ZUMEX Speed Up Citric Active Quick Start Manual page 4

Instructions for cleaning the components
Automatic PulpOut System
1
Rest the PulpOut system on a flat surface
and disassemble the side cover, holding it
from above to remove the ends of the gui-
des.
4
Remove the sweeping belt together with
the other roller and remove both parts.
Squeezing system
1
Remove the pressing units.
Zumex Group S.A. Tel. +34 961 301 251. zumex@zumex.com. Zumex Service Tel: +34 960 800 999.
2
Remove the black upper lid by pushing
upwards on the tabs sticking out.
5
Clean the conveyor belt and the rest of the
components of the Pulp Out with the clea-
ning steps indicated.
2
Clean all the parts following the steps
shown. All the parts can also be washed in
a dish- washer.
3
Turn the assembly around and place your
fingers on the sweeping belt by pushing it
outwards to release it.
6
All the parts can also be washed in a dish-
washer.
