AP410C Hardware Guide
This icon indicates a general caution. Failure to comply with a caution notification can result in damage to equipment.
This icon indicates an electrical caution. Failure to comply with an electrical notification can result in serious injury or
death, and extensive damage to equipment.
This icon indicates a laser caution. Failure to comply with a laser caution can result in serious injury.
The following table lists the safety precautions you should follow when installing your AP410C devices.
Extreme Networks devices must be installed by a professional installer who is certified to install these types of devices
and to ensure that they are properly grounded and meet applicable local and national electrical codes.
These devices are intended for indoor use only.
Do not install the device in an environment where the operating ambient temperature might exceed the recom-
mended ranges.
Warning: This is a Class A product. In a domestic environment this product may cause radio interference in which case
the user may be required to take adequate measures.
For products available in the USA/Canada market, for the 2.4 GHz band, only channels 1-11 can be operated. Selec-
tion of other channels is not possible.
Changes or modifications made to this device that are not expressly approved by the party responsible for com-
pliance could void the user's authority to operate the equipment.
Use only attachments and accessories specified by Extreme Networks.
These devices are not intended for use by persons (including children) with reduced physical, sensory, or mental cap-
abilities, or with lack of experience of knowledge unless they are given supervision or instruction concerning use of the
devices by a person who is responsible for their safety. Children should be supervised to ensure that they do not play
with the devices.
Electrostatic discharge (ESD) can damage equipment and impair electrical circuitry. ESD damage occurs when elec-
tronic components are improperly handled and can result in complete or intermittent failures. Be sure to follow ESD-pre-
vention procedures when handling electronic components and equipment.
During operation, the surfaces of the AP410C can become hot. Use caution when handling.
To meet federal radiation exposure requirements, these devices should be installed at a minimum distance of 8" (20 cm)
from people or animals.

Install the AP

You can mount the AP410C on a flat surface or wall, or on the rails of a standard dropped ceiling grid. There is also an accessory mounting bracket
that allows you to install the device in Armstrong-style dropped ceilings (ordered separately).
The following sections describe how to install your AP410C devices.

Shipping Carton Contents

The AP410C shipping carton contains the following items:
AP410C chassis
l
Mounting bracket
l
Read Me card
l
Install the AP on a Ceiling Track
The AP410C ships with a mounting bracket that lets you easily install it on the rail of a standard dropped ceiling grid. The following illustration
shows how to attach the bracket to the ceiling rail, and then install the AP on the bracket.
