Summary of Contents for Whirlpool WVMD1208AHG
- Page 1 SERVICE MANUAL Automatic Washer WVMD1208AHG (Singapore) WVMD1208BHG (Philippine)
-
Page 2: Specification
SPECIFICATION Power source AC 220~240V, 50/60Hz Overall dimension(Net dimension) 601 (W) × 632(D) × 999(H) Net weight 52kg Power consumption 1600W Motor output 140W Marked capacity of washing/spinning 12kg Washing method Automatic reverse turn Water capacity 99 Liters Water consumption 162 Liters (Regular wash cycle Water level: High) Spinner tub speed... -
Page 3: Circuit Diagram
4) Abnormal condition of child lock. Running in setting child lock, the washer lid is opened beyond 4 seconds. The number window LED display abnormal code: and the electric buzzer sounds to indicate a problem at the same time. 5) Abnormal condition of water level sensor. The water level sensor malfunctions or the water level is overrunning the alert level when the water does not stop. -
Page 4: Water Supply
Poor connect of 6-pin Repair or replace. connectors (blue&white). Control circuit board is Replace. defective TROUBLE INSPECTION INSPECTION CAUSES REMEDY b. Water Supply Water does not Does humming Something on the filter of flow when the noise come on the water valve or hose Clean the filter. - Page 5 Note: When removing the flow sheet, reinstate the filter in place correctly. Does water stop Something in the air trap Water does not stop when the plug Clean or replace. hose or air leaks from a part related water level is removed or sensor system.
- Page 6 ’ Brake lining is worn out. Replace bearing ass ’ ’ Brake lever ass y is defective. Replace bearing ass d. Drain Water does not Foreign matter in drain hose. Clean drain hose drain out. inside. Pump lead wire is Repair or replace.
- Page 7 Note: 1. The safety switch works 3 times continuously or works 1 time in the single program spin-dry number window LED display abnormal code: and begin blinking on and off at the same time and the electric buzzer sounds to indicate a problem. 2.
- Page 8 stop Spin-Dry cycle and operates water supply valve to pour water into the Wash/Spin Tub and then starts washing cycle for replacing washing clothes evenly. After above operation has down twice, if safety device works again, machine will stop, and the number window LED display abnormal code: and begin blinking on and off at the same time and the electric buzzer sounds to indicate a problem.
- Page 9 PART LIST ’ 中文名称 Key No. Part No. Description 301B14A001548 后板组件 A Rear plate assembly A L-shaped pin 301B15A001563 L 型轴销 301B31A001567 投入口盖 Casting cover Rear panel cover finish 301B14A001558 后板罩光完成 301B14A005158 洗涤上盖组件 A Washer Lid A Complete Seal A 301B41A001568 密封圈...
- Page 10 ST1TN40120SE- 螺钉 Screw Door lock 301B80A001594 门锁 ST1TN40120SE- 螺丝 Screw 301B14A001562 线束挡板 Harness bezel ST1TN40120SE- 螺丝 Screw 301B22A001521 波轮盖 Pulsator Cover 3012411301140 波轮螺钉 Pulsator Screw 3012411401140 波轮螺钉衬垫 Pulsator Screw Washer 301B22A001513 波轮组件 Pulsator 3012411501140 波轮垫片 Pulsator Washer 301B22A001503 平衡环组件 Balance Weight Assembly ST1TN50210UK- 螺钉...
- Page 11 Clutch component 301B421000014 离合器部件 3012912208140 特种螺钉 Special Screw 3012912209140 特种螺钉 Special Screw Ultrasonic pump Assy 3010350310040 超音波泵完成 3012912213140 特种螺钉 Special Screw 3012152509140 卡箍 Clamp 301B32A001498 排水阀组件 Drain valve Assembly ST1TN40140SE- 螺钉 Screw 3012912203140 特种螺钉 Special Screw 3014264S18140 扭矩电机 Torque Motor 3012912207140 特种螺钉...
- Page 12 3012143462140 缓冲垫 Cushion ST2TN60200SE- 螺钉 SCR 6×20 ST1TN40120SE- 螺钉 SCR 4×12 3010143002140 可调脚组件 Adjuster Assembly PE protective film 301B411600001 PE 防护膜 70C01224 DDM DC inverter driver board is completed DDM 直流变频驱动板完成 ST1TN50210UK- 螺钉 SCR 5×21 Drive board cover 301B141700014 驱动板盒盖 STAPN30100SE- 螺钉...
-
Page 13: Exploded View
ExplodedView...
