- Page 1 SPH3000TL BL-US SPH3600TL BL-US SPH4000TL BL-US SPH4600TL BL-US SPH5000TL BL-US SPH6000TL BL-US Installation & Operation Manual Download Manual GR-UM-200-A-00 GR-UM-200-A-00...
- Page 2 1.4 Safety Instructions 2 Safety Safety Measure Symbols introduction on the SPH inverter 3 Product Description 3.1 Growatt SPH series inverter 3.2 Label Explanation 3.3 Size and weight 3.4 The advantage of the unit of SPH Unpacking 5 Installation 5 1 Basic installation requirements...
- Page 3 6 Commissioning 11 Decommissioning 6.1 Commissioning of SPH 11.1 Dismantling the energy storage 6.2 Operation modes 11.2 Packing the SPH inverter 6.3 Display and button 11.3 Storing SPH inverter 6.4 Communication 11.4 Disposing of the SPH inverter 7 Start-up and shut down 12 Product specification SPH system 12.1 SPH series energy storage machine...
-
Page 4: Brief Introduction
SPH TL BL-US for self consumption or when Grid power is lost, SPH TL BL-US Antenna can be used as backup power. SPH series has six kinds of type USB interface Ÿ SPH3000TL BL-US PV switch Dry contact Ÿ SPH3600TL BL-US PV input port ... - Page 5 1.4 Safety Instructions 2.2 Symbols introduction on the SPH inverter 1. Please be clear which kind of battery system you want, lithium battery system or Symbol Description lead-acid battery system, if you choose the wrong system, SPH can’t work normally. 2.
- Page 6 Product description 3.3 Size and weight 3.1 Growatt SPH series inverter Marks of SPH: Mark Description Explanation Push-button Operation of display screen and set system SPH run normally Green light on Red light on Fault state Status symbol of SPH...
-
Page 7: Installation
Unpacking Installation 5 5.1 Basic installation requirements Please check whether external damage to the goods before unpacking. A. The installation location must be suitable for SPH's weight for a long period time B. The installation location must conforms with dimension of SPH After unpacking, please check whether the unit damage or missing parts, if it is C. - Page 8 K. Don't install the machine in the living area. L. Be sure that the machine is out of the children's reach. There're two types of sensors for use with Growatt SPH. One is wired current sensor, M. Taking the battery fixing space into account, about the dimensions please one is meter sensor, if you choose wired sensor or meter.
- Page 9 5.3.2 Installation of SPH 1. Project the machine’s probably sizes on the wall, the thickness of wall for SPH must be not less than 60mm. 2. Make sure the drill position, use paper board (installation guide), put the paper board cling to the wall and make sure the top edge of paper board is level (As the chart below).
- Page 10 (Optional) 1.Use cables that can withstand 90°C Purchased by Ground cable at (194°F) or 105°C (221°F). 6 AWG the customer the PV 2.Single-core outdoor copper cable 1.Use cables that can withstand 90°C Purchased by Battery cable (194°F) or 105°C (221°F). 6-4 AWG the battery 2.Single-core outdoor copper cable...
- Page 11 Limit: 5.5 SPH System electrical connection Max PV voltage: 550V (consider the lowest temperature) 5.5.1 Connection of PV terminal Max PV input current: 13A Remark: 1. Please do not connect to DC source! 2. For RSD function, the default brand of RSD supplier is Tigo, including AP system and other brand RSD can be integrated.
- Page 12 AC output terminal connection steps as follow: EPS output terminal connection steps as follow: 1 7mm 17mm E-L1 E-L2 PE Step 1: Remove the locking nut and waterproofing bolt. Step 1: Remove the locking nut and waterproofing bolt. Step 2: Route the AC output power cable through the conduit and then the fitting of the Step 2: Route the EPS output power cable through the conduit and then the fitting of pipe.
- Page 13 6. If you want to use on gird and off grid, you can use ATS (transfer switch single phase) like chart before or ask Growatt for help to connect them. ATS is using to switch when SPH is not working or in fault mode. For example: if SPH is in fault mode but there is Grid power.
- Page 14 5.5.3 Connection of battery terminal 5.5.4 Connection of CT terminal or meter Install battery cable steps are as follows: There is a CT or meter communication in SPH inverter to monitor the power consumption situation of residential users, so the CT terminal or meter connection steps are as follows: Step 1: Remove the locking nut and waterproofing bolt..
- Page 15 Grid to Load. Sensor needs to be placed in the power distribution cabinet. 2. Meter must be provided by Growatt. If not, maybe meter can't communicate with SPH inverter. 3. The more detail description of meter installation, please turn to meter user manual.
- Page 16 5.5.6 Connection of temperature probe for lead-acid battery 5.5.5 Connection of communication terminal for lithium battery (CAN) When customer using lead-acid battery, the temperature probe of the lead-acid When using CAN communication with lithium batteries (for example HOMEe11), connect lithium battery terminal (RJ45) steps as follows: battery is used to detect the ambient temperature of the lead-acid battery, the battery temperature cable of the SPH side connection steps are as follows: Step 1: Remove the locking nut and waterproofing bolt..
- Page 17 Commissioning 6 5.5.7 Connection of Dry contact 6.1 Commissioning of SPH The dry contact is used to communicate with external devices (such as remote start Electrify SPH after all installation of Part5 be finished, here are the steps: hot water heater). The wiring steps are as follows: 1.
- Page 18 Back up mode 6.3 Display and button Back up mode is used for bad weather, if back up mode is enable, battery will be 6.3.1 LCD display area charged first. Customer can set up charging power ratio and stop SOC. If back up mode continued more than 3 days.
- Page 19 The B line's information as follow: 6.3.2 LED and button instruction In normal, it will turn on page automatically, when pushing the button “UP”, the order of the paging information as follow: WorkMode PV1/PV2 today energy Epv_d:xxxx.x KWh WorkMode Input&Output Para WorkMode PV1/PV2 total energy Epv_a:xxxx.x KWh...
- Page 20 Note: 1. Under the Basic Para, you can see the setup options below after pressing Enter for 1. “Down” control command (if pushing “up” button, command will go back). 2. Workmode depend on the situation. If SPH is normal state, it will show “normal”. If Press “enter”...
- Page 21 3. Under the Priority, you can see the setup options below after pressing Enter: 5. Under the ExportLimit, you can see the setup options below after pressing Enter: If you need to enable AC charging If battery first is choosen P r e s s “...
- Page 22 8. Under the default set, you can see the setup options below after pressing Enter: 7. Under the Backup set, you can see the setup options below after pressing Enter: Press “enter” key more Press “enter” key to make WorkMode WorkMode WorkMode WorkMode...
- Page 23 Note: Removing RS232 cover first: This kind of monitoring can only be used by the monitor of Growatt's Shineserver /shine phone provided by the company. Through RS232 interface connect to Wi-Fi- S/shinelink/GPRS, use computer terminal/or mobile phone for data monitoring.
- Page 24 4. Turn the switch on in turn of PV, Grid and battery SPH inverter stops working. Growatt SPH series inverter without fan so belongs to 5. When the LED turns green, the working information on LCD indicates the...
-
Page 25: Fault Removal
Output High Error Message Discription Suggestion standard for disconnection Please contact Growatt service center if time when the output DC restart can't solve the problem. Check the wire connection between meter and current is too high. inverter is good or not. -
Page 26: Manufacturer Warranty
Manufacturer Warranty 10 Error Message This certificate represents a 5 year warranty for the Growatt products listed below. Error Fault Discription Suggestion Possession of this certificate validates a standard factory warranty of 5 years from the Message date of purchase. - Page 27 Decommissioning 11 Liability 11.1 Dismantling the energy storage The liability of manufacturer in respect of any defects in its machines shall be limited 1. Disconnect the storage machine such as mentioned in section 7. to compliance with the obligations as stated in these terms and conditions of warranty. 2.
-
Page 28: Product Specification
12 Product specification 12.1 SPH series energy storage machine product specification Model SPH3000 SPH3600 SPH4000 Specifications TL BL-US TL BL-US TL BL-US Model SPH3000 SPH3600 SPH4000 Specifications TL BL-US TL BL-US TL BL-US Battery data（DC） Input data(DC) Battery voltage range 42~59V Max. - Page 29 Model SPH4600 SPH5000 SPH6000 Model SPH3000 SPH3600 SPH4000 Specifications TL BL-US TL BL-US TL BL-US Specifications TL BL-US TL BL-US TL BL-US Input data(DC) Self-Consumption < 12 W*4 Max. recommended PV power(for 8000 module STC) Topology Transformerless Max. DC voltage Cooling Natural Start voltage...
- Page 30 Model SPH4600 SPH5000 SPH6000 Model SPH4600 SPH5000 SPH6000 Specifications TL BL-US TL BL-US TL BL-US Specifications TL BL-US TL BL-US TL BL-US Battery data（DC） Self-Consumption < 12 W*4 Battery voltage range 42~59V Topology Transformerless Recommended battery voltage Cooling Natural Max. charging / discharging current Protection degree IP65/ NEMA Type 4X Continuous charging / discharging...
- Page 31 Upper cover screws 1.3Nm(10.8 1bf.in) different countries and regions of different safety standards. Shell and RS232screws 0.7Nm(6.2 1bf.in) Model Certificate Dc connector 1.8Nm(16.0 1bf.in) SPH3000TL BL-US UL1741:2018, SPH3600TL BL-US M6 screwdriver 2Nm(18 1bf.in) IEEE1547, SPH4000TL BL-US CSA C22.2, SPH4600TL BL-US Grounding screw 2Nm(18 1bf.in)
-
Page 32: Annex: Technical Data
Annex: Technical Data 1 Parameter setting according to Rule21 1.2 Ride-Through High Frequency and Low Frequency 1.1 Ride-Through High Voltage and Low Voltage Required settings in accordance with Parameter name Maximum Rule 21 Maximum UL 1741 SA Required settings in accordance Parameter name Rule 21 with UL 1741 SA... - Page 33 1.3 Normal e and soft Start rise rate (RR, SS) Volt-var Minimum Maximum Default Value Parameters Adjustable Range Adjustable Range RR: When normal startup, the output power rise is 1%~100%, the maximum output current/section is adjustable. SS: The output power is increased by 1%~100% for inverter reconnection after grid fault 0.92Vn 0.90Vn 1.05Vn...
- Page 34 2 Remote control inverter on/off and modify parameter settings When the grid frequency reaches 60+db , the inverter output active power is PM. The inverter have the following functions: Remote receive message from the utility or its agent to start or shutdown inverter; Remote receive message form the utility or its agent to complete parameter setting, enable or disable the above function in accordance to Rule21.The remote control software: ShineBus can be obtained from the equipment provider.
- Page 35 3 Test parameter tolerances Default Tolerance of Parameter Units Measurement Voltage Volts ±1%Urated Current Amps ±1%Irated Power Watts ±1%Prated Reactive Power ±1%Srated Power Factor Displacement power factor ±0.01 Frequency ±0.05 Response Time Seconds Time accuracy Total time 0.1%...
