HIKVISION DS-K1T501SF Manual

Call 2 nd indoor station and hik connect
Hide thumbs Also See for DS-K1T501SF:

Advertisement

Quick Links

Download this manual
DS-K1T501SF call 2
List of devices and version :
Model
DS-K8301WT
DS-KH8350-WTE1
DS-K1T501SF
IVMS-4200
Functions:
1.
DS-K1T501SF can support 1
station with this version.
2.
After adding the indoor station to Hik Connect , press the call
button on the DS-K1T501SF, both the indoor station and Hik
Connect will get the call.
3.
Hik Connect can add the DS-K1T501SF directly without
indoor station.
4.
DS-K1T501SF can support extensions at most 8 extensions.
Operations:
1.
Download the firmware and upgrade the device, after
upgrading the device, please default all devices. Then
activate the device and change the IP address to which you
want.
2.
Remote configuration on DS-K1T501SF , select General
and then change the Device Name to 10010110001.
nd
indoor station and Hik connect
Firmware
V1.5.0 build 181121
V2.1.2 build 191014
V1.1.0 build 191010
V3.2.0.10 build 20191216
st
and 2
nd
generation indoor

Advertisement

loading
Need help?

Need help?

Do you have a question about the DS-K1T501SF and is the answer not in the manual?

Questions and answers

Related Manuals for HIKVISION DS-K1T501SF

Summary of Contents for HIKVISION DS-K1T501SF

  • Page 1 After adding the indoor station to Hik Connect , press the call button on the DS-K1T501SF, both the indoor station and Hik Connect will get the call. Hik Connect can add the DS-K1T501SF directly without indoor station.
  • Page 2 DS-K1T501SF call 2 indoor station and Hik connect (0001 is the indoor station room No, if room No is 2, then we should fill 10010110002) Remote configuration on indoor station, select ID configuration and change the Call No to 1.
  • Page 3 DS-K1T501SF call 2 indoor station and Hik connect And then select Linked Network Configuration and input the DS- K1T501SF IP address.
  • Page 4 DS-K1T501SF call 2 indoor station and Hik connect For the extension indoor station. Remote configuration on extension indoor station. Select ID Configuration and change the Device type to Indoor Extension and also input indoor station No, it can support up...
  • Page 5 DS-K1T501SF call 2 indoor station and Hik connect Select Linked Network Configuration and input Main indoor station IP address. For the extension outdoor station ,select Advanced Settings.
  • Page 6 DS-K1T501SF call 2 indoor station and Hik connect The Security control platform is for the IP address of the Main DS-K1T501SF. The No is the extension No. After all settings, please reboot all the devices.
  • Page 7 Hik connect Trouble shooting Q1: Customer feedbacks he can’t live view the image on the indoor station. A:Check the resolution of the DS-K1T501SF,make sure the resolution is 720P Remote configuration on DS-K1T501SF, select Video/Audio and change the resolution to 720P Q2: Customer feedbacks he can get the call on the indoor station but can’t get the call on Hik connect.
  • Page 8 Remote comfiguration on indoor station, select Time Parameters and change the Call Forwarding Time to 0s. Q3: when press the finger on DS-K1T501SF , it will not call indoor station directly when can’t recognize the finger. A : This function is disabled by default.
  • Page 9 DS-K1T501SF call 2 indoor station and Hik connect Q4： The device neither call indoor station nor enroll card A:Check the device whether it is in the arming status.
  • Page 10 DS-K1T501SF call 2 indoor station and Hik connect Select Tool-> Device Arming Control , make sure the device is arming. This version doesn’t support two way audio beginning from the indoor station side.
