Check Real-Time Access Records; Event Center - HIKVISION DS-K1TA70MI-T User Manual

Capture
Capture a picture manually.
Note
The Capture button is available when the device supports capture function. The picture is
saved in the PC running the client. For setting the saving path, refer to Set File Saving Path in
the user manual of the client software.
Result
The icon of the doors will change in real-time according to the operation if the operation is
succeeded.

7.9.2 Check Real-Time Access Records

The access records will display in real time, including card swiping records, face recognitions
records, comparison records, etc. You can view the person information and view the picture
captured during access.
Steps
1. Click Monitoring and select a group from the drop-down list on the upper-right corner.
The access records triggered at the doors in the selected group will display in real time. You can
view the details of the records, including card No., person name, organization, event time, etc.
2. Optional: Check the event type and event status so that these events will show in the list if the
events are detected. The events of unchecked type or status will not be displayed in the list.
3. Optional: Check Show Latest Event and the latest access record will be selected and displayed
at the top of the record list.
4. Optional: Click the event to view the accessed person details, including person pictures
(captured picture and profile), person No., person name, organization, phone, contact address,
etc.
Note
You can double click the captured picture to enlarge it to view the details.
5. Optional: Right click on the column name of the access event table to show or hide the column
according to actual needs.

7.10 Event Center

The event information (for example, device offline) received by the client displays. In the Event
Center, you can check the detailed information of the real-time and historical events, view the
event linked video, handle the events, and so on.
Face Recognition Terminal User Manual
110
