IMPORTANT!
Read this entire installation manual to ensure proper installation. When
fi nished with the installation, fi le this manual with the owner or maintenance
department. Compliance and conformity to local codes and ordinances is
the responsibility of the installer. Bradley cannot assume any responsibility
for improperly installed units.
Separate parts from packaging and make sure all parts are accounted for
before discarding packaging material. If any parts are missing, do not begin
installation until you obtain the missing parts.
Make sure that all water supply lines have been fl ushed and then completely
turned off before beginning installation. Debris in supply lines can cause
valves to malfunction.
Product warranties may be found under "Products" on our web site at
bradleycorp.com.
Installation
CBSHWR9000KD
Cabinet Shower
Table of Contents
Supplies Required . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Rough-In Information . . . . . . . . . . . . . . . . . . . . . . . . . 2
Installation Instructions . . . . . . . . . . . . . . . . . . . . . . . 3
Cleaning Instructions . . . . . . . . . . . . . . . . . . . . . . . . . 4
P.O. Box 309, Menomonee Falls, WI 53052-0309
Phone: 1-800-BRADLEY
bradleycorp.com
Fax: 262-253-4161
Advertisement
Related Manuals for Bradley CBSHWR9000KD
Summary of Contents for Bradley CBSHWR9000KD
- Page 1 fi nished with the installation, fi le this manual with the owner or maintenance Installation department. Compliance and conformity to local codes and ordinances is the responsibility of the installer. Bradley cannot assume any responsibility for improperly installed units. Separate parts from packaging and make sure all parts are accounted for Packing List •...
- Page 2 1/2" Supply: Nominal Copper Tube Right Side 2-1/4" (57) No-Hub P-Trap (if specified) 5˝ Chase (127) 2˝ (51) Shower Front 2-1/4" (57) No-Hub Elbow (if specified) Finished Floor 2-3/4˝ 1-3/4˝ Showerhead Connection Point (44) (70) 4-9-10 Bradley Corporation • 215-1676; EN 10-07-002...
- Page 3 Attach Access Panel Assembly to the cabinet with security screws provided. 3/8" NPT Tube Connector Caulk around Valve Panel to seal 9036KD Left Side Back View of Chase Panel against water intrusion. Chase Shown. Bradley Corporation • 215-1676; EN 10-07-002 4-9-10...
- Page 4 Many products named are regional in distribution, and can be found in local supermarkets, department and hardware stores, or through your cleaning service. It is emphasized that all products should be used in strict accordance with package instructions. 4-9-10 Bradley Corporation • 215-1676; EN 10-07-002...
