.40 ARF LOW WING TRAINER
Wingspan
Fuselage length
Engine: 40 - 46 2T / 52 - 60 4T
Electric Motor: 600-700W
Radio: 5 channel / 4-5 servo
RC Functions: Rudder - Elevator - Aileron - Throttle
WARNING! This radio controlled model is NOT a toy. If modified or flown carelessly it could go out of controll and
cause serious human injury or property damage. Before flying your airplane, ensure the air field is spacious enough.
Always fly it outdoors in safe areas and seek professional advice if you are unexperienced.
RADIO CONTROL MODEL
ASSEMBLY INSTRUCTION
Mega fly
1510mm
1070mm
Advertisement
Related Manuals for VQ Mega Fly
Summary of Contents for VQ Mega Fly
- Page 1 RADIO CONTROL MODEL ASSEMBLY INSTRUCTION Mega fly .40 ARF LOW WING TRAINER Wingspan 1510mm Fuselage length 1070mm Engine: 40 - 46 2T / 52 - 60 4T Electric Motor: 600-700W Radio: 5 channel / 4-5 servo RC Functions: Rudder - Elevator - Aileron - Throttle WARNING! This radio controlled model is NOT a toy.
-
Page 2: Required For Operation
REQUIRED FOR OPERATION Purchase separetely Silicone tube 10.5x6 for .40 - 2 cycle engine 11x6 for .46 - 2 cycle engine 11x7 for .52 - 4 cycle engine 12x7 ~13x6 - Electric motor Extension for aileron servo. Brushless Motor Radio a 5 channel (min) .40 - .46 - 2T .52 - .70 4T 600-720W... -
Page 3: Joining The Wing
Joining the wing Before gluing: - Draw the center line on the wing joiner. - Trial fit each part before gluing . Be certain that there are no gaps. If the parts will join, but with a gaps, sand or trim the parts a little at a time until the parts meet exactly with no gaps. - Page 4 Aileron servo installation Cut away the covering of the wing bottom where the aileron servo goes. Pull the thread out of the wing and connecting the aileron servo extension cord to one end of the thread. Pull one end of the thread (on the top and near the wing root) to install the aileron extension cord into the wing.
- Page 5 4- Main wing/installing the main gear BOTTOM VIEW Main gear 1- Locate the main landing gear struts and place them into the landing gear slot as show. Make sure that the ends of the struts are inserted into 3x12 mm screw the holes in the landing gear channel.
- Page 6 After confirming the direction . Insert this assembly, clunk end 7-Fuel tank first, into the fuel tank and tighten and screw the fuel tank cap on firmly. Ensure that the fuel tank clunk does not touch the rear of the fuel tank. To muffler Filler tube Rubber stopper...
- Page 7 FUSELAGE - BOTTOM VIEW 9-Servo Throttle rod Elevator servo Throttle servo Switch Elevator rod Fuel tank BATTERY AREA Rudder rod Rudder servo Nose gear rod 10- Linkage Rudder - elevator linkages Rudder push rod Steel clevis To rudder servo To elevator servo Elevator push rod 11- Windshield...
- Page 8 - This model aircraft is designed to be powered by a 2 cycle .40 ~ .46 engine or a 4 cycle .48 ~ .52 engine. Installing a more powerful engine than specified or flying the MEGA FLY aggressively may lead to serious damages and accidents.
