- Page 3 Drive Startup Manual KEB-PM Document History Date Version Summary of Changes October 23,2018 Initial Submittal August 23,2019 Changed cover page New document format Added secondary brake wiring August 23,2019 ©2019 Smartrise Engineering, Inc. All Rights Reserved Page i...
- Page 4 Drive Startup Manual KEB-PM Page intentionally left blank Page ii © 2019 Smartrise Engineering, Inc. All Rights Reserved August 23,2019...
-
Page 5: Table Of Contents
Car Moving to Slow or Rough ..................... 10 Appendix 1 Terminal and Encoder Card Locations ............ 11 Appendix 2 KEB Programming Menu ................ 13 Appendix 3 Advanced Troubleshooting ..............15 August 23,2019 ©2019 Smartrise Engineering, Inc. All Rights Reserved Page iii... - Page 6 Drive Startup Manual KEB-PM Starting Over (Defaulting Drive) ....................15 Vibration ............................ 15 Motor Noise ..........................15 Motor Not Running When Given Command ................15 Page iv © 2019 Smartrise Engineering, Inc. All Rights Reserved August 23,2019...
- Page 7 Figure 3: Ground Bus Terminal ............................2 Figure 4: Example of Construction Wiring ........................5 Figure 5: Breakers ................................6 Figure 6: Terminal Locations ............................11 Figure 7: Encoder Terminal Location ........................... 12 August 23,2019 ©2019 Smartrise Engineering, Inc. All Rights Reserved Page v...
- Page 8 Drive Startup Manual KEB-PM List of Tables Table 1: Wiring References for Common Encoders ....................... 3 Table 2: Parameter Groups ............................13 Page vi © 2019 Smartrise Engineering, Inc. All Rights Reserved August 23,2019...
-
Page 9: Keb Drive
Figure 2: Example of Parameter Table Scroll through the motor parameters and verify that they are set to the motor nameplate values prior to performing the Motor Learn procedure. August 23,2019 ©2019 Smartrise Engineering, Inc. All Rights Reserved Page 1... -
Page 10: Grounding Requirements
Figure 3: Ground Bus Terminal The building, motor, transformer, and filter(s) must all share a common ground. This removes ground loops, limits impedance, and routes noise into the ground. Page 2 © 2019 Smartrise Engineering, Inc. All Rights Reserved August 23,2019... -
Page 11: Wiring
Green and Black Green Blue / Black Red/ Blue Yellow and Black Yellow Red/Black Blue Blue and Black Blue Red/Black (7) Red and Black CLK+ Gray White Gray Black August 23,2019 ©2019 Smartrise Engineering, Inc. All Rights Reserved Page 3... -
Page 12: Construction
Connect a jumper from 24VDC to MM. Verify the Car Door Bypass and Hoistway Bypass switches are in the OFF position. Place the Inspection switch to INSPECTION. Page 4 © 2019 Smartrise Engineering, Inc. All Rights Reserved August 23,2019... -
Page 13: Powering Up
Figure 4: Example of Construction Wiring Powering Up Perform the following to power up the drive. Apply external power by closing the main disconnect. Close the two-pole breaker and all pushbutton breakers. August 23,2019 ©2019 Smartrise Engineering, Inc. All Rights Reserved Page 5... -
Page 14: Encoder Cable
Drive Startup Manual KEB-PM Verify the LCD on the Smartrise board and the Magnetek Drive powers up. Figure 5: Breakers Encoder Cable Proper connection of the encoder cable to the drive is key to a proper running elevator. Many drive issues can be attributed to a defective encoder, encoder cable, or the encoder (or cable) not installed properly. -
Page 15: Initial Setup
See Encoder Synchronization for more information. If the Encoder Synchronization process has previously been completed, the user may abort the Encoder Synchronization step without losing the learned Encoder Pole Position. August 23,2019 ©2019 Smartrise Engineering, Inc. All Rights Reserved Page 7... -
Page 16: Encoder Synchronization
No Faults Make sure the car is moving without triggering a fault either on the Smartrise SRU Board or the drive. If the SRU Board displays a drive fault, look at the drive to see what the fault is. See Drive Fault / Encoder Fault for troubleshooting drive fault. -
Page 17: Troubleshooting
Wrong Direction If the car is moving in the wrong direction check the following: On the Smartrise controller board make sure that IO CUP comes on when commanding the UP direction and IO CDN comes on when commanding the DOWN direction. -
Page 18: Car Moving To Slow Or Rough
If the car is moving to slow or rough perform the following: Swap the A with /A phasing by navigating to parameter LE03 and selecting A-B Swapped. Run LL05 after swapping the phases. Verify the brakes are lifting fully. Page 10 © 2019 Smartrise Engineering, Inc. All Rights Reserved August 23,2019... -
Page 19: Appendix 1 Terminal And Encoder Card Locations
Drive Startup Manual KEB-PM Appendix 1 Terminal and Encoder Card Locations The figure below shows the terminal and encoder wire terminal locations. Figure 6: Terminal Locations August 23,2019 ©2019 Smartrise Engineering, Inc. All Rights Reserved Page 11... -
Page 20: Figure 7: Encoder Terminal Location
Drive Startup Manual KEB-PM Figure 7: Encoder Terminal Location Page 12 © 2019 Smartrise Engineering, Inc. All Rights Reserved August 23,2019... -
Page 21: Appendix 2 Keb Programming Menu
LO01 - LO20 Outputs Defines the functionality of the relay and solid-state drive outputs. Defines the settings for the control with serial FB01 - FB55 Field Bus Configuration communication. August 23,2019 ©2019 Smartrise Engineering, Inc. All Rights Reserved Page 13... - Page 22 Drive Startup Manual KEB-PM Parameter Parameter Group Description TS01 - TS08 Terminal Slowdown Defines the settings for the NTSD inputs and speed thresholds. Page 14 © 2019 Smartrise Engineering, Inc. All Rights Reserved August 23,2019...
-
Page 23: Appendix 3 Advanced Troubleshooting
Navigate to US05 and select Write Configuration to Drive. Perform the following to re-load OEM values (Programmed by Smartrise). Go to US05 and select Restore OEM Defaults to reload Smartrise settings. Vibration If any vibration occurs: Cut the KP (LC03, LC04) and KI (LC08, LC09) gains in half. - Page 24 Drive Startup Manual KEB-PM Page intentionally left blank Page 16 © 2019 Smartrise Engineering, Inc. All Rights Reserved August 23,2019...
