Description of the device

ATTENTION
Device damage during transport
If the device is not transported correctly, it may be damaged.
• Use suitable covers to protect the connections against damage.
4 Description of the device
The Servitec Mini is a water degassing system for use in small systems of up to 1 m
4.1

Overview

1 Venting grille
2 Hinge for folding up
3 Controller
4 Gas-rich water inlet
5 Dirt trap
6 Degassed water outlet
7 Folds up in the direction of the arrow
4.2

Identification

The nameplate provides information on manufacturer, year of manufacture, part number and technical data. The nameplate is located on the rear side of
the controller inside the system.
Information on nameplate
Type
Serial No.
min. / max. allowable pressure P
min. / max. continuous operating temperature
Year built
8 — English
system volume.
3
Meaning
Device name
Serial number
Minimum/maximum permissible pressure
Minimum/maximum continuous operation temperature
Year of manufacture
Servitec Mini — 01.08.2017 - Rev. B
