Figure D-5 displays the RS-366 Y cable, part number 1200120L1.
DB25 Female
Primary RS-366
DB25 Female
Secondary RS-366
Figure D-6 displays the RS-530 to V.35 adapter cable, part number 1200072L1.
DB25 Male
RS-530
61202.086L1-1
RS-530 to V.35 Adapter Cable
ISU 512 User Manual
Appendix D. Pinouts
DB25 Male
RS-366 Port
Figure D-5
RS-366 Y Cable
V.35
Connector
Figure D-6
95
