SPECIFICATION

Power source
Overall dimension(Net dimension)
Net weight
Power consumption
Motor output
Marked capacity of washing/spinning
Washing method
Water capacity
Water consumption
Spinner tub speed
Specification: Subject to change without notice.

ABNORMAL CONDITION

When the washer is abnormal, the washer stops as the every actions turns off, beep tone
sounds ON-0.1 second and OFF-0.1 second for 6 seconds and number window LED display
abnormal code. The washer judges the following six conditions as abnormal condition.
1) Abnormal condition of water supply
In supplying with water, the water level does not reach extra low level within 10 minutes or
does not reach your chosen water level within 20 minutes.
The number window LED display abnormal code:
indicate a problem at the same time.
2) Abnormal condition of drain
In draining, the water level does not go down below the reset level of the water level sensor
within 8 minutes.
The number window LED display abnormal code:
indicate a problem at the same time.
3) Abnormal condition of spin-dry
• The safety switch works 3 times continuously during the program of rinse-spin or works 1
time in the single program of spin-dry.
The number window LED display abnormal code:
indicate a problem at the same time.
• The washer lid is opened.
The number window LED display abnormal code:
indicate a problem at the same time.
AC 220~240V, 50/60Hz
601 (W) × 632(D) × 999(H)
52kg
1600W
140W
12kg
Automatic reverse turn
99 Liters
162 Liters (Regular wash cycle
Water level: High)
650 rpm
and the electric buzzer sounds to
and the electric buzzer sounds to
and the electric buzzer sounds to
and the electric buzzer sounds to
