ABB OTM C Series Installation And Operating Instruction page 10

10
M O T O R I Z E D C H A N G E - O V E R A N D T R A N S F E R S W I T C H E S , O T M _ C
A 1
Figure 4.2 Motorized change-over switches, drilling hole distances / screw-mounting, [mm/in]
3,5...4 Nm 31...35.4 lb.in
OTM160-250_C_
OTM315_400_C_
OTM160-250_C_M
E3
E4
A1 116
116
A2 258 293
OTM315-400_C_M
E3 E4
142 142
A1
A2 305 349
OTM630-800_C_M
E4
E3
A1 180 180
A2 390 455
OTM1000-1250_C_M
E3
E4
A1 230 230
A2 556,5
476,5
OTM2000-2500_C_M
E3 E4
A1 230
230
A2
614,5 740,5
OTM3200-4000_C_M
E3 E4
A1
250 250
A2 661,5 801,5
M M M M
M a n .
M a n . M a n .
M5
OTM600-800E_C_
OTM160-250_WC_M
E3 E4
116 116
282 325
OTM400_C_M
U3 U4
142/5.59 142/5.59
335/13.19
389/15.31
OTM600_C_M
U4
U3
180/7.09 180/7.09
390/15.35 455/17.91
OTM1600_WC_M
E4
E3
230 230
556,5
476,5 476,5/18.77
M6 M10
OTM800-1200U_C_
OTM1000-2500_C_
OTM3200_C_
OTM200_C_M
U4
U3
116/4.57 116/4.57
282/11.10 325/12.80
OTM800-1200_C_M
U4
U3
230/9.06
230/9.06
556,5/21.92
