- Page 1 Operating Instructions Electronics module VEGAMIP series 60 - emitting unit VEGAMIP series 60 - receiving unit Document ID: 37349 Radar...
-
Page 2: Table Of Contents
Contents Contents About this document Function........Target group ......Symbolism used. -
Page 3: About This Document
1 About this document 1 About this document 1.1 Function This operating instructions manual provides all the information you need for mounting, connection and setup as well as important instructions for maintenance and fault rectification. Please read this information before putting the instrument into operation and keep this manual accessible in the immediate vicinity of the device. -
Page 4: For Your Safety
2 For your safety 2 For your safety 2.1 Authorised personnel All operations described in this operating instructions manual must be carried out only by trained specialist personnel authorised by the plant operator. During work on and with the device the required personal protective equipment must always be worn. -
Page 5: Product Description
3 Product description 3 Product description 3.1 Configuration Scope of delivery The scope of delivery encompasses: Electronics module for emitting unit VEGAMIP series 60 (MP60EE.T**) or electronics module for receiving unit VEGAMIP series 60 (MP60EE.R**) Documentation this operating instructions manual 3.2 Principle of operation Application area The electronics module MP60 is suitable as a replacement for the... - Page 6 3 Product description Relative humidity 20 … 85 % Electronics module • VEGAMIP series 60 - receiving unit...
-
Page 7: Mounting
4 Mounting 4 Mounting 4.1 Instructions for installation If the electronics module is defective, it can be replaced by the user. In Ex applications only one instrument and one electronics module with respective Ex approval may be used. 4.2 Mounting preparations Keep in mind that the emitting and receiving unit require special electronics modules. - Page 8 4 Mounting Information: Make sure that the housing is not rotated during the electronics exchange. Otherwise the plug may be in a different position later. Screw in the two holding screws and tighten them Insert the terminal block again. You must hear it snap in. 10 Screw the housing cover back on The electronics exchange is now finished.
- Page 9 4 Mounting 10 Carry out the adjustment according to the operating instructions of the sensor 11 Screw the housing cover back on The electronics exchange is now finished. As a rule, an exchange of electronics must be documented internally when Ex applications are involved. Electronics module •...
-
Page 10: Setup
5 Setup 5 Setup 5.1 Setup Setup After having exchanged the electronics module, the complete setup must be carried out. The adjustment should be carried out according to the description in the operating instructions manual. Electronics module • VEGAMIP series 60 - receiving unit... -
Page 11: Maintain
Attach the completed form and, if need be, also a safety data sheet outside on the packaging Please contact for the return shipment the agency serving you. You can find the agency on our home page www.vega.com. Electronics module • VEGAMIP series 60 - receiving unit... -
Page 12: Dismounting
7 Dismounting 7 Dismounting 7.1 Dismounting steps Warning: Before dismounting, be aware of dangerous process conditions such as e.g. pressure in the vessel, high temperatures, corrosive or toxic products etc. Take note of chapters "Mounting" and "Connecting to power supply" and carry out the listed steps in reverse order. -
Page 13: Supplement
8 Supplement 8 Supplement 8.1 Technical data Technical data are stated in the operating instructions manual of the respective sensor. Electronics module • VEGAMIP series 60 - receiving unit... - Page 14 8 Supplement Electronics module • VEGAMIP series 60 - receiving unit...
- Page 15 8 Supplement Electronics module • VEGAMIP series 60 - receiving unit...
- Page 16 All statements concerning scope of delivery, application, practical use and operating conditions of the sensors and processing systems correspond to the information avail- able at the time of printing. © VEGA Grieshaber KG, Schiltach/Germany 2012 Subject to change without prior notice 37349-EN-121205...
