3D WHEEL ALIGNER
GEO 15
SERVICE MANUAL
UK

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GEO 15 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Cormach GEO 15

Summary of Contents for Cormach GEO 15

  • Page 1 3D WHEEL ALIGNER GEO 15 SERVICE MANUAL...

  • Page 3: Table Of Contents

    IR-LED board replacing procedure ........................85 Target Quality Check ............................87 Target replacing ............................... 89 SOFTWARE IMPROVEMENTS ........................... 91 jOB RECORDS SAVING ............................. 92 Setting for a correct graphic print........................93 TROUBLESHOOTING ............................96 GEO 15 Service Manual - Rel. 02 06-2016...

  • Page 4: Installation Place

    Installation place Note: the dimension 700 could be reduced to 300 mm. GEO 15 Service Manual - Rel. 02 06-2016...

  • Page 5: Electrical Connections

    Electrical connections Refer the following picture to connect all electrical parts. GEO 15 Service Manual - Rel. 02 06-2016...
  • Page 6 POW: This is the power cable to source the Led Boards. It must be connected to the power source (PS). CM: Automatic Camera Movement Control. POW CABLE wire PS OUTPUT BLUE +12V (+V2) BROWN GEO 15 Service Manual - Rel. 02 06-2016...

  • Page 7: Computer Basic Requirement

    Example of commercial PC: HP PRODESK 490 G2 Intel® Pentium G3240 Processor Up to 3.1 GHz Base Frequency 3 MB cache 2 cores 2 threads Intel HD Graphics Supports DDR3 memory up to 1600 MT/s data rate GEO 15 Service Manual - Rel. 02 06-2016...

  • Page 8: Windows 7 Configuration Setting The Right Screen Resolution

    WINDOWS 7 CONFIGURATION Setting the right screen resolution: Open the Control Panel select Display. Select Adjust resolution. Select Advanced settings. Select List All Modes. GEO 15 Service Manual - Rel. 02 06-2016...
  • Page 9 Select 800x600, True Color (32 bit), 60 Hertz. Click OK here and Apply in the following window. Click on Yes in this window. GEO 15 Service Manual - Rel. 02 06-2016...

  • Page 10: Windows 10 Configuration Power Setting

    Select System. Select Power & Sleep. Set Never in both selection boxes.  Turn off the display NEVER  Put the computer to sleep NEVER Select Additional power settings. Select Change plan settings. GEO 15 Service Manual - Rel. 02 06-2016...
  • Page 11 Set to Disabled the following item: USB Settings  USB selective suspend setting Click OK Close the configuration window. AUTOMATIC UPDATES SETTINGS: Open the Settings page. Select Update & Security. Select Windows Update. Select Advanced options. GEO 15 Service Manual - Rel. 02 06-2016...
  • Page 12 Deselect “Defer upgrades”. Select “Choose how updates are delivered”. Set to OFF the sliding selector. Return to Settings page. Select Windows Defender. Disable Real-time protection. Return to Settings page and close it. GEO 15 Service Manual - Rel. 02 06-2016...
  • Page 13 NOTIFICATION and WEB BROWSER SETTINGS: Open the Settings page. Select System. Select Notifications & actions. Turn OFF the 5 sliding selectors. Select Default apps. Switch the actual Web browser from Edge to Internet Explorer. GEO 15 Service Manual - Rel. 02 06-2016...
  • Page 14 Left click on Cortana search bar. Click on Cortana’s settings icon Turn OFF the 3 sliding controls. STANDARD DISPLAY RESOLUTION SETTINGS: Right click on the Desktop. Select Display Settings. Select Advanced display settings. GEO 15 Service Manual - Rel. 02 06-2016...
  • Page 15 To be executed if the STANDARD DISPLAY RESOLUTION SETTINGS procedure does not allow to set the resolution to 800x600. Right click on the Intel Graphics Control Panel icon near the clock. Select Graphics Properties… Select Display. GEO 15 Service Manual - Rel. 02 06-2016...
  • Page 16 Select Yes. Manually set: WIDTH: 800 HEIGHT: 600 REFRESH RATE: 60 Click on the Add icon on the bottom right of the window. Select Yes Right click on the Desktop. Select Display Settings. GEO 15 Service Manual - Rel. 02 06-2016...
  • Page 17 Select Advanced display settings. Select 800 x 600. Select Apply. Select Keep changes. GEO 15 Service Manual - Rel. 02 06-2016...
  • Page 18 800x600 it is also possible to set the aligner software to full screen. Right click on the Desktop. Select Display Settings. Select Advanced display settings. Select 1024x768. Select Apply. GEO 15 Service Manual - Rel. 02 06-2016...
  • Page 19 Select Keep changes. Set the ZOOM to 125%. Select Apply. Right click on the Desktop. Select Personalize. Select Background Background: Solid Color Select the BLACK COLOR Close the window. GEO 15 Service Manual - Rel. 02 06-2016...
  • Page 20 TASKBAR SETTINGS: FOR ALL DISPLAY BOARDS: Right click on the Task bar. Select Properties. Set: Lock the taskbar Auto-hide the taskbar Click OK. GEO 15 Service Manual - Rel. 02 06-2016...

  • Page 21: Software Installation

    Switch ON the PC and insert the SOFTWARE CD- ROM inside the CD-ROM drive. The installation process should automatically start. If not, please open CD-ROM folder and run SETUP.EXE. Follow the on screen instructions to perform the first installation. GEO 15 Service Manual - Rel. 02 06-2016...
  • Page 22 PC. Select the “RECOVERY” procedure when asked. DO NOT REMOVE THE .NET FRAMEWORK. WINDOWS 10: Not required to be installed. Go ahead in alignment software installation without installing the Microsoft .NET Framework. GEO 15 Service Manual - Rel. 02 06-2016...
  • Page 23 Click OK. Installation in progress. Please wait… At the end, the PC will be restarted… After restart, the aligner will start. There are some error messages due to the missing of configuration files. GEO 15 Service Manual - Rel. 02 06-2016...
  • Page 24 Now it is necessary to exit to Windows. Select to exit to Windows. Enter the password “end” in lowercase. Click on "F3" icon to exit. Remove the SOFTWARE CD-ROM from the drive and re-place it inside its envelope. GEO 15 Service Manual - Rel. 02 06-2016...
  • Page 25 OVERWRITING THE EXISTING FILES). NOTE: Inside the Alignment folder must be present only one WORKINGDIR folder containing calibration files. After installing Wheel Alignment software it is suggested to perform the Beam Alignment. GEO 15 Service Manual - Rel. 02 06-2016...

  • Page 26: Driver Installation Check

    CAMERA DRIVERS INSTALLATION. To be installed if missing “Tucsen ISH130BW Camera” driver. For 32 bit PC: Open this folder: C:\Program Files\Alignment\Driver\Camera Run the Tucsen_x32.exe installer. Follow the displayed instructions. For 64 bit PC: Open this folder: C:\Program Files (x86)\Alignment\Driver\Camera GEO 15 Service Manual - Rel. 02 06-2016...
  • Page 27 Open this folder: C:\Program Files (x86)\Alignment\Driver\Softdog Run the SoftDogInstdrv.exe installer. Click on INSTALL DRIVER. Click on EXIT when installation is complete. Open the "Device Manager" to check if all the drivers are correctly installed. GEO 15 Service Manual - Rel. 02 06-2016...

  • Page 28: Alignment Position And Distances

    If the customer has a 4 column lift, the distance between the lift and the aligner must be from 1800 to 2800 mm. The distance between the column must be 2900 mm. GEO 15 Service Manual - Rel. 02 06-2016...

  • Page 29: Camera Check

    Press OK on both message boxes. This warning inform you that System and Target calibration are already done, but Calibration Check is still not performed. Press OK to continue. Select ”EXPERT MODE”. GEO 15 Service Manual - Rel. 02 06-2016...
  • Page 30 THIS PROCEDURE IS TO BE USED ONLY WHEN THE CAMERA SETTINGS ARE INCORRECT. Select Swap SX DX camera from the Camera Settings menu. Click on Swap button. Click on OK button to close the window. GEO 15 Service Manual - Rel. 02 02-2016...

  • Page 31: Beam Alignment

    Set the screen resolution at 1920 x 1080. Run ServiceWindows.exe placed on desktop. Click on the SERVICE icon. The password is “1234”. The software will display informations about the 2 cameras connected to the Press OK on both message boxes. GEO 15 Service Manual - Rel. 02 02-2016...
  • Page 32 Align the beam in order to reach this situation: You have to obtain the same A and B distance from the left and right side. Besides maximum 1 target of vertical offset is admitted. GEO 15 Service Manual - Rel. 02 06-2016...
  • Page 33 Solution: Align better the beam. EXAMPLE OF BAD ALIGNMENT OF THE BEAM: Vertical offset out of range. Solution: Align better the beam. At the end, set again the screen resolution at 800 x 600. GEO 15 Service Manual - Rel. 02 06-2016...

  • Page 34: Calibration Bar Mounting

    10 – Target disk shim 11 – Shim 12 – Spring gasket 13 – Nut 14 – M6 stainless steel sockets screw 15 – M8 stainless steel sockets screw 16 – Transfer axle GEO 15 Service Manual - Rel. 02 06-2016...

  • Page 35: Calibration Check

    Press OK on both message boxes. This warning inform you that System and Target calibration are already done, but Calibration Check is still not performed. Press OK to continue. Select "CALIBRATION CHECK”. GEO 15 Service Manual - Rel. 02 06-2016...
  • Page 36 Place BAR on LEFT SIDE of the hoist. Press START. Wait for the following response. Move the BAR in another position. GEO 15 Service Manual - Rel. 02 06-2016...
  • Page 37 If the answer is Bad Calibration the problem could be or the camera or the calibration bar is not stable. For more information see the troubleshooting page. Press NO. Place BAR on the right side. GEO 15 Service Manual - Rel. 02 06-2016...
  • Page 38 Press START. Wait for the following response. Move the BAR in another position. GEO 15 Service Manual - Rel. 02 06-2016...
  • Page 39 If the answer is Bad Calibration the problem could be or the camera or the calibration bar is not stable. For more information see the troubleshooting page. Press NO. Place BAR on the Central Position. GEO 15 Service Manual - Rel. 02 06-2016...
  • Page 40 Press Start. Wait for the following response. Move the BAR in another position. Press YES/SI. GEO 15 Service Manual - Rel. 02 06-2016...
  • Page 41 NOT GOOD. If Rx, Ry, Rz values of Cameras and Actual rows differ less than 0.10(degrees), the Calibration Check is GOOD. At the end, set again the screen resolution at 800 x 600. GEO 15 Service Manual - Rel. 02 06-2016...

  • Page 42: System Calibration

    Calibration Check is still not performed. Press OK to continue. Select “SYSTEM CALIBRATION”. Follow the instructions on the screen: Place the calibration bar in central position. Make sure the targets will be show inside the yellow frames. GEO 15 Service Manual - Rel. 02 06-2016...
  • Page 43 2,5 degrees otherwise the calibration procedure can’t be performed. In this case please use the bar height regulation pin or tilt the bar with a spacer in order to reach right values. GEO 15 Service Manual - Rel. 02 06-2016...
  • Page 44 Press START. When OK a popup message will appear. Press YES/SI to continue. Note: from version 6.4.2.47 of ImageServer.exe the yellow squares switch to green when the targets are in the right position. GEO 15 Service Manual - Rel. 02 06-2016...
  • Page 45 Make sure the targets will be show inside the yellow frames. Press START. Click on Yes/SI. Note: from version 6.4.2.47 of ImageServer.exe the yellow squares switch to green when the targets are in the right position. GEO 15 Service Manual - Rel. 02 06-2016...
  • Page 46 In this case or a camera is bad or the calibration bar is warped. Repeat System Calibration, if the error message is showed again, please read the troubleshooting guide. At the end, set again the screen resolution at 800 x 600. GEO 15 Service Manual - Rel. 02 06-2016...

  • Page 47: Target Calibration

    Example: If changing the front right target and clamp assembly, it is to replace the SysCal1.ini file. This file is contained in the folder with the same name of the target serial number. GEO 15 Service Manual - Rel. 02 06-2016...
  • Page 48 Press OK to continue. Select “Target Calibration”. Select “Read From File”. If you replaced the Front Right Target: Select “Load Target S2”. S1: Front Left S2: Front Right S3: Rear Right S4: Rear Left GEO 15 Service Manual - Rel. 02 06-2016...
  • Page 49 For other Checks select OK. Otherwise close the page by clicking on Select "EXIT". At the end, set again the screen resolution at 800 x 600. RESTART ALIGNER SOFTWARE. GEO 15 Service Manual - Rel. 02 06-2016...

  • Page 50: Single Target Calibration

    Press OK on both message boxes. This warning inform you that System and Target calibration are already done, but Calibration Check is still not performed. Press OK to continue. Select “Target Calibration”. Select “Calibrate 1 Target”. GEO 15 Service Manual - Rel. 02 06-2016...
  • Page 51 Raise up the car underbody and the wheel must be free. Place the target in vertical position (0 degrees). Click on “Start”. Acquisition in progress… please wait. GEO 15 Service Manual - Rel. 02 06-2016...
  • Page 52 MOUNTED THE OPTIONAL UP/DOWN KIT DO NOT MOVE THE BEAM DURING TARGET CALIBRATION PROCEDURE. Rotate the target of 30 degrees, as in the picture. Click on “Start”. Click on YES/SI. Target calibration complete. GEO 15 Service Manual - Rel. 02 06-2016...

  • Page 53: Target Calibration

    Then the customer will do the Loading Target Parameter Procedure, and the aligner will be ready again. 4 Target Calibration This procedure is required only if needed to re-calibrate all 4 targets (used only in production line). Please refer to the Single Target Calibration Procedure. GEO 15 Service Manual - Rel. 02 06-2016...

  • Page 54: Drive On Assistant Camera Installation

    Windows by entering the “system” password, as explained above. Open the C:\Program Files\Alignment folder. Run the "P" application. Drive on Assistant configuration page. In the top-right of the screen there is the camera configuration box. GEO 15 Service Manual - Rel. 02 06-2016...
  • Page 55 When the configuration is OK, click on Set for both camera. Click on the YELLOW ARROW icon to exit. Drive On Assistant Aligner enabling procedure. Start the Aligner software. Go in the main page. Select GEO 15 Service Manual - Rel. 02 06-2016...
  • Page 56 Press "F11" and then select: Service Programs  After-Sales Service After-sales Service Select "Config Machine". Press ENTER. Select "WebCam". Press ENTER. Select "YES". Press ENTER. Press "F3" to confirm. GEO 15 Service Manual - Rel. 02 06-2016...
  • Page 57 Press "F11" and then select: Service Programs  After-Sales Service Smart Card Data Card Diagnostics page: Select Select "Smart Card Update". GEO 15 Service Manual - Rel. 02 06-2016...
  • Page 58 Click on OK. Click on "F3" icon to continue. Click on to return to the main page of the Aligner. Restart the Aligner software. Note: Keep the UPGRADE USB KEY for future upgrades. GEO 15 Service Manual - Rel. 02 06-2016...

  • Page 59: Working Language Changing

    Working language changing To change the working language, please, proceed as follows. Press “F2”. Enter the password “end” and then press “F3” or click on Double left click on GEO 15 Service Manual - Rel. 02 06-2016...
  • Page 60 Left click on “Region and Language”. Click on to display the languages list. Select the language (for example Korean). GEO 15 Service Manual - Rel. 02 06-2016...
  • Page 61 Left click on “Apply”. Left click on “Administrative” and then left click on “Change system local”. Click on to display the languages list. GEO 15 Service Manual - Rel. 02 06-2016...
  • Page 62 Select the language. Left click on “OK”. Left click on “Restart now” and after check in the right side of the screen the correct language. Press “F11”. GEO 15 Service Manual - Rel. 02 06-2016...
  • Page 63 Select “Setup” and then press “Enter”. Select “Customisation” and then press “Enter”. Select “Working Language” and then press “Enter”. Press on the keyboard to select the language. Confirm with “F3 or left click on to confirm. GEO 15 Service Manual - Rel. 02 06-2016...

  • Page 64: Camera Movement Installation Instruction (Up/Down Kit)

    2x Check rail 4x Fixing plate for check rails 1x Sliding carriage of camera beam 2x Switch with support 1x Motor with electric wiring 1x Pulley and motor support 1x End support of pulley GEO 15 Service Manual - Rel. 02 06-2016...
  • Page 65 Package content: GEO 15 Service Manual - Rel. 02 06-2016...
  • Page 66 The rails are already assembled GEO 15 Service Manual - Rel. 02 06-2016...
  • Page 67 Installation Instruction: 1 - Place the rails on the backside of the pole. GEO 15 Service Manual - Rel. 02 06-2016...
  • Page 68 2 - Match the holes in this way. GEO 15 Service Manual - Rel. 02 06-2016...
  • Page 69 3 - Install the motor support. 4 - Fix the motor and fix with self adhesive tape the electric box on the left side. GEO 15 Service Manual - Rel. 02 06-2016...
  • Page 70 5 - Install the pulley and the cord. 6 - Fix the pulley on the motor shaft, the two pulley must to work at the same height. GEO 15 Service Manual - Rel. 02 06-2016...
  • Page 71 7 - The steel cable come from the top hole and then it will be fixed on the plate. 8 - Install the 2 safety microswitch. First install the UPPER microswitch. GEO 15 Service Manual - Rel. 02 06-2016...
  • Page 72 B - Remember of the proper wires connection (RED WIRE with connector no. 12 on the RIGHT – BLUE WIRE with connector no. 11 on the LEFT). RED WIRE BLUE WIRE on 12 on 11 C - Disconnect RED and BLUE wires. GEO 15 Service Manual - Rel. 02 06-2016...
  • Page 73 D - Insert micro switch cable (it is the LONGEST CABLE) inside the hole on rear carter. E - Insert cameras cable inside the hole on rear carter. F - Mount the below micro switch. GEO 15 Service Manual - Rel. 02 06-2016...
  • Page 74 G - Connect RED WIRE with RIGHT connector no. 12 and BLUE WIRE with LEFT connector no. 11. BLUE WIRE RED WIRE on 11 on 12 H - Close the below micro switch. GEO 15 Service Manual - Rel. 02 06-2016...
  • Page 75 The UP/DOWN KIT system is operated by Wheel Alignment Software. Calibration or further settings via SW are not required! Start the Wheel Alignment Software. UP MOVEMENT: Press PAGE_UP key on the keyboard. DOWN MOVEMENT: Press PAGE_DOWN key on the keyboard. GEO 15 Service Manual - Rel. 02 06-2016...
  • Page 76 Electrical Wiring GEO 15 Service Manual - Rel. 02 06-2016...
  • Page 77 12 - To place it in the front is necessary to disconnect cables, but these cables are signed… just connect 1-1; 2-2; etc… The UP/DOWN KIT system works completely independent from the wheel aligner’s software. Calibration or further settings via SW are not required! GEO 15 Service Manual - Rel. 02 06-2016...

  • Page 78: Service Procedure

    To check if the hardware work properly install ISCapture software. Please insert the Aligner Software CD-ROM and on ADD-ON folder you will found the ISCapture 3.6 Setup. Please Install it…. Click on Next. GEO 15 Service Manual - Rel. 02 06-2016...
  • Page 79 Click on Next. Unselect the 2 Video Compressor Plugin and click on Next. Wait… Click on Next. GEO 15 Service Manual - Rel. 02 06-2016...
  • Page 80 Select “Yes, restart the computer now”. Click on Finish. After PC-Restart close the wheel aligner program. Double click on ISCapture icon on Desktop to run the camera test program. ISCapture main page. GEO 15 Service Manual - Rel. 02 06-2016...
  • Page 81 Identify which camera is not working (LEFT or RIGHT) by referring to the above picture of the aligner. Please note that LEFT and RIGHT camera assembly are different: THIN THIN THICK THICK LEFT CAMERA ASSEMBLY RIGHT CAMERA ASSEMBLY GEO 15 Service Manual - Rel. 02 06-2016...

  • Page 82: Camera Assembly Replacement Procedure

    RIGHT CAMERA ASSEMBLY REPLACING Open the cover by unscrewing the 4 rear screws. Unscrew the 2 screws to unlock the camera assembly. Extract camera assembly from the beam and unconnect the USB cable. GEO 15 Service Manual - Rel. 02 06-2016...
  • Page 83 SUPPORT METAL BLOCK. This picture shows the TOP VIEW OF THE LEFT CAMERA ASSEMBLY INSTALLED ON THE BEAM. Please note the thick spacer position (on left side). Re-mount the the camera cover. GEO 15 Service Manual - Rel. 02 06-2016...
  • Page 84 You should see the new camera serial number. This message informs the operator that one camera has been replaced. Clicking on OK the new camera calibration parameters will be stored in the PC. Press OK. GEO 15 Service Manual - Rel. 02 06-2016...
  • Page 85 EXIT from the ServiceWindows program and run the Wheel Aligner Software, by clicking on the WheelAl icon on the desktop. At the end, set again the screen resolution at 800 x 600. GEO 15 Service Manual - Rel. 02 06-2016...

  • Page 86: Ir-Led Board Replacing Procedure

    There are 2 cables: USB cable Power cable. RIGHT IR-LED BOARD There are 3 cables: USB cable Power cable Automatic Camera Movement cable. Unscrew the 4 screws to unlock the camera assembly. GEO 15 Service Manual - Rel. 02 06-2016...
  • Page 87 Re-mount the the camera cover. Tighten the 4 rear fastening screws. IR-LED BOARD REPLACEMENT PROCEDURE COMPLETED. NOW THE ALIGNER WORKS PROPERLY. Plug the main power of the aligner and turn on the PC. GEO 15 Service Manual - Rel. 02 06-2016...

  • Page 88: Target Quality Check

    The software will display informations about the 2 cameras connected to the Press OK on both message boxes. This warning inform you about the service tasks. Press OK to continue. Select “Expert Mode”. GEO 15 Service Manual - Rel. 02 06-2016...
  • Page 89 The left image shows the ideal target layout (in red) and the real target (in green). It is also shown the red-blue- green dots. At the end, set again the screen resolution at 800 x 600. GEO 15 Service Manual - Rel. 02 06-2016...

  • Page 90: Target Replacing

    This grain is used to fix the clamp to the plastic cover of the target. The 4 holes (circled in red) are used to insert the target grain, as showed in the following pictures. GEO 15 Service Manual - Rel. 02 06-2016...
  • Page 91 FRONT RIGHT TARGET GRAIN TOP OF THE CLAMP FRONT LEFT TARGET GRAIN FRONT LEFT-REAR LEFT REAR LEFT TARGET GRAIN After target assembly it is required to perform the Target Calibration on the new target. GEO 15 Service Manual - Rel. 02 06-2016...

  • Page 92: Software Improvements

    HALF SUN: Select this operation mode if the condition of sunlight and reflections inside the garage is medium. FULL SUN: Select this operation mode if the condition of sunlight and reflections inside the garage is remarkable. GEO 15 Service Manual - Rel. 02 06-2016...

  • Page 93: Job Records Saving

    JOB RECORDS SAVING For saving and storing all the jobs performed by the user with GEO 15, just follow the steps below. to exit to Windows or press "F2" and Select enter the password "end". Open the C:\Program Files\Alignment folder.

  • Page 94: Setting For A Correct Graphic Print

    [Printer.HP Deskjet 5600 Series] -3=600 We have removed the underlining symbol (the first character) and kept the rest unaltered; we have replaced the characters after “=” with the resolution value read. GEO 15 Service Manual - Rel. 02 06-2016...
  • Page 95 _-1=-1 (Fast Draft) 300 dpi _-2=-2 (Draft) 600 dpi _-3=-3 (Fast Normal) 600 dpi _-4=-4 (Normal) 600 dpi _-4=-4 (Maximum dpi) 1200 dpi In this case there are two lines with an index of “_-4=” GEO 15 Service Manual - Rel. 02 06-2016...
  • Page 96 NOTE: if more than one sheet is printed, with the subsequent sheets showing only a part of the text and not a cut part of the graphics, check first of all that the dimensions of the paper used correspond to the paper dimensions set in the printer. GEO 15 Service Manual - Rel. 02 06-2016...

  • Page 97: Troubleshooting

    If the camera are not directly connected to USB 2.0 ports of the PC the following messages could appear and in some case locks the PC. The PC has to be restarted in order to exit the Synchronization procedure. GEO 15 Service Manual - Rel. 02 06-2016...
  • Page 98 In case ONE or BOTH Tucsen ISH130BW are connected to an USB 3.0 HUB (See above Intel USB 3.0 eXtensible Host Controller) IT IS REQUIRED TO CHANGE THE CAMERA CONNECTION PORTS TO TWO USB 2.0 ports. GEO 15 Service Manual - Rel. 02 06-2016...
  • Page 99 F1 icon the error page is shown. It is necessary to close the aligner and exit to Windows. The Apache icon is in the “STOP” condition: Start the Windows Command Prompt. GEO 15 Service Manual - Rel. 02 06-2016...
  • Page 100 Foundation\Apache2.2\bin Run: httpd –k install Press Enter. Click on Allow access RESTART THE PC. After PC restart the Apache status is “RUNNING”. The help page are correctly displayed inside the Aligner software. GEO 15 Service Manual - Rel. 02 06-2016...
