Workflow of IP8101 Positioner Setup

The workflow of IP8101 smart positioner from setup to initial adjustment is shown below. Follow this
flow when performing setups and adjustments of the positioner.
Start setup
Check
specifications
Select the
bracket shape
Mount a fork
lever-type fitting
Mount the
positioner
Piping
Electrical Wiring
Check each
part's description
Check the contents on
the LCD display
Initial adjustment
Start operation
Check the specification and ensure the positioner is
suitable for the connected actuator and application.
With reference to "■Example of Mounting on
Actuator", select the bracket suitable for the
application.
With reference to "■Connection with Feedback
Shaft", mount a fork lever-type fitting on the
actuator.
Connect the positioner to the actuator with the fork
lever-type fitting.
With reference to "■Piping Layout", select the
piping method suitable for the application.
<Perform initial adjustment in the following order along with this manual>
1. Select calibration
mode
2. Set the angle of the
fork lever-type fitting
3. Simple balance
current adjustment
4. Calibration
5. Calibration of input
current
Fig.2
8
Select the mode used for initial
adjustment.
Set the angle of the fork lever-type
fitting as shown in "■Mounting".
Adjust balance current simply.
Perform zero point/span adjustment
and PID constant settings suitable for
the connected actuator.
Perform calibration of the input
current as necessary. Normally, this
is not required.
