M O T O R I Z E D C H A N G E - O V E R A N D T R A N S F E R S W I T C H E S , O T M _ C
2. Turn the Motor/Manual selection switch to the Motor (M) position, see Figure 8.2.
I
0
I I
Figure 8.2 Motor/Manual selection switch in the Motor (M) position
3.
Operate the motorized change-over switch with the push-buttons or selector switch via impulse
control or continuous control.
The motor operator is protected from overloading by a fuse (F1) under the motor operator.
Only use the same type of fuse that is described on the label close to the fuse.
Information
M M
M a n . M a n .
M a n .
M a n .
M M
M M M M
M a n . M a n .
M a n .
