- Page 2 Page intentionally left blank...
- Page 3 New document format Added secondary brake wiring December 12, 2019 Updated Accucoder encoder wiring March 5, 2020 Updated Construction procedure to include the run box must be set to ON March 5, 2020 ©2020 Smartrise Engineering, Inc. All Rights Reserved Page i...
- Page 4 Drive Startup Manual DSD412 Page intentionally left blank Page ii © 2020 Smartrise Engineering, Inc. All Rights Reserved March 5, 2020...
-
Page 5: Table Of Contents
Drive Power-Up Sequence ..................7 Abnormal Display Conditions .................. 8 Fan Check ........................ 9 Verify Parameters ....................9 Magnetek DSD412 Drive Self-Tune Procedure ............10 Shuddering at High Speed ..................11 Operation ......................12 No Faults ..........................12 Proper Direction ........................12 At Speed .......................... - Page 6 Figure 6: Terminal Connections ............................. 6 Figure 7: DIP Switch ............................... 7 Figure 8: Encoder Connection ............................7 Figure 9: NVRAM Protection Switch ..........................9 Figure 10: Terminal Locations ............................14 Page iv © 2020 Smartrise Engineering, Inc. All Rights Reserved March 5, 2020...
- Page 7 List of Tables Table 1: Wiring References for Common Encoders ....................... 3 Table 2: Abnormal Display Conditions and Solutions ....................8 Table 3: Magnetek DSD412 Parameters ........................9 March 5, 2020 ©2020 Smartrise Engineering, Inc. All Rights Reserved Page v...
- Page 8 Drive Startup Manual DSD412 Page intentionally left blank Page vi © 2020 Smartrise Engineering, Inc. All Rights Reserved March 5, 2020...
-
Page 9: Dsd412 Drive
Drive Startup Manual DSD412 DSD412 Drive The DSD412 drive is a DC drive. Figure 1: DSD412 Drive Equipment/Settings Verification Set and verify the equipment matches the job specific parameters for proper operation. See the C4 Controller sheet 01 Getting Started Parameter Table for more information. -
Page 10: Grounding Requirements
Perform the following to connect power. See the C4 Controller sheet 03 Machine Room for job specific information. • Connect main line power to terminal blocks L1/L2/L3. • Connect the ground wire to the yellow/green terminal block next to L1-L3. Page 2 © 2020 Smartrise Engineering, Inc. All Rights Reserved March 5, 2020... -
Page 11: Brake
Green Yellow Yellow Yellow Yellow Red/Black Blue Gray Black Blue Blue Orange Gray Gray Gray Green Violet CLK+ CLK- DAT+ DAT- SHIELD Shield Shield Shield Shield Shield Shield March 5, 2020 ©2020 Smartrise Engineering, Inc. All Rights Reserved Page 3... -
Page 12: Construction
Connect a jumper from 24VDC to MM. Verify the Car Door Bypass and Hoistway Bypass switches are in the OFF position. Place the Inspection switch to INSPECTION. Page 4 © 2020 Smartrise Engineering, Inc. All Rights Reserved March 5, 2020... -
Page 13: Figure 4: Example Of Construction Wiring
Drive Startup Manual DSD412 Figure 4: Example of Construction Wiring March 5, 2020 ©2020 Smartrise Engineering, Inc. All Rights Reserved Page 5... -
Page 14: Powering Up
Perform the following to power-up the drive. Apply external power by closing the main disconnect. Close the two-pole breaker and all pushbutton breakers. Verify the LCD on the Smartrise board and the Magnetek Drive powers up. Figure 5: Breakers Setup Perform the following connections as shown in the figures below. -
Page 15: Drive Power-Up Sequence
LEDs come on for about 1 second. The LEDs and display should turn off. The drive performs internal checks. The SCDU displays tESt while a self-test is being performed. March 5, 2020 ©2020 Smartrise Engineering, Inc. All Rights Reserved Page 7... -
Page 16: Abnormal Display Conditions
Press the RESET push button. The drive goes through its power-up sequence again; however, this time it will initialize the unprotected NVRAM and load in factory supplied default parameter values. Page 8 © 2020 Smartrise Engineering, Inc. All Rights Reserved March 5, 2020... -
Page 17: Fan Check
• Set the NVRAM PROTECTION switch to the protect position (UN PROT NV RAM light is off) to ensure that set up data cannot be corrupted. • Run the controller to verify drive changes. The table below lists the Magnetek DSD412 Parameters. Table 3: Magnetek DSD412 Parameters Parameter... -
Page 18: Magnetek Dsd412 Drive Self-Tune Procedure
Remove the jumper and perform Function #994 to permanently save the changed values. Verify the Smartrise MR board LCD is not showing an active fault as indicated by a flashing Red LED, and it displays Construction Mode. Close the Run Bug Stop switch. -
Page 19: Shuddering At High Speed
• Make sure the encoder is electrically insulated from the motor shaft and frame. • If using a friction wheel encoder, make sure both surfaces are perfectly round. March 5, 2020 ©2020 Smartrise Engineering, Inc. All Rights Reserved Page 11... -
Page 20: Operation
No Faults Make sure the car is moving without triggering a fault either on the Smartrise SRU Board or the drive. If the SRU Board displays a drive fault, look at the drive to see what the fault is. See Drive Fault / Encoder Fault for troubleshooting drive fault. -
Page 21: Troubleshooting
If the car is moving in the wrong direction check the following: • On the Smartrise Controller board, make sure that IO CUP comes on when commanding the UP direction and IO CDN comes on when commanding the DOWN direction. -
Page 22: Appendix
Drive Startup Manual DSD412 Appendix The figure below shows the terminal locations. Figure 10: Terminal Locations Page 14 © 2020 Smartrise Engineering, Inc. All Rights Reserved March 5, 2020...
