OPTION 4: ATTACHED TO HOPPER LEGS
2 x left-hand side inner
fastening plate
14
8 x thick plastic ring
17
12 x socket head bolt
M10x45
20
PROTECTIVE COVER
1 x protective cover
13
2 x right-hand side inner
fastening plate
15
16 x thin plastic ring
18
12 x spring washer
M10
21
4 x outer fastening plate
16
4 x stainless steel tube ø14x2x30
19
