44
M O T O R I Z E D C H A N G E - O V E R A N D T R A N S F E R S W I T C H E S , O T M _ C
—

11. Clearances per UL 1008

Size (Current)
OT_100-1200U_C
Minimum enclosure size or equivalent volume
Size (current)
OTMDC100_C
OTM200U_C
OTM400U_C
OTM600U_C
OTM800-1200U_C
Figure 11.1 Clearances per UL 1008, minimum enclosure size or equivalent volume
A B
0 0.5 in/13 mm
Height
6.3 in/190 mm
16 in/406 mm
24 in/610 mm
24 in/610 mm
48 in/1220 mm
D C
According to the UL1008
0.5 in/13 mm
standard
Width
19 in/490 mm
12 in/305 mm
14 in/356 mm
28 in/700 mm
24 in/610 mm
Depth
12 in/315 mm
8 in/203 mm
10 in/254 mm
16 in/400 mm
16 in/400 mm
