Summary of Contents for CORNING Axygen MotoPet
- Page 1 Axygen® MotoPet® Pipet Controller Instruction Manual...
- Page 2 A – Aspiration button: PP B – Dispense button: PP C – Suction speed switch: PP D – Dispense mode switch: PP E – Display F – Nose piece: PP G – Pipet holder: SI H – Membrane filter: PP/PTFE J – Connector gasket: SI K – Battery cover: PP L –...
- Page 3 Table of Contents 1. Introduction The Axygen®MotoPet® pipet controller is a device intended for pipetting liquids with the use of measuring pipets. It can work with all types of glass or plastic pipets in the volume 1. Introduction ..............5 range from 0.5 mL to 100 mL.
- Page 4 • The pipet controller should not be used for drawing solutions with a temperature above Setting the Volume 50°C. After filling the pipet, the end should be dried with an absorbent paper that will not leave • The pipet controller should be operated in the temperature range from +10°C to +35°C. impurities, in order to remove any excess solution on the outside surface of the pipet. To set the required liquid volume precisely, press the dispense button gently (Figure 3C), • T he pipet controller is suitable for general laboratory use only. It must be used only by dispense the excessive liquid from the pipet until the meniscus of the liquid aligns exactly personnel who know the health risks associated with the substances that are normally with the required volume mark on the pipet.
- Page 5 4. The battery level is indicated by displaying three ‘’bars” which display continuously • Wall hanger (Figure 5.1). The pipet controller has a NiMH type battery. 11. Ordering Information The service life of the battery is approx. 1,000 charging cycles, if used correctly. It is not The Axygen® Motopet® pipet controller (Corning Cat. No. MOTOPET-1) comes with a uni- possible to overcharge the battery, if all instructions of the manufacturer are followed. versal charger and a set of adapters in different versions: EU, US, UK, and AUS. Choose your country’s adapter and connect to the housing. Note: Charging should not be interrupted. If the charging process is interrupted, the next charging cycle should only be after the battery has been completely discharged.
- Page 6 Warranty/Disclaimer: Unless otherwise specified, all products are for research use only. Not intended for use in diagnostic or therapeutic procedures. Corning Life Sciences makes no claims regarding the performance of these products for clinical or diagnostic applications. All rights reserved. Product described in this manual is subject to availability and technical modification. Errors excepted.
- Page 7 For additional product information, visit www.corning.com/lifesciences or call 1.800.492.1110. Customers outside the United States, call +1.978.442.2200 or contact your local support office. Corning Incorporated Worldwide E U R O P E Support Offices Life Sciences France t 0800 916 882 836 North St.
