STUDIO DUE MINICITY 150 Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Safety informations
Informazioni di sicurezza................................................................................................................... page 1
Caratteristiche tecniche .................................................................................................................... page 3
Prima dell'uso .................................................................................................................................... page 4
Terminale di linea DMX ..................................................................................................................... page 7
Parti di ricambio................................................................................................................................. page 11
Electric diagrams
Schemi elettrici ................................................................................................................................. page 13
S h u t t e r

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MINICITY 150 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for STUDIO DUE MINICITY 150

Summary of Contents for STUDIO DUE MINICITY 150

  • Page 1: Table Of Contents

    Safety informations Informazioni di sicurezza........................page 1 Technical features Caratteristiche tecniche ........................page 3 Before using Prima dell'uso ............................ page 4 Lamp installation, replacement and setting Installazione, sostituzione e regolazione lampada................page 5 Connection to the main power/Fuse replacement Connessione alla rete/Sostituzione fusibili..................page 6 DMX terminal line Terminale di linea DMX ........................

  • Page 2: Informazioni Di Sicurezza

    WARNING SAFETY INFORMATION READ ALL CAUTIONS AND WARNINGS PRIOR TO OPERATE THIS EQUIPMENT. INSTRUCTION TO PREVENT INJURY OR DAMAGE DUE TO ELECTRIC SHOCK, FIRE, MECHANICAL HAZARDS AND UV RADIATION HAZARDS. •PROTECTION AGAINTS FIRE 1)This equipment is designed for use with the following lamps only: Mastercolour 150W •...
  • Page 3 •Art. 0102 MINICITY 150 with shutter for Mastercolour 150W (CDM-T 150W/942 • CDM-SA/T 150W/942). The input protocol is the DMX 512. To drive the MINICITY 150 we suggest to use either our controllers Control Show 512, Fancy or the Easy Control, which can drive the MINICITY 150 in the most appropriate way.

  • Page 4: Technical Features

    TECHNICAL FEATURES • LAMP Mastercolour CDM-T 150W/942 or CDM-SA/T 150W/942) Averange lamp life: 6000 hours Colour temperature: 4200 K Luminous flux: 14000 lumen Colour rendering index: 96 Ra • OPTIC/COLOUR SYSTEM New concept optical system (patent pending) Full CYM color mixing, unlimited variety of colours and shades High resolution stepper motors Colour crossfades can be programmed at four different speeds or in real time •DIMMER (for art.

  • Page 5: Before Using

    2) Collegare i cavi dell’alimentazione al circuito elettronico interno e se necessario (modo sincrono) i cavi DMX (vedere pag. 6). Il MINICITY 150 è fornito per una tensione di lavoro di 230V 50 Hz; 1,1A. Per un’alimentazione di 100-120V è assolutamente necessario un autotrasformatore con le seguenti caratteristiche: •...

  • Page 6: Lamp Installation, Replacement And Setting Installazione, Sostituzione E Regolazione Lampada

    d) Replace the lamp when the lamp life is exhausted (6000 hours) to avoid bad peformances of the fixture or that the optic system is damaged by the lamp explosion. e) The protection screens, the lenses, or the ultraviolet filters must be replaced if they are visibly damaged and their effectiveness has been reduced, for example, by cracks or deep scratches.

  • Page 7: Connection To The Main Power/Fuse Replacement Connessione Alla Rete/Sostituzione Fusibili

    CONNECTION TO THE MAINS POWER AND TO THE DMX SIGNAL / REPLACING FUSES To connect the MINICITY 150 to the mains power, remove the cover located behind the fixture, and connect the cable to the electronic board as shown in pict. 3.

  • Page 8: Dmx Terminal Line

    1) Connect the DMX data cable coming from the controller to the DMX-IN connector on the electronic board (see pict. 3/a page 6). 2) Connect the DMX data cable to the DMX-OUT connector on the electronic board to control the next MINICITY 150 (see pict. 3/a page 6).

  • Page 9: Dmx Signal Connection/Dmx Listing Connessione Segnale Dmx/Lista Valori Dmx

    EXAMPLE OF CONNECTION DMX CONTROLLER-SPOT / ESEMPIO DI COLLEGAMENTO CENTRALINA - FARI DMX CONTROLLER OR LIGHT CONSOLE/ SPOT SPOT SPOT LAST SPOT/ CENTRALINA O BANCO DMX ULTIMO SPOT EXAMPLE 1/ESEMPIO 1 Connection controller-spot with PL AY PROG RA MMIN G ST AN D B Y FA DING 1 DMX 512 OUTPUT...

  • Page 10: Setup Settaggio

    3) Choose the games by operating on the UNITS and TENS rotary switches (on MASTER fixture). Games: from n° 1 to n° 15 4) Set all the rest of the MINICITY 150 as SLAVE by setting n° 7 on the HUNDREDS rotary switch.

  • Page 11: Appendix "B" Appendice "B

    APPENDIX “B” Here below you can find the complete list of available games (ref. page 9). APPENDICE “B” Diamo di seguito la lista completa dei giochi disponibili (rif. pagina 9). ROTARY SWITCHES FUNCTIONS SETTING Red Magenta Yellow –color mix sequence (slow – 30sec) Red Magenta Yellow + White color mix sequence (slow –...

  • Page 12: Spare Parts

    S h u t t e r SPARE PARTS, TECHNICAL DRAWINGS and SCHEMATIC DIAGRAMS PARTI DI RICAMBIO, DISEGNI TECNICI e SCHEMI ELETTRICI ... 11 ...

  • Page 13: Technical Drawings Disegni Tecnici

    •TECHNICAL DRAWING art.9902/0102• ... 12 ...
  • Page 14 •MAIN BOARD art. 9902/art.0102• ... 13 ...
  • Page 15 •ELECTRONIC DIAGRAM art.9902/art.0102• ... 14 ...
  • Page 16 NOTE ... 15 ...
