34OTA-OKA125-600 / rev. C / 1SCC340167M0203
Aluminum enclosed safety switch/switch-disconnector
OTA125-600, OKA125-600
Installation instruction
1
Type
OTA/OKA125-160
OTA/OKA200-400
OTA/OKA600
Product dimensions and fixing dimensions.
2
Cut holes according to cable
size in cable glands.
A
B
C
459
431
364
519
491
424
619
591
524
3
Cable position to be adjusted
and tightened with cable
clamps.
D
E
F
519
586
614
615
682
710
752
819
847
G
H
J
656
425
196
752
485
208
890
585
251
4
The red shock absorbers shall
not be removed or replaced
with any other parts. Damaged
pipes must be replaced.
K
152
162
205
M8
4,0 Nm
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for ABB OTA125
Summary of Contents for ABB OTA125
- Page 1 34OTA-OKA125-600 / rev. C / 1SCC340167M0203 Aluminum enclosed safety switch/switch-disconnector OTA125-600, OKA125-600 Installation instruction Type OTA/OKA125-160 OTA/OKA200-400 OTA/OKA600 Product dimensions and fixing dimensions. 4,0 Nm Cut holes according to cable Cable position to be adjusted The red shock absorbers shall size in cable glands.
- Page 2 13 21 43 31 14 22 44 32 OTA/OKA125-160 22 Nm OTA/OKA125-160 / 1NO+1NC OTA/OKA200-600 / 2NO+2NC OTA/OKA200-400 45 Nm OTA/OKA600 77 Nm Wiring diagram for OTA/OKA125-600. Tightening torques. Connection bar lugs can be OTA/OKA125-600 connection bar mounting. mounted only on top of connection bars.
- Page 3 OZXB-types that fit OTA/OKA125-160 OZXB2L OZXB8 OZXB9 OTA/OKA200-400 OZXB9 OTA/OKA600 OZXB4* Ø5...10 mm List of OZXB connection terminal types compatible with OTA/OKA types. Handles lockable in OFF-position. Handles lockable in ON-position are available on request. Pay special attention! *OTA/OKA 600 OZXB4 mountable under OTA/OKA 125-400 OZXB_ mountable on top connection bars only for clearance to of connection bars with provided lock bolts.
- Page 4 For more information please contact: ABB Oy, Protection and Connection P.O. Box 622, FI-65101 Vaasa, Finland new.abb.com/low-voltage...
