Technical Characteristics; Ul Approval - Meech Hyperion 929IPS Operating Manual

Technical and Construction
Dimensions (W x H)
Maximum Length
Operating Range
Weight
Construction
Mounting
Emitters
Input Current
Input Voltage
Output Voltage
Electrical Connection
Clean Pin Output Signal
Output Frequency
Output Balance
Environmental Protection
Max Ambient Temperature

UL Approval

Static elimination bar Hyperion 929IPS has been investigated by UL in accordance
with the following standard(s): UL 60950-1 & CAN/CSA C22.2 No. 60950-1-07.
26mm x 43mm
2965mm
50mm – 500mm
0.9kg/metre
PVC/ ABS FR.
STATIC ELIMINATION BAR
'T' Slot with M4 x 20 studs
Sharp titanium pins
Max 500mA
24V DC (21-27VDC)
+/- 10kV Pulsed DC
4 Pole M8
24V Output resistance 10kΩ
Default Setting: 5Hz
Adjustable with BarMaster from 1Hz to 20Hz;
Default Setting: 52%:48% Pos:Neg
STATIC ELIMINATION BAR
Adjustable with BarMaster from 80:20 to 20:80 Pos:Neg
IP66
60 °C
STATIC ELIMINATION BAR
operating manual
operating manual
operating manual
19
