO NOT connect or disconnect any test equipment while the ignition is on or the engine is running. DO NOT disassemble the Phoenix Plus 2. Engine parts will become hot when the engine is running. To prevent severe burns, avoid contact with hot engine parts. -
Page 41: Faq
The tablet has been standby for too Charge it for over 2 hours before long, and the battery drains. turning it on. Please contact the dealer or TOPDON Problem of the Charger. after-sale service for timely support. Q: Why can't I register? - Page 42 Firmware/System” to fi x the fi rmware. Q: Can I use other chargers to charge the tablet? A: No, please use the original charger provided by TOPDON. Any damage or economic loss caused by using the improper battery charger will not be our responsibility.
- Page 43 Q: The MDCI dongle is missing. A: Please contact the dealer or TOPDON after-sale service for timely support. Q: Diagnostic software error. A: Tap “Feedback” to send specifi c problems to us for technical support. Tap the vehicle software icon and hold it to uninstall the corresponding software. Then enter the upgrade center to download and install a new version.
-
Page 44: Warranty
TOPDON shall not be liable for any incidental or consequential damages arising from the device's use, misuse, or mounting. If there is any confl ict between the TOPDON warranty policy and local laws, the local laws shall prevail. This limited warranty is void under the following conditions: •... - Page 45 FCC Statement Any changes or modifi cations not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause...
