Omcan BE-IT-0406 Instruction Manual page 14

Parts Breakdown
Model BE-IT-0406
Item No. Description
78833 Inox Plate for 13177
78834 Grey Plastic Box for 13177
78835 Plastic Feet for 13177
78836 Lower Steel Slide for 13177
78837 Upper Steel Slide for 13177
78838 Lifting Beam Assy for 13177
78839 Counter Weight Scale for 13177
78840 Counter Weight Pin for 13177
78841 Scale Shaft for 13177
78842 Back Scraper for 13177
78843 Front Scraper for 13177
78844 Lower Eccentric Shaft for 13177
78845 Lower Cylindrical Shaft for 13177
78846 Lower Cylindrical Roller for 13177
78847 Steel Rod for 13177
17674 Lower Roller for 13177
78848 Lower Reduction Gear Support for 13177
78849 Cylindrical Screw for 13177
14572 Spacer for 13177
14571 Spacer for 13177
13177
Position Item No. Description
1 78850 6202 ZZ Bearing for 13177
2 14570 Plug for 13177
3 14576 Plug for 13177
4 14575 Bearing 6200 2Z for 13177
5 14567 Gear, comes with Elastic Ring for 13177
6 14573 Ring for 13177
7 78851 O-Ring for 13177
8 78853 Upper Eccentric Shaft for 13177
9 78854 Upper Cylindrical Shaft for 13177
10 14569 Handle for 13177
11 78855 Upper Eccentric Roller for 13177
12 78856 Upper Cylindrical Roller for 13177
13 78857 Upper Guard for 13177
14 78858 Lower Guard for 13177
15 44841 Plastic Cover for 13177
16 78860 Spacers Lower Slide for 13177
17 78861 Control Unit Label for 13177
18 40160 Circuit Board 12V 110/60Hz for 13177
19 78863 Cable Fastener for 13177
20 78864 Pedal Accessory for 13177
Position Item No.
21 78865
22 78866
23 78867
24 78868
25, 26 78869
27 18683
28 78870
30 18684
31 78871
32 30424
33 14574
34 78872
35 78873
36 78874
37 78875
39 78876
40 78877
41 78878
42 78879
43 78880
14
Description Position
Control Panel Accessory for 13177 44
Pedal for 13177 45
Motor for 13177 46
Motor Support Screws for 13177 47
Reduction Pulley for 13177 48
Pulley for 13177 49
Upper Small Support for 13177 50
Belt 8x920 for 13177 51
Feet for 13177 52
Springs for 13177 53
Belt 8 x 784 for 13177 54
Lower Reduction Gear Support for
58
13177
Spacer for 13177 59
Scale Unit for 13177 60
Stainless Steel Pin for 13177 61
Scale Shaft for 13177 62
Counter Weight Scale for 13177 63
Counter Weight Accessory for 13177 64
Counter Weight Accessory for 13177 65
Counter Weight Accessory for 13177 66
