Trina Solar 210 Vertex Series User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 210 Vertex Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Trina Solar 210 Vertex Series

Summary of Contents for Trina Solar 210 Vertex Series

  • Page 2 DE19 DE20 DE21 DEG18MC.20(II) DEG19C.20 Bifacial products DEG20C.20 DEG21C.20 Contents of this document are subject to change without notice. For the latest document please refer to Trina Solar official website: www.trinasolar.com. UM-M-0002/Ver.B Copyright © June, 2021. Trina Solar Co., LtD.

  • Page 3: Table Of Contents

    Table of Contents INTRODUCTION ........................1 SAFETY PRECAUTIONS ....................... 1 SITE SELECTION AND ANGLE ...................... 3 UNLOAD/TRANSPORTATION/STORAGE ..................4 UNPACKING INTRODUCTION ..................... 7 UNPACKING SAFETY ..........................7 UNPACKING STEPS ..........................9 INSTALLATION ........................11 INSTALLATION SAFETY ........................11 INSTALLATION METHOD ........................13 6.2.1 SCREW INSTALLATION ..........................

  • Page 4: Introduction

    The installer must inform the end customers (or consumers) of the above matters accordingly. The term "Module" or "PV Module" in this manual refers to one or more 210 Vertex series solar modules. Please retain this manual for future reference.
  • Page 5 Do not stand, sit, walk, or jump directly on the module package or the module itself. The PV module does not contain any serviceable parts. Do not disassemble or move any part of the module. Do not damage or scratch the front- or backside surfaces of the module, as scratches may directly affect the product safety.

  • Page 6: Site Selection And Angle

    The tilt angle of the PV module refers to the angle between the module and the horizontal ground. The tilt angle shall be selected according to the local conditions for different projects. Trina Solar recommends that the mounting tilt angle should not be less than 10° . For specific tilt angles, it shall be chosen in accordance with the local design procedures, specifications and regulations, or following the recommendations of the experienced PV module installers.

  • Page 7: Unload/Transportation/Storage

    Upon arrival of the modules, please check the packaging box is in good condition, and check whether the module type and quantity on the outer packaging are consistent with the delivery order, if anything is wrong, please contact Trina Solar logistics and sales staff immediately. 1. Unloading with a crane When crane is used to unload the modules, please choose and use specialized tooling according to the weight and size of the module.
  • Page 8 Trina Solar User Manual | Vertex Series Modules Please drive slowly and do not allow forks to hit the cartons or pallets. It is recommended to operate the forklift from the short side of the pallet and not touch the glass side. If the operation must be carried out on the glass side, please place buffer protection material (in yellow) in advance to prevent the inside modules being damaged due to the external force.
  • Page 9 SECONDARY TRANSPORTATION The packaged modules can be transported by land, sea or air. During transportation, make sure that the package is fixed with packing belts securely on the shipping platform without any movement. If the unpacked modules need to be transported to other places, it is recommended to pack the single module together in a package to the maximum number allowed, and fixed with inner packing belts (2100N force recommended).

  • Page 10: Unpacking Introduction

    Stacks of modules should contain no more than 16 modules, and the frames should be aligned. For matters regarding the unpacking stand supporter, please contact Trina Solar sales.
  • Page 11 In windy weather, it is recommended not to carry the modules, and the unpacked modules should be properly secured. Do not unpack the modules outside under rain and snow conditions. Do not carry the module by one person to prevent the module from slipping and hitting other modules, causing scratches, cracks, or deformation on the modules.

  • Page 12: Unpacking Steps

    Trina Solar User Manual | Vertex Series Modules 5.2 UNPACKING STEPS Method A: Unpacking from one side for DE18M(II) / DE18M.08(II) / DEG18MC.20(II) / DE19 / DEG19C.20 series modules with vertical landscape package. 3) Prepare for unpacking (do 1) Place the carton box on a flat 2) Remove the attached plywood.
  • Page 13 Method C: For DE20 / DE21 / DEG21C.20 series modules with vertical portrait package. 1) Remove the wrapping 3) Remove the carton box. 2) Remove the top cover film and packing belts. and sealing tape. 6) When there are 1-2 vertical 5) Cut off all the horizontal 4) Place the stand supporter packing belts remaining, push the...

  • Page 14: Installation

    The fire rating of Trina Solar modules complies with relevant standards or local laws and regulations. Before installation, please carefully check the modules for abnormalities such as glass bursts, cell cracks, backsheet scratches, deformation of installation holes, broken junction boxes or missing covers, nameplates falling off or missing, and broken cables or connectors, etc.
  • Page 15 blocking the solar cells on the back of the module. The open area should minimize arc coil, which can reduce the risk of induced lightning impact on PV module. Do not install modules under rain, snow or windy conditions. If installing or operate modules after rain or in the morning dew, appropriate protective measures need to be taken to prevent water vapor from penetrating into the connector.

  • Page 16: Installation Method

    If in such case that an alternative mounting method is used but not approved by Trina Solar, the module may get damaged and the warranty will be invalidated. The mechanical loads described in this manual are the test loads. For calculating the equivalent maximum design loads, a safety factor of 1.5 needs to be considered in compliance with the...

  • Page 17: Clamp Installation

    6.2.2 CLAMP INSTALLATION Trina Solar has tested its modules with a number of clamps from different manufacturers, it is recommended to use fixing bolt of at least M8. The clamp should have length of ≥50 mm (1.97 inch) with thickness of ≥3 mm (0.12 inch). The clamp shall not be malfunctioned due to deformation or corrosion during the loading process.
  • Page 18 Trina Solar User Manual | Vertex Series Modules The installation method of clamps is shown in Figure 2. End clamp installation Middle clamp installation. Figure 2. PV module installed with clamp fitting method. Clamp positions are of crucial importance for the reliability of the installation. The clamp centerlines must only be positioned within the ranges indicated in table below, depending on the configurations and loads.
  • Page 19 The following installation methods and mechanical loads have been verified by the Trina Solar’s National Key Laboratory for PV Science and Technology. Module type Maximum loads Module type Maximum loads Use 4 clamps on the short side. Use 4 clamps on the short side.
  • Page 20 Trina Solar User Manual | Vertex Series Modules Use 2 clamps on the short side and 2 clamps on the long Use 4 clamps on the short side and 2 clamps on the long side. side. Mounting rails run perpendicular to the long side frame.

  • Page 21: Single-Axis Installation

    1.5 mm (0.06 inch) thickness with an outer diameter of 16-20 mm (0.63-0.79 inch), except for DEG19C.20 using an outer diameter of 16-18 mm (0.63-0.71 inch). Trina Solar modules can be used with trackers produced by different manufacturers, please check Appendix A for details.

  • Page 22: Grounding

    Do not drill any extra ground holes for convenience, this will void the modules warranty. Trina Solar does not provide grounding devices or materials. Any third-party grounding device that meets the requirements of the installation electrical equipment specifications can be used for grounding of Trina Solar’s modules.

  • Page 23: Electrical Installation

    (12 AWG). All other cables applied to connect the DC system should be provided with a similar or larger wire cross section. Trina Solar recommends that all cables are routed in appropriate conduits or rails where water does not accumulate.

  • Page 24: Wiring

    The number of modules in series and in parallel shall be designed reasonably according to the system configuration. All the above instructions must be followed to meet Trina Solar's warranty conditions. Figure 5: Series and parallel connection circuit diagram. Trina Solar recommends the following two wiring methods for portrait and landscape installations with short and long cable lengths, respectively.

  • Page 25: Fusing

    FUSING The correction factor of a fuse shall be determined by an authorized professional electrical engineer in accordance with the relevant design regulations and system simulation results. Trina Solar does not responsible for determining the minimum rating of fuse. The fuse rated current should be chosen depending on different standards, as follows ⋅...

  • Page 26: Pv Module Maintenance

    Please cover the front surface of modules with an opaque material during repairing. Modules exposed to sunlight can generate high voltage, which is extremely dangerous. Trina Solar PV modules are equipped with bypass diodes in the junction box to minimize module heating and current losses.

  • Page 27: Cleaning

    7.3 CLEANING This manual covers the requirements for the cleaning procedures of Trina Solar PV modules. Professional installers should read these guidelines carefully and strictly follow these instructions. Failure to follow these instructions may result in death, injury, or property damage. Damages induced by inappropriate cleaning procedures will void Trina Solar warranty.
  • Page 28 The maximum water pressure recommended is 4 MPa (40 bar) Method B: Compressed Air Trina Solar recommends using this method to clean the soft dirt (like dust) on modules. This technique can be applied as long as the method is efficient enough to clean the modules considering the on-site conditions.

  • Page 29: Reporting Technical Issues And Claims

    REPORTING TECHNICAL ISSUES AND CLAIMS Contact your installer.  Contact Trina Solar after sales service team at http://customerservice.trinasolar.com/.  Submit the Customer Feedback Form at: http://customerservice.trinasolar.com/ and one of our  technical service representatives will contact you within 5 business days. A username and password is required to send feedback from the customer service link.
  • Page 30 Trina Solar User Manual | Vertex Series Modules APPENDIX A: TRACKERS COMPATIBILITY The following tracker manufacturers and types are approved with Trina Solar modules. Module type Tracker Company Tracker type Maximum Load Vanguard™ Uplift load ≤ 1800 Pa DEG19C.20 Trina Solar Co., Ltd.

This manual is also suitable for:

De09De09.05De09.08De18mDe18miiDe18m.08 ... Show all
