Installation Instructions
Horizontal Ducting Preparation
18
4. Place top rectangular cover plate
over opening on top of the liner.
NOTE: Make sure the cover plate
tabs are on top of the cover plate
as shown. From inside the liner,
secure plate to top of liner with
(2) 3/16 x 3/8 screws.
At this point, install the liner into
the cabinet by following the
steps on page 14, step 4. After
liner installation, continue on
page 18.
5. From inside the liner, push 8"
round adapter through the back
knock-out and secure to interior
back wall of liner with (4) M4 x
6mm screws.
6. Secure (2) horizontal ducting
blower brackets to blower as
shown above by using the (4)
3/16" x 3/8" screws previously
removed from Page 17, Step 2; (2)
screws for each bracket.
