Assa Abloy NORTON RIXSON 7540STH Installation Manual

7540STH Low Profile
Slide Track Door Closer
Pull Side
Push Side
With or without DA suffix (delayed action)
With or without M suffix (metal cover)
WARNING
This product can expose you to lead which is known to the state of
California to cause cancer and birth defects or other reproductive harm.
For more information go to www.P65warnings.ca.gov.
Left Hand Door - LH
Right Hand Reverse - RHR
Right Hand Door - RH
Left Hand Reverse - LHR
Included Components (See page 2 or 3 for mounting hardware)
TO DETERMINE
HAND OF
To Determine Your Hand of Door:
YOUR DOOR:
Right Hand
Reverse
LEFT
HAND
DOOR
Copyright © 1997, 2014, 2022, ASSA ABLOY Accessories and Door Controls Group, Inc. All rights reserved. Reproduction in whole
or in part without the express written permission of ASSA ABLOY Accessories and Door Controls Group, Inc. is prohibited.
80-9377-0561-020 Rev 3 03/22
9/64"
Hex Drive
Socket Head
Screw
Closer
Arm Assembly
To Identify Your Model:
Older models may
be stamped "1-6",
"1-4" or "2-6". They
Left Hand
can be replaced
Reverse
with a newer "1-6"
model which has
RIGHT
no stamp.
HAND
DOOR
Standard 7500ST = 4 valves
Delayed Action 7500STDA = 5 valves
Hold Open Arm Models
7540STH
PS7540STH
Ce produit peut vous exposer au plomb qui, dans l'état de la Californie,
est reconnu pour causer le cancer, des anomalies congénitales ou d'autres
problèmes de reproduction. Pour plus d'informations, visitez:
www.P65warnings.ca.gov.
Pull Side
Push Side
Stop (Push) Side
Hinge (Pull) Side
Slide Track
Slide Track
Tools Needed
Right Hand Door - RH
Left Hand Reverse - LHR
Right Hand Reverse - RHR
Optional Components
2 Cover
Screws
7786JP Drop Plate
Cover
with Insert
NORTON
RIXSON
Left Hand Door - LH
