Oneida Vortex DCS
Dust Containment Systems
Keep the Job Clean!
Sander
Not Included
The most effective portable floor sanding dust containment system
"I gotta say, that's an impressive machine."
Vortex Gorilla Vac
Dust Containment System
Owner's Manual
with patented vortex technology.
TM
Norm Abram
This Old House
TM
Episode #2615
12_13
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Oneida Air Systems Vortex DCS
Summary of Contents for Oneida Air Systems Vortex DCS
- Page 1 Oneida Vortex DCS Dust Containment Systems Keep the Job Clean! 12_13 Sander Not Included Owner’s Manual The most effective portable floor sanding dust containment system with patented vortex technology. “I gotta say, that’s an impressive machine.” Norm Abram This Old House...
- Page 2 Without proper dust collection, workers are exposed on every job and customers are exposed until all dust is finally cleaned up. Not a good situation for either party. Collect Dust at the Source! OAS Vortex DCS Owner’s Manual O.A.S. 2013...
- Page 3 Congratulations! You have purchased a state-of-the-art Oneida Vortex DCS Dust Containment System for floor sanding machines. In order to facilitate your transition to using our system, makesure all people using the system read the Owner’s Manual. The information provided is very important to the day-to-day opera- tion of the dust containment system.
- Page 4 Flex Hose out to 2nd lies on the Cyclone on dust drum seam between and Vac Pump. the elbow and exhaust stack. Watch for leaks at this location. Tighten clamp OAS Vortex DCS Owner’s Manual O.A.S. 2013...
- Page 5 This is a quick way to maintain your filters on the job and must be done when the Sander is off. It does not take the place of cleaning filters with compressed air. OAS Vortex DCS Owner’s Manual O.A.S. 2013...
- Page 6 *Note: Use only the amount of hose that is necessary to do the job. Extended lengths will impair waste pick-up at cyclone. Shorter lengths will improve waste removal at cyclone, especially for aggressive sanding. OAS Vortex DCS Owner’s Manual O.A.S. 2013...
- Page 7 This is VERY important! System will not work unless filters are clean! Turn crank up and down filter. Blow off filter from At least 3” away outside with compressed air while Vac pump is ON and Sander is OFF. OAS Vortex DCS Owner’s Manual 2013...
- Page 8 2 1/8” Tube Clamp 2 1/8” Tube Clamp VRC002125 VRC002125 Lagler Trio Retrofit Kit VSRSLT000 5” Includes: VXA040000 - Lagler Trio Retrofit VSACPH250 - 2.5” Clamp *Refer to installation sheets for retrofit instructions. OAS Vortex DCS Owner’s Manual O.A.S. 2013...
