M O T O R I Z E D C H A N G E - O V E R A N D T R A N S F E R S W I T C H E S , O T M _ C
—

3. Quick start

This is a quick guide only meant for those who need a reminder of how to operate the unit.
For more detailed instructions, see chapter 6.
—
3.1 Operating the motorized change-over switch electrically; remote control
To operate the motorized change-over switch electrically:
1. Remove the handle from the switch panel. You can remove the handle in all positions (I, 0, II).
2. Turn the Motor/Manual selector to the Motor (M) position to enable electrical operation.
M M
M a n . M a n .
Figure 3.1 Operating the motorized change-over switch electrically; remote control
M M M M
M a n . M a n .
M a n .
M M M M
M a n . M a n .
M a n .
