Jacuzzi Signa 5 w/Skirt Y345 Specification Sheet

signa 5 whirlpool bath with Integral skirt - front right motor/pump
®
the signa ® whirlpool bath takes its name from the medieval central Italian walled city, lastra a signa.
Like the walled city for which it is named,
Signa 5 was specially developed and
®
designed for walled surround spaces.
features:
• Contoured backrest.
• 4 Fully adjustable TheraPro™ jets
• 2 AccuPro™ foot jets.
• Exclusive Tru-Level™ base system.
• Slip-resistant bottom.
• Patented Silent Air™ Induction system.
• Integral skirt
• Electronic controls
• Drain included on whirlpool baths
signa 5 whirlpool bath
®
(with integral skirt)
model number: Y345 – front right pump
exterior dimensions:
60" long x 42" wide x 22" high
interior dimensions (at bottom):
41" long x 25" wide
# of Jets/type of Jets:
4 TheraPro™ Jets,
2 AccuPro™ Foot Jets
operating gallons:
42 gallons
signa 5 soaking bath
®
(with integral skirt)
model number: Y350
exterior dimensions:
60" long x 42" wide x 22" high
interior dimensions:
41" long x 25" wide
