Beok Controls BOT Series Quick Start Manual page 3

6. Advanced Setting: Long Press Senior
setting mode:
7. Switch of Manual mode and Auto mode: Press
mode or Auto mode.
8.Power off : Press to turn on or off thermostat.
X. Installation Instruction
Insert the equipped USB (Type-C) connector into the charger.
Thermostat can be hung on the wall, or put on the table. User can choose one of
them when he places an order. We will equip corresponding installation bracket
and USB wire for user.
XI. Set Sequence Number
1. Every thermostat has a matched receiver, and thermostat and receiver
have a same group of sequence number. If user mix during installation,
sequence number can be set through the following method.(Sequence
number is unique)
2. In Advance Setting, SNP need to be set 01. Then to set SN through the
following four steps.
Power Off State
The first step, press button under power off state, then press
then press button to enter parameter setting;
The second step, after appearing SN1, press
The third step, every time pressing once
SN5 and SN6 in order. Refer to second step, press
, you will go into Advanced
to switch manual
1. Press button
2. Press button
button,
Modify to be right numbers
or to modify the number;
Modify to be right numbers
Appear SN2-SN6 in order
, it will appear SN2, SN3, SN4,
or to modify.
The forth step, after SN is finished setting, if CHK Code is the same with
bar code, it is correct. If not consistent, it is not correct. Please input again.
3.VAC: Control valves1-8 place numbers. The default value is 01.
(This setting is only useful when thermostat is applied to control Wireless
Main-Control Centralized Controller. If thermostat is used to control boiler,
this setting must be 01.)
XII. ATT:
Thank you for buying this product!
Please read this manual for complete instructions on installing and
operating your thermostat. If you require further assistance, please
feel free to contact us.
In the box you will find:
Model BOT-W306
√
Thermostat
√
User Manual
√
Screws
Receiver
USB Cable
Desktop Support
Bracket(optional)
Wall-hung Support
Bracket(optional)
Our Service:
We offer the warranty of 24 months from the sales day.
During the warranty, if it is belong to the quality issue, we will fix or
replace them for you by free after test them.
If it is not quality problem or beyond the warranty time, we will
charge for the after-sales service.
BEOK
Boiler Thermostat
BOT306 Series
CHK(Check) Code
All SN are correct. CHK code is same.
BOT-X306
BOT306RF-WIFI
√ √
√
√
√
√
√
√
√
√
√
