Signature™ Collection

Maintenance

To clean your bathtub, simply use a mild, nonabrasive liquid detergent solution. You can protect and restore the gloss
to a dulled acrylic surface by applying Meguiar's #10 Mirror Glaze, a product specifically designed for use on acrylic
finishes. If Meguiar's is not available, use a fine grade automotive rubbing compound followed by an application of clear
automotive paste wax.
Minor scratches which do not penetrate the color finish can be removed by lightly sanding with 600-grit wet/dry
sandpaper. Restore the gloss using Meguiar's Mirror Glaze or automotive paste wax. Major scratches and gouges
which penetrate the acrylic surface will require refinishing. Call Jacuzzi Luxury Bath to find a service agent in your area.
Suction Cover/Strainer Maintenance
Clean the suction cover/strainer of hair and debris when
necessary (Figure 16).
Remove the center screw and detach the suction cover.
1
Clean the cover by backflushing debris from the holes.
2
Replace the suction cover immediately after cleaning.
3
WARNING
Keep hair a minimum of 6 inches (152 mm) away from
the suction fitting at all times when the whirlpool system is
operating. Hair longer than shoulder length should be secured
close to the head, or a bathing cap should be worn.
Do not operate the whirlpool system with the suction cover/
strainer removed! It is a safety device and must always be in
place on the suction fitting to minimize the potential hazard of
hair and body entrapment.

Skirt Panel Installation

To remove the skirt panel -
Grasp an edge of the skirt panel and pull to separate.
To reinstall the skirt panel (Figure 17) -
Align the six (6) posts on the panel with the six (6)
receptor sockets on the tub and press into place.
Skirt Panel Adjustment (Figure 18) -
Insert a standard screwdriver into the receptor socket,
through the slot at the rear. Turn clockwise to tighten and
counter-clockwise to loosen.
Interior View
Bathtubs with Optional Skirt
If you are installing an optional skirt, please refer to the Skirt Installation Guide before proceeding any further.
Installation and Operation
Fig. 18
Receptor Socket
Slot
Exterior View
www.jacuzzi.com
Suction Fitting
Suction Cover
Screw
Receptor Socket
Post
Fig. 16
Fig. 17
Page 11
