Extremis Sensu Assembly Instructions, How To Use, Useful Tips For Keeping Your Tool For Togetherness In Shape

Single square straight/tilted
Hide thumbs Also See for Sensu:

Advertisement

Quick Links

Download this manual
Sensu
Single square straight
Single square tilted
Assembly instructions, how to use, useful tips for keeping
MANUAL
your tool for togetherness in shape.
LAB162-2
EN

Advertisement

loading
Need help?

Need help?

Do you have a question about the Sensu and is the answer not in the manual?

Questions and answers

Related Manuals for Extremis Sensu

Summary of Contents for Extremis Sensu

  • Page 1 Sensu Single square straight Single square tilted Assembly instructions, how to use, useful tips for keeping MANUAL your tool for togetherness in shape. LAB162-2...
  • Page 2 Tools for togetherness © All our designs are original creations and protected by intellectual property rights.
  • Page 3 IMPORTANT! RETAIN FOR FUTURE REFERENCE: READ CAREFULLY. BELANGRIJK! LEES DIT DOCUMENT AANDACHTIG EN BEWAAR HET VOOR TOEKOMSTIGE RAADPLEGING! WICHTIG! AUFHEBEN, UM SPÄTER ETWAS NACHSEHEN ZU KÖNNEN: SORGFÄLTIG DURCHLESEN! IMPORTANT! LISEZ ATTENTIVEMENT CE MANUEL ET CONSERVEZ-LE POUR RÉFÉRENCE ULTÉRIEURE! IMPORTANTE! CONSERVARE COME RIFERIMENTO PER IL FUTURO: LEGGERE ATTENTAMENTE! ¡IMPORTANTE! CONSÉRVELO PARA...
  • Page 4 Do not use power tools!

  • Page 7: Table Of Contents

    Table of contents Mounting kit Assembly wheel base Moving up/down Open / close Rotate 360° Tilting vertically Assembly permanent fixation Assembly floor fastening spacer plate Warnings – Assembly text instructions – Maintenance...
  • Page 8 Mounting kit 4 x wheel 16 x M6x12 iso 7380 4 x plate Mounting kit to fix wheels to the wheel base...
  • Page 9 4 x plates 4 x M10x25 Mounting kit to fix rotating system...
  • Page 10 Assembly with wheel base N° 4 - 6 15’ p 40 16 x M6x12 4 x plate 4 x wheel The rotating system is inside the box of the parasol 4 x plates 4 x M10x25...
  • Page 11 Do not use the wheel base without any weight! Add at least 200 kg!
  • Page 12 Take the included parasol support out of the pole...
  • Page 13 Tilted Straight 4 x M10x16...
  • Page 14 8. Straight 2° Make sure shade is tilted backwards...
  • Page 15 8. Tilted 10° Make sure shade is tilted forward...
  • Page 17 Tighten the two adjusting screws on the back...

  • Page 18: Moving Up/Down

    Moving up / down Use the handle to move the shade up / down...
  • Page 19 Move all the way up + fix the handle...

  • Page 20: Open / Close

    Open / Close...
  • Page 21 Put the Sensu in a tilted position for water drainage & wind advantage We strongly advise you to close the shade at wind speed 28 km/h (18 mph)

  • Page 22: Rotate 360

    Rotate 360° Unlock position Turn the rotating pin 180° to unlock the pole : take corner of the fabric to turn easily...
  • Page 23 Lock position When in desired position, lock the rotating pin by turning it back 180° Rotate the parasol a bit untill you here it “lock”...

  • Page 24: Tilting Vertically

    Tilting vertically Use the handle to tilt the shade up and down...
  • Page 25 Fix handle in the desired position...

  • Page 26: Assembly Permanent Fixation

    Assembly with permanent fixation N° 6 45’ p 41 Use tape to close the bottom side of the tube...
  • Page 27 40 cm...
  • Page 28 GRASS GRAVEL TILES GRASS GRAVEL TILES 10 cm / 4” 4 cm / 1 ” 10 cm 4 cm...
  • Page 29 Cover 4 x M10x16...
  • Page 30 Take the included parasol support out of the pole...
  • Page 31 4 x M10x16 Add the pole extension...
  • Page 32 11. Straight 2° Make sure shade is tilted backwards...
  • Page 33 11. Tilted 10° Make sure shade is tilted forward...
  • Page 35 Tighten the two adjusting screws on the back...
  • Page 36 Assembly with floor fastening 30’ p 41 Use the spacer to mark the holes Use suitable bolts or screws from a specialized store depending on the material your terrace is made of...
  • Page 37 4 x M10x16...
  • Page 38 4. Straight 2° Make sure shade is tilted backwards...
  • Page 39 4. Tilted 10° Make sure shade is tilted forward...

  • Page 40: Warnings - Assembly Text Instructions - Maintenance

    5° à 10° angle. the pole. • Fix the closed Sensu with the supplied strap. Moving up / down - p18 Powder coating 1. Use the handle to move the shade up / down.
  • Page 41 3. Take the included parasol support out of the with the hook. pole and position the parasol support on top of 3. Put the Sensu in a tilted position for water the rotating system. Make sure that the cutout is drainage & wind advantage.
  • Page 44 All rights reserved. Unless otherwise specified, all designs and photographs contained in this publication are copyright protected and are the property of Extremis. No part of this publication may be copied or distributed without Extremis’ prior written consent. The names of the authors of photographs to which we do not hold rights are mentioned here. We have done our utmost to provide a...
