M O T O R I Z E D C H A N G E - O V E R A N D T R A N S F E R S W I T C H E S , O T M _ C
—

10. Accessories

—
10.1 Terminal clamp sets OZXA_, OZXB_
Figure 10.1 Mounting of the terminal clamp sets, types OZXB_ and OZXA_
OTM2000-2500E_C_
OTM3200E_C_
OZXB3
OZXB4
OZXB5
OZXB6
OZXB7L
OTM1000-1600E_C_
OZXB3
OZXB4
OZXB5
*
OZXB6
OZXB7L
OTM630-OTM800E_C_
OZXB3
OZXB4
OZXB5
OZXB6*
OZXB7L
OTM315-OTM400E_C_
OZXB2L
OZXB3
OZXB7
OZXB7L
OZXB8
OZXB9
OTM160-OTM250E_C_
OZXB1L
OZXB2
OZXB2L
OZXB8
OZXB9
OTM800-1200U_C_
OZXA-1200_
OZXA-1206_
* max. 1 pcs/side
OTM600U_C_
OZXA-800_
OZXA-806_
* max. 1 pcs/side
OTM400U_C_
OZXA-400_
OZXA-406_
OTM200U_C_
OZXA-200_
OZXA-206_
