Butler LIBRAK355 Instruction Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
For spare parts drawings refer to the section " LIST OF COMPONENTS" enclosed to this manual.
• For any further information please contact your local dealer or call:
Phone (+39) 0522 647911 - Fax (+39) 0522 649760 - e-mail: Info@butler.it
1297-M008-4_B
LIBRAK355S
LIBRAK355PS
LIBRAK355WS
LIBRAK355PWS
INSTRUCTION MANUAL
TRANSLATION FROM THE
GB
ORIGINAL INSTRUCTIONS
BUTLER ENGINEERING and MARKETING S.p.A. a s. u.
Via dell'Ecologia, 6 - 42047 Rolo - (RE) Italy
1297-M008-4_B - Rev. n. 4 (04/2018)

Advertisement

Table of Contents
loading

Related Manuals for Butler LIBRAK355

Summary of Contents for Butler LIBRAK355

  • Page 1 • For any further information please contact your local dealer or call: BUTLER ENGINEERING and MARKETING S.p.A. a s. u. Via dell’Ecologia, 6 - 42047 Rolo - (RE) Italy Phone (+39) 0522 647911 - Fax (+39) 0522 649760 - e-mail: Info@butler.it 1297-M008-4_B - Rev. n. 4 (04/2018)

  • Page 2: Table Of Contents

    1297-M008-4_B INSTRUCTION, USE AND MAINTENANCE MANUAL Page 2 of 68 LIBRAK355 - LIBRAK355P - LIBRAK355S - LIBRAK355PS - LIBRAK355WS - LIBRAK355PWS SUMMARY 11.0 AIR CONNECTION _________________ 21 SYMBOLS USED IN THE MANUAL ________ 5 12.0 FITTING THE WHEEL ON THE MAN- 1.0 GENERAL INTRODUCTION __________ 7...
  • Page 3 1297-M008-4_B INSTRUCTION, USE AND Page 3 of 68 MAINTENANCE MANUAL LIBRAK355 - LIBRAK355P - LIBRAK355S - LIBRAK355PS - LIBRAK355WS - LIBRAK355PWS 14.8.1 ECO-WEIGHT mode ________________39 15.3.3 Gauge calibration __________________55 14.8.2 SPLIT mode ________________________41 15.3.4 Touch monitor calibration (only 14.8.3 Weights hidden behind spokes...
  • Page 4 1297-M008-4_B INSTRUCTION, USE AND MAINTENANCE MANUAL Page 4 of 68 LIBRAK355 - LIBRAK355P - LIBRAK355S - LIBRAK355PS - LIBRAK355WS - LIBRAK355PWS Fig. 1 1 – Weight holding bridge 11 – Pusher ring 2 – Pneumatic mandrel (only for LIBRAK355P - 12 –...

  • Page 5: Symbols Used In The Manual

    1297-M008-4_B INSTRUCTION, USE AND Page 5 of 68 MAINTENANCE MANUAL LIBRAK355 - LIBRAK355P - LIBRAK355S - LIBRAK355PS - LIBRAK355WS - LIBRAK355PWS SYMBOLS USED IN THE MANUAL Symbols Description Symbols Description Mandatory. Operations or jobs to Read instruction manual. be performed compulsorily.
  • Page 6 1297-M008-4_B INSTRUCTION, USE AND MAINTENANCE MANUAL Page 6 of 68 LIBRAK355 - LIBRAK355P - LIBRAK355S - LIBRAK355PS - LIBRAK355WS - LIBRAK355PWS INFORMATION PLATE LOCATION TABLE Code numbers of plates 99990114 Arrow plate 99990758 Electricity danger plate 999910050 Protection device use plate...

  • Page 7: General Introduction

    1297-M008-4_B INSTRUCTION, USE AND Page 7 of 68 MAINTENANCE MANUAL LIBRAK355 - LIBRAK355P - LIBRAK355S - LIBRAK355PS - LIBRAK355WS - LIBRAK355PWS INTENDED USE SOME OF THE PICTURES AND/ OR DISPLAY SCREEN PAGES The machines described in this manual and their...

  • Page 8: Safety Devices

    1297-M008-4_B INSTRUCTION, USE AND MAINTENANCE MANUAL Page 8 of 68 LIBRAK355 - LIBRAK355P - LIBRAK355S - LIBRAK355PS - LIBRAK355WS - LIBRAK355PWS SAFETY DEVICES GENERAL SAFETY RULES PERIODICALLY, AT LEAST MONTH- LY, CHECK THE INTEGRITY AND THE FUNCTIONALITY OF THE SAFETY AND PROTECTION DE- •...

  • Page 9: Packing And Mobilization For Transport

    1297-M008-4_B INSTRUCTION, USE AND Page 9 of 68 MAINTENANCE MANUAL LIBRAK355 - LIBRAK355P - LIBRAK355S - LIBRAK355PS - LIBRAK355WS - LIBRAK355PWS PACKING AND MOBILIZATION FOR OPERATORS MUST WEAR SUIT- TRANSPORT ABLE WORK CLOTHES, PROTEC- TIVE GLASSES AND GLOVES, AGAINST THE DANGER FROM...

  • Page 10: Unpacking

    1297-M008-4_B INSTRUCTION, USE AND MAINTENANCE MANUAL Page 10 of 68 LIBRAK355 - LIBRAK355P - LIBRAK355S - LIBRAK355PS - LIBRAK355WS - LIBRAK355PWS UNPACKING MOBILIZATION DURING UNPACKING, ALWAYS WEAR GLOVES TO PREVENT ANY INJURY CAUSED BY CONTACT THE LIFTING EQUIPMENT MUST WITHSTAND...

  • Page 11: Working Area

    1297-M008-4_B INSTRUCTION, USE AND Page 11 of 68 MAINTENANCE MANUAL LIBRAK355 - LIBRAK355P - LIBRAK355S - LIBRAK355PS - LIBRAK355WS - LIBRAK355PWS MACHINE ASSEMBLY Working area After having freed the various components from the Fig. 3 packing check that they are complete, and that there...

  • Page 12: Fixtures Contained In The Packing

    1297-M008-4_B INSTRUCTION, USE AND MAINTENANCE MANUAL Page 12 of 68 LIBRAK355 - LIBRAK355P - LIBRAK355S - LIBRAK355PS - LIBRAK355WS - LIBRAK355PWS Fixtures contained in the packing Fig. 5 The packing case contains also the fixtures box. Check that all the parts listed below are there (see Fig.

  • Page 13: Assembly Procedures

    1297-M008-4_B INSTRUCTION, USE AND Page 13 of 68 MAINTENANCE MANUAL LIBRAK355 - LIBRAK355P - LIBRAK355S - LIBRAK355PS - LIBRAK355WS - LIBRAK355PWS Assembly procedures 9.3.2 Fitting and removal of the pneumatic mandrel on the flange 9.3.1 Fitting the mandrel on the flange...
  • Page 14 INSTRUCTION, USE AND MAINTENANCE MANUAL Page 14 of 68 LIBRAK355 - LIBRAK355P - LIBRAK355S - LIBRAK355PS - LIBRAK355WS - LIBRAK355PWS 2. Press the brake's pedal and, at the same time, tighten 4. Close the pneumatic mandrel by means of the pedal the internal mandrel as far as it will go using the to access the key socket (Fig.

  • Page 15: Fitting The Protection Guard

    1297-M008-4_B INSTRUCTION, USE AND Page 15 of 68 MAINTENANCE MANUAL LIBRAK355 - LIBRAK355P - LIBRAK355S - LIBRAK355PS - LIBRAK355WS - LIBRAK355PWS 9.3.3 Fitting the protection guard 9.3.4 Fitting of external data gauge (stand- ard for LIBRAK355S - LIBRAK355PS 1. Mount the protection guard (Fig. 13 ref. 1) to the models ) (optional for LIBRAK355 - LI- support (Fig.

  • Page 16: Fitting Of Professional External Data Gauge

    INSTRUCTION, USE AND MAINTENANCE MANUAL Page 16 of 68 LIBRAK355 - LIBRAK355P - LIBRAK355S - LIBRAK355PS - LIBRAK355WS - LIBRAK355PWS 3. Connect connector (Fig. 16 ref. 1) of the cable com- 9.3.5 Fitting of professional external data ing from inside the machine to connector (Fig. 16 gauge (optional for LIBRAK355 - ref.

  • Page 17: Fitting Of Run-Out Ultrasounds With Support

    INSTRUCTION, USE AND Page 17 of 68 MAINTENANCE MANUAL LIBRAK355 - LIBRAK355P - LIBRAK355S - LIBRAK355PS - LIBRAK355WS - LIBRAK355PWS 3. Connect connector (Fig. 19 ref. 1) of the cable com- 3. Demount wheel balancer's protection guard again. ing from inside the machine to connector (Fig. 19 4.

  • Page 18: Monitor Fitting

    INSTRUCTION, USE AND MAINTENANCE MANUAL Page 18 of 68 LIBRAK355 - LIBRAK355P - LIBRAK355S - LIBRAK355PS - LIBRAK355WS - LIBRAK355PWS 9.3.7 Monitor fitting 3. Fix the monitor (Fig. 23A ref. 1) to the support (Fig. 23A ref. 2) with the screws (Fig. 23A ref. 3) 1.

  • Page 19: 19" Touch Monitor Fitting (Vargm19Ts355)

    INSTRUCTION, USE AND Page 19 of 68 MAINTENANCE MANUAL LIBRAK355 - LIBRAK355P - LIBRAK355S - LIBRAK355PS - LIBRAK355WS - LIBRAK355PWS 9.3.8 19” Touch monitor fitting 3. Connect the cables to the monitor (Fig. 23B ref. 1), as shown in Fig. 23B (USB cable ref. 2, HDMI (VARGM19TS355) cable ref.

  • Page 20: Electrical Connection

    1297-M008-4_B INSTRUCTION, USE AND MAINTENANCE MANUAL Page 20 of 68 LIBRAK355 - LIBRAK355P - LIBRAK355S - LIBRAK355PS - LIBRAK355WS - LIBRAK355PWS 10.0 ELECTRICAL CONNECTION FAILURE TO OBSERVE THE ABOVE INSTRUCTIONS WILL IMMEDIATE- EVEN THE TINIEST PROCEDURE LY INVALIDATE THE WARRANTY.

  • Page 21: Air Connection

    1297-M008-4_B INSTRUCTION, USE AND Page 21 of 68 MAINTENANCE MANUAL LIBRAK355 - LIBRAK355P - LIBRAK355S - LIBRAK355PS - LIBRAK355WS - LIBRAK355PWS 12.0 FITTING THE WHEEL ON THE MAN- 11.0 AIR CONNECTION DREL Only for LIBRAK355P - LIBRAK355PS - LIBRAK355PWS models...
  • Page 22 MAINTENANCE MANUAL Page 22 of 68 LIBRAK355 - LIBRAK355P - LIBRAK355S - LIBRAK355PS - LIBRAK355WS - LIBRAK355PWS 4. Fit the protection cap (Fig. 28 ref. 1) in the locknut 7. Fit the cone (Fig. 30 ref. 3) with the narrowest part (Fig.

  • Page 23: Fitting Of The Wheel (Librak355P - Librak355Ps - Librak355Pws)

    1297-M008-4_B INSTRUCTION, USE AND Page 23 of 68 MAINTENANCE MANUAL LIBRAK355 - LIBRAK355P - LIBRAK355S - LIBRAK355PS - LIBRAK355WS - LIBRAK355PWS 12.2 Fitting of the wheel ( LIBRAK355P - Fig. 32 LIBRAK355PS - LIBRAK355PWS) Open the pneumatic mandrel by means of the special pedal, see Fig.

  • Page 24: Adjustment Of Ultrasound Sensor Sup

    1297-M008-4_B INSTRUCTION, USE AND MAINTENANCE MANUAL Page 24 of 68 LIBRAK355 - LIBRAK355P - LIBRAK355S - LIBRAK355PS - LIBRAK355WS - LIBRAK355PWS 12.3 Adjustment of ultrasound sensor sup- Fig. 34 port (standard for LIBRAK355WS - LIBRAK355PWS models) (optional for LIBRAK355 - LIBRAK355P models) Ultrasound sensor support (Fig.

  • Page 25: Correct Positioning Of The Run-Out Ul- Trasounds Detecting Device

    1297-M008-4_B INSTRUCTION, USE AND Page 25 of 68 MAINTENANCE MANUAL LIBRAK355 - LIBRAK355P - LIBRAK355S - LIBRAK355PS - LIBRAK355WS - LIBRAK355PWS 13.0 CONTROL PANEL IF ACTIVATED, EACH TIME THAT The wheel balancers are equipped with a control panel THE WHEEL PROTECTION GUARD with a 7-key-keyboard (Fig.

  • Page 26: Wheel Balancing

    1297-M008-4_B INSTRUCTION, USE AND MAINTENANCE MANUAL Page 26 of 68 LIBRAK355 - LIBRAK355P - LIBRAK355S - LIBRAK355PS - LIBRAK355WS - LIBRAK355PWS 14.0 WHEEL BALANCING Touch screen Fig. 39B 14.1 Switching the machine on and off Press the "ON" switch (Fig. 25 ref. 1), located in the rear part of the equipment.

  • Page 27: Balancing Programs Setting

    INSTRUCTION, USE AND Page 27 of 68 MAINTENANCE MANUAL LIBRAK355 - LIBRAK355P - LIBRAK355S - LIBRAK355PS - LIBRAK355WS - LIBRAK355PWS At the bottom of the main screen and each screen 14.2 Balancing programs setting described below, there will be coloured rectangles The setting of the balancing programs can be per- (Fig.

  • Page 28: Programs Rapid Setting And Measurements Through Distance- Diameter Caliper Arm

    INSTRUCTION, USE AND MAINTENANCE MANUAL Page 28 of 68 LIBRAK355 - LIBRAK355P - LIBRAK355S - LIBRAK355PS - LIBRAK355WS - LIBRAK355PWS 14.2.1 Programs rapid setting and meas- - bring into contact the weights fitting gripper with the inner part of the rim (2 contact points) (see Fig. 42) urements through distance-diameter to select “ALU-S”...
  • Page 29 INSTRUCTION, USE AND Page 29 of 68 MAINTENANCE MANUAL LIBRAK355 - LIBRAK355P - LIBRAK355S - LIBRAK355PS - LIBRAK355WS - LIBRAK355PWS - After entering all the required measures, you can spin • Measuring procedure of electronic RUN-OUT with the distance-diameter caliper arm.
  • Page 30 INSTRUCTION, USE AND MAINTENANCE MANUAL Page 30 of 68 LIBRAK355 - LIBRAK355P - LIBRAK355S - LIBRAK355PS - LIBRAK355WS - LIBRAK355PWS - On the monitor you will see the screen below where Fig. 49 there are buttons to select the type of flaw detection.

  • Page 31: Programs Setting Through "Meas- Urement Being Acquired" Screen Page

    1297-M008-4_B INSTRUCTION, USE AND Page 31 of 68 MAINTENANCE MANUAL LIBRAK355 - LIBRAK355P - LIBRAK355S - LIBRAK355PS - LIBRAK355WS - LIBRAK355PWS 14.2.2 Programs setting through “Measure- ment being acquired” screen page From the “Home” page, press the (Fig. 40 ref. 1) button to display the "Measurement being ac- quired"...

  • Page 32: Indicative Display Of Points Where To Detect Measures/To Fit Weight

    1297-M008-4_B INSTRUCTION, USE AND MAINTENANCE MANUAL Page 32 of 68 LIBRAK355 - LIBRAK355P - LIBRAK355S - LIBRAK355PS - LIBRAK355WS - LIBRAK355PWS 14.3 Indicative display of points where to 14.3.1 Weights positioning detect measures/to fit weight The monitor displays when it is absolutely necessary that the weight is applied at "12 o'clock"...

  • Page 33: Wheel Balancing Screen

    1297-M008-4_B INSTRUCTION, USE AND Page 33 of 68 MAINTENANCE MANUAL LIBRAK355 - LIBRAK355P - LIBRAK355S - LIBRAK355PS - LIBRAK355WS - LIBRAK355PWS 14.5 Wheel balancing screen page descrip- NORMALLY DURING THE DETEC- tion TION OF MEASUREMENTS, THE 1ST ACTIVE FIELD WILL BE THE...

  • Page 34: Balancing Mode

    INSTRUCTION, USE AND MAINTENANCE MANUAL Page 34 of 68 LIBRAK355 - LIBRAK355P - LIBRAK355S - LIBRAK355PS - LIBRAK355WS - LIBRAK355PWS 14.5.1 Balancing mode The machine has the ability to perform the wheel bal- ancing (weights fitting) in 3 different ways: - using the distance-diameter caliper arm with weights fitting grippers;...
  • Page 35 1297-M008-4_B INSTRUCTION, USE AND Page 35 of 68 MAINTENANCE MANUAL LIBRAK355 - LIBRAK355P - LIBRAK355S - LIBRAK355PS - LIBRAK355WS - LIBRAK355PWS 6. Proceed in the same way as described in points TO USE THIS WEIGHT APPLICA- 1-2-3. TION MODE THE OPERATOR...

  • Page 36: Use Of Machines With Disabled Auto- Matic Gauge

    1297-M008-4_B INSTRUCTION, USE AND MAINTENANCE MANUAL Page 36 of 68 LIBRAK355 - LIBRAK355P - LIBRAK355S - LIBRAK355PS - LIBRAK355WS - LIBRAK355PWS 14.6 Use of machines with disabled auto- After entering all the required measures, you can spin matic gauge the wheel by pressing the button...

  • Page 37: Static-1

    1297-M008-4_B INSTRUCTION, USE AND Page 37 of 68 MAINTENANCE MANUAL LIBRAK355 - LIBRAK355P - LIBRAK355S - LIBRAK355PS - LIBRAK355WS - LIBRAK355PWS 14.7.2 Static-1 14.7.4 Dynamic STATIC 1 function is a procedure that offsets wheel The DYNAMIC program allows the wheels balancing...

  • Page 38: Alu-S1

    1297-M008-4_B INSTRUCTION, USE AND MAINTENANCE MANUAL Page 38 of 68 LIBRAK355 - LIBRAK355P - LIBRAK355S - LIBRAK355PS - LIBRAK355WS - LIBRAK355PWS 14.7.6 ALU-S1 14.7.8 ALU-1 ALU-S1 function permits balancing wheels with light ALU-1 function permits balancing wheels with light alloy rims by fitting adhesive weights on the outer side alloy rims by fitting adhesive weights on the outer and and weight with clip on inner side of wheel (at 12 o’...

  • Page 39: Optional Balancing Programs

    1297-M008-4_B INSTRUCTION, USE AND Page 39 of 68 MAINTENANCE MANUAL LIBRAK355 - LIBRAK355P - LIBRAK355S - LIBRAK355PS - LIBRAK355WS - LIBRAK355PWS 14.7.10 ALU-3 14.8 Optional balancing programs ALU-3 function is a procedure that uses mixed weights 14.8.1 ECO-WEIGHT mode to offset wheel unbalance: weight with clip on inner side of wheel, adhesive weight on outer side, not visible because inside the rim.
  • Page 40 INSTRUCTION, USE AND MAINTENANCE MANUAL Page 40 of 68 LIBRAK355 - LIBRAK355P - LIBRAK355S - LIBRAK355PS - LIBRAK355WS - LIBRAK355PWS Press the brake pedal and fit the adhesive weight on the pliers of the distance-diameter caliper as shown in Fig. 56.

  • Page 41: Split Mode

    1297-M008-4_B INSTRUCTION, USE AND Page 41 of 68 MAINTENANCE MANUAL LIBRAK355 - LIBRAK355P - LIBRAK355S - LIBRAK355PS - LIBRAK355WS - LIBRAK355PWS 14.8.2 SPLIT mode IMMEDIATELY AFTER HAVING SELECTED THE ECO -WEIGHT Split procedure proves useful when the dynamic unbal- PROCEDURE, YOU CAN KNOW...
  • Page 42 1297-M008-4_B INSTRUCTION, USE AND MAINTENANCE MANUAL Page 42 of 68 LIBRAK355 - LIBRAK355P - LIBRAK355S - LIBRAK355PS - LIBRAK355WS - LIBRAK355PWS TWO SMALLER WEIGHTS (55g) USING SPLIT PROCEDURE Press button to select the outer weight to edit. Press buttons to increase or decrease the total weight to be fitted.

  • Page 43: Weights Hidden Behind Spokes

    INSTRUCTION, USE AND Page 43 of 68 MAINTENANCE MANUAL LIBRAK355 - LIBRAK355P - LIBRAK355S - LIBRAK355PS - LIBRAK355WS - LIBRAK355PWS 14.8.3 Weights hidden behind spokes mode Adhesive correction weight positioning may not look attractive on some types of rims. In this case, "weights hidden behind spokes"...

  • Page 44: Matching Mode

    INSTRUCTION, USE AND MAINTENANCE MANUAL Page 44 of 68 LIBRAK355 - LIBRAK355P - LIBRAK355S - LIBRAK355PS - LIBRAK355WS - LIBRAK355PWS Bring any spoke upwards at "12 o'clock" position and Complete the operation by adding an additional weight inside the rim as required by the selected mode (ALU- S or STATIC).
  • Page 45 INSTRUCTION, USE AND Page 45 of 68 MAINTENANCE MANUAL LIBRAK355 - LIBRAK355P - LIBRAK355S - LIBRAK355PS - LIBRAK355WS - LIBRAK355PWS STEP 2. Remove the wheel from the wheel balancer. Remove the tyre and turn it on the rim through 180°.
  • Page 46 1297-M008-4_B INSTRUCTION, USE AND MAINTENANCE MANUAL Page 46 of 68 LIBRAK355 - LIBRAK355P - LIBRAK355S - LIBRAK355PS - LIBRAK355WS - LIBRAK355PWS Fig. 58 - Press the button to bring the wheel into posi- tion. In this screen you will see the dynamic unbalance that the wheel had before performing the operation (Fig.

  • Page 47: Special Balancing Programs

    1297-M008-4_B INSTRUCTION, USE AND Page 47 of 68 MAINTENANCE MANUAL LIBRAK355 - LIBRAK355P - LIBRAK355S - LIBRAK355PS - LIBRAK355WS - LIBRAK355PWS 14.9 Special balancing programs 14.10 Recalculation Function After making a spin, the wheel automatically stops, 14.9.1 Pax indicating the weight/s to be fitted and its/their position.

  • Page 48: Motorbike Mode Wheel Balancing

    1297-M008-4_B INSTRUCTION, USE AND MAINTENANCE MANUAL Page 48 of 68 LIBRAK355 - LIBRAK355P - LIBRAK355S - LIBRAK355PS - LIBRAK355WS - LIBRAK355PWS 14.11 Motorbike Mode wheel balancing Fig. 61 By enabling “motorbike wheel balancing” function, the wheel balancers can also balance motorbike wheels.

  • Page 49: User Menu (Options And Cali- Bration)

    1297-M008-4_B INSTRUCTION, USE AND Page 49 of 68 MAINTENANCE MANUAL LIBRAK355 - LIBRAK355P - LIBRAK355S - LIBRAK355PS - LIBRAK355WS - LIBRAK355PWS 15.0 USER MENU (OPTIONS AND CALI- 15.1 Options menu BRATION) Press button to display the monitor screen to enable/disable the options as shown below: From the main page “Home”...
  • Page 50 INSTRUCTION, USE AND MAINTENANCE MANUAL Page 50 of 68 LIBRAK355 - LIBRAK355P - LIBRAK355S - LIBRAK355PS - LIBRAK355WS - LIBRAK355PWS It allows you to change the unit of meas- Enable/disable machine print functions urement of the weights from grams to (disabled on machine delivery).

  • Page 51: Lower Weight Limit

    1297-M008-4_B INSTRUCTION, USE AND Page 51 of 68 MAINTENANCE MANUAL LIBRAK355 - LIBRAK355P - LIBRAK355S - LIBRAK355PS - LIBRAK355WS - LIBRAK355PWS 15.1.1 Lower weight limit 15.1.2 Setting adhesive weight dimensions and static threshold percentage Correction weight below a certain limit is normally shown equal to zero.

  • Page 52: User Management

    INSTRUCTION, USE AND MAINTENANCE MANUAL Page 52 of 68 LIBRAK355 - LIBRAK355P - LIBRAK355S - LIBRAK355PS - LIBRAK355WS - LIBRAK355PWS 15.1.3 User management The "User Management" function is disabled on ma- chine delivery. To enable it, proceed as described in Para 15.1.

  • Page 53: Enabling Of Electronic Run-Out Meas- Uring Device

    1297-M008-4_B INSTRUCTION, USE AND Page 53 of 68 MAINTENANCE MANUAL LIBRAK355 - LIBRAK355P - LIBRAK355S - LIBRAK355PS - LIBRAK355WS - LIBRAK355PWS 15.2 Enabling of electronic Run-out meas- uring device (Optional for LIBRAK355 - LIBRAK355P - LIBRAK355WS - LIBRAK355PWS models) From the main page “Home” press the button to move to the next screen page and the button to access the user menu.

  • Page 54: Mandrel "0" (Zero) Calibration

    1297-M008-4_B INSTRUCTION, USE AND MAINTENANCE MANUAL Page 54 of 68 LIBRAK355 - LIBRAK355P - LIBRAK355S - LIBRAK355PS - LIBRAK355WS - LIBRAK355PWS 15.3.1 Mandrel “0” (zero) calibration 15.3.2 Weight measurement sensors calibra- tion Press the button to display the following screen...

  • Page 55: Gauge Calibration

    INSTRUCTION, USE AND Page 55 of 68 MAINTENANCE MANUAL LIBRAK355 - LIBRAK355P - LIBRAK355S - LIBRAK355PS - LIBRAK355WS - LIBRAK355PWS - At the end, on the monitor will appear the following screen, saying that you should apply a weight of 100 g to the "12 o'clock"...
  • Page 56 1297-M008-4_B INSTRUCTION, USE AND MAINTENANCE MANUAL Page 56 of 68 LIBRAK355 - LIBRAK355P - LIBRAK355S - LIBRAK355PS - LIBRAK355WS - LIBRAK355PWS Place the gauge (Fig. 67 ref. 1) on the mandrel flange (Fig. 67 ref. 2). - Press push button Fig.
  • Page 57 1297-M008-4_B INSTRUCTION, USE AND Page 57 of 68 MAINTENANCE MANUAL LIBRAK355 - LIBRAK355P - LIBRAK355S - LIBRAK355PS - LIBRAK355WS - LIBRAK355PWS - Press push button - Press button to end the operation. On the On the monitor the next screen page will be dis-...
  • Page 58 1297-M008-4_B INSTRUCTION, USE AND MAINTENANCE MANUAL Page 58 of 68 LIBRAK355 - LIBRAK355P - LIBRAK355S - LIBRAK355PS - LIBRAK355WS - LIBRAK355PWS On the monitor the next screen page will be displayed: Fig. 71 SCREW MANDREL Move the tip of the width measuring device (Fig. 73 GAR305 ref.

  • Page 59: Touch Monitor Calibration

    1297-M008-4_B INSTRUCTION, USE AND Page 59 of 68 MAINTENANCE MANUAL LIBRAK355 - LIBRAK355P - LIBRAK355S - LIBRAK355PS - LIBRAK355WS - LIBRAK355PWS Calibration of automatic external data gauge 15.3.4 Touch monitor calibration (only for VARGM19TS355) Mount the GAR352 sizing body onto the mandrel and fix it through the special locking devices.

  • Page 60: Error Signals

    INSTRUCTION, USE AND MAINTENANCE MANUAL Page 60 of 68 LIBRAK355 - LIBRAK355P - LIBRAK355S - LIBRAK355PS - LIBRAK355WS - LIBRAK355PWS 16.0 ERROR SIGNALS During wheel balancer operation, if wrong commands are given by the operator or device faults occur, an error code may appear on the monitor screen.

  • Page 61: Routine Maintenance

    INSTRUCTION, USE AND Page 61 of 68 MAINTENANCE MANUAL LIBRAK355 - LIBRAK355P - LIBRAK355S - LIBRAK355PS - LIBRAK355WS - LIBRAK355PWS 17.0 ROUTINE MAINTENANCE To guarantee the efficiency and correct functioning of the machine, it is essential to carry out daily or...

  • Page 62: Technical Data

    1297-M008-4_B INSTRUCTION, USE AND MAINTENANCE MANUAL Page 62 of 68 LIBRAK355 - LIBRAK355P - LIBRAK355S - LIBRAK355PS - LIBRAK355WS - LIBRAK355PWS 18.0 TECHNICAL DATA LIBRAK 355P 355S 355PS 355WS 355PWS Wheel max. weight (Kg) Max. absorbed voltage (W) Power supply...

  • Page 63: Dimensions

    1297-M008-4_B INSTRUCTION, USE AND Page 63 of 68 MAINTENANCE MANUAL LIBRAK355 - LIBRAK355P - LIBRAK355S - LIBRAK355PS - LIBRAK355WS - LIBRAK355PWS 18.1 Dimensions Fig. 74 * Only for LIBRAK355S and LIBRAK355PS versions...

  • Page 64: Storing

    1297-M008-4_B INSTRUCTION, USE AND MAINTENANCE MANUAL Page 64 of 68 LIBRAK355 - LIBRAK355P - LIBRAK355S - LIBRAK355PS - LIBRAK355WS - LIBRAK355PWS 19.0 STORING 21.0 REGISTRATION PLATE DATA If storing for long periods disconnect the main power supply and take measures to protect the machine from dust build-up.
  • Page 65 PRINTER LASER OUTSIDE POWER SUPPLY MONITOR LASER INSIDE LASER 12 O'CLOCK electric diagram (monitor equipment) LIBRAK355 - LIBRAK355P - LIBRAK355S - LIBRAK355PS - LIBRAK355WS - LIBRAK355PWS WIRING CONNECTION 1297-M008-4_B DIAGRAM Page 65 of 68 Table N°A - Rev. 4 129705532...
  • Page 66 52 – Cable 1,8 m connection USB/A-USB/B 53 – Monitor SBC kit 54 – Power supply cable 55 – Printer kit LIBRAK355 - LIBRAK355P - LIBRAK355S - LIBRAK355PS - LIBRAK355WS - LIBRAK355PWS WIRING CONNECTION 1297-M008-4_B DIAGRAM Page 66 of 68 Table N°A - Rev.
  • Page 67 3 – Card power supply cable 4 – Internal cable assembly + laser blade 5 – Laser external extension cable 6 – External cable assembly + laser blade LIBRAK355 - LIBRAK355P - LIBRAK355S - LIBRAK355PS - LIBRAK355WS - LIBRAK355PWS WIRING CONNECTION 1297-M008-4_B DIAGRAM Page 67 of 68 Table N°B - Rev.

  • Page 68: Librak355P - Librak355Ps - Librak355Pws

    1 – Pneumatic tightening diagram 2 – Tightening drive cylinder 3 – 5/2 NC solenoid valves 4 – Separating filter LIBRAK355P - LIBRAK355PS - LIBRAK355PWS PNEUMATIC CONNECTION 1297-M008-4_B DIAGRAM Page 68 of 68 Table N°C - Rev. 0 129600170...
  • Page 69 • En caso de dudas, para eventuales aclaraciones, póngase en contacto con el distribudor más próximo ó diríjasie directamente a: BUTLER ENGINEERING and MARKETING S.p.A. a s. u. Via dell’Ecologia, 6 - 42047 Rolo - (RE) Italy Phone (+39) 0522 647911 - Fax (+39) 0522 649760 - e-mail: Info@butler.it 1297-R008-3_B - Rev. n. 3 (04/2018)
  • Page 70 LISTA DEI COMPONENTI Pag. 2 di 29 LIST OF COMPONENTS TEILELISTE LIBRAK355 - LIBRAK355P LISTE DES PIECES DETACHEES LIBRAK355S - LIBRAK355PS LISTA DE PIEZAS LIBRAK355WS - LIBRAK355PWS 1297-R008-3_B SOMMARIO - SUMMARY - INHALT SOMMAIRE - SUMARIO Tavola N°1 - Rev. 3 ____ ....... 4 Tavola N°10 - Rev.
  • Page 71 LISTA DEI COMPONENTI Pag. 3 di 29 LIST OF COMPONENTS TEILELISTE LIBRAK355 - LIBRAK355P LISTE DES PIECES DETACHEES LIBRAK355S - LIBRAK355PS LISTA DE PIEZAS LIBRAK355WS - LIBRAK355PWS 1297-R008-3_B Tavola N°18 - Rev. 0 ___ GAR337 ....27 Tavola N°20 - Rev. 1 ___ GAR332 ....29...
  • Page 72 LISTA DEI COMPONENTI - LIST OF COMPONENTS - TEILELISTE Pag. 4 di 29 ASSIEME GENERALE LISTE DES PIECES DETACHEES - LISTA DE PIEZAS MAIN ASSEMBLY GENERALSATZ LIBRAK355 - LIBRAK355P ASSEMBLAGE GENERAL Tavola N°1 - Rev. 3 LIBRAK355S - LIBRAK355PS JUNTO GENERAL LIBRAK355WS - LIBRAK355PWS...
  • Page 73 LISTA DEI COMPONENTI - LIST OF COMPONENTS - TEILELISTE ASSIEME GENERALE MAIN ASSEMBLY LISTE DES PIECES DETACHEES - LISTA DE PIEZAS GENERALSATZ LIBRAK355 - LIBRAK355P ASSEMBLAGE GENERAL Tavola N°1 - Rev. 3 LIBRAK355S - LIBRAK355PS JUNTO GENERAL LIBRAK355WS - LIBRAK355PWS Tav.
  • Page 74 LIBRAK355 LIBRAK355P LIBRAK355S LIBRAK355PS LIBRAK355WS LIBRAK355PWS       LISTA DEI COMPONENTI - LIST OF COMPONENTS - TEILELISTE GRUPPO MOTORE LISTE DES PIECES DETACHEES - LISTA DE PIEZAS MOTOR UNIT Pag. 6 di 29 MOTORSATZ GROUPE MOTEUR Tavola N°2 - Rev.
  • Page 75 LIBRAK355 LIBRAK355P LIBRAK355S LIBRAK355PS LIBRAK355WS LIBRAK355PWS    LISTA DEI COMPONENTI - LIST OF COMPONENTS - TEILELISTE GRUPPO ROTANTE COMPLETO LISTE DES PIECES DETACHEES - LISTA DE PIEZAS COMPLETE ROTARY UNIT Pag. 7 di 29 KOMPLETTER ROTIERENDER SATZ GROUPE ROTATIF COMPLET Tavola N°3A - Rev.
  • Page 76 LIBRAK355 LIBRAK355P LIBRAK355S LIBRAK355PS LIBRAK355WS LIBRAK355PWS    LISTA DEI COMPONENTI - LIST OF COMPONENTS - TEILELISTE GRUPPO ROTANTE COMPLETO LISTE DES PIECES DETACHEES - LISTA DE PIEZAS COMPLETE ROTARY UNIT Pag. 8 di 29 KOMPLETTER ROTIERENDER SATZ GROUPE ROTATIF COMPLET Tavola N°3B - Rev.
  • Page 77 LIBRAK355 LIBRAK355P LIBRAK355S LIBRAK355PS LIBRAK355WS LIBRAK355PWS       LISTA DEI COMPONENTI - LIST OF COMPONENTS - TEILELISTE GRUPPO FRENO LISTE DES PIECES DETACHEES - LISTA DE PIEZAS BRAKE UNIT Pag. 9 di 29 BREMSATZ GROUPE FREIN Tavola N°4 - Rev.
  • Page 78 LIBRAK355 LIBRAK355P LIBRAK355S LIBRAK355PS LIBRAK355WS LIBRAK355PWS       LISTA DEI COMPONENTI - LIST OF COMPONENTS - TEILELISTE GRUPPO TELAIO LISTE DES PIECES DETACHEES - LISTA DE PIEZAS FRAME UNIT Pag. 10 di 29 RAHMENSATZ GROUPE CHASSIS Tavola N°5 - Rev.
  • Page 79 LIBRAK355 LIBRAK355P LIBRAK355S LIBRAK355PS LIBRAK355WS LIBRAK355PWS       LISTA DEI COMPONENTI - LIST OF COMPONENTS - TEILELISTE GRUPPO PLANCIA LISTE DES PIECES DETACHEES - LISTA DE PIEZAS BOARD UNIT Pag. 11 di 29 BRETTSATZ GROUPE PLANCHE Tavola N°6 - Rev.
  • Page 80 LIBRAK355 LIBRAK355P LIBRAK355S LIBRAK355PS LIBRAK355WS LIBRAK355PWS       LISTA DEI COMPONENTI - LIST OF COMPONENTS - TEILELISTE GRUPPO CALIBRO LISTE DES PIECES DETACHEES - LISTA DE PIEZAS TESTER UNIT Pag. 12 di 29 KALIBERSATZ GROUPE CALIBRE Tavola N°7 - Rev.
  • Page 81 LIBRAK355 LIBRAK355P LIBRAK355S LIBRAK355PS LIBRAK355WS LIBRAK355PWS       LISTA DEI COMPONENTI - LIST OF COMPONENTS - TEILELISTE GRUPPO AZIONAMENTO FRENO LISTE DES PIECES DETACHEES - LISTA DE PIEZAS BRAKE OPERATION GROUP Pag. 13 di 29 SATZ FÜR BREMSBETÄTIGUNG GROUPE ACTIONNEMENT FREIN Tavola N°8 - Rev.
  • Page 82 LIBRAK355 LIBRAK355P LIBRAK355S LIBRAK355PS LIBRAK355WS LIBRAK355PWS    LISTA DEI COMPONENTI - LIST OF COMPONENTS - TEILELISTE GRUPPO PEDALE LISTE DES PIECES DETACHEES - LISTA DE PIEZAS PEDAL UNIT Pag. 14 di 29 PEDALSATZ GROUPE PÉDAL Tavola N°9A - Rev. 1...
  • Page 83 LIBRAK355 LIBRAK355P LIBRAK355S LIBRAK355PS LIBRAK355WS LIBRAK355PWS    LISTA DEI COMPONENTI - LIST OF COMPONENTS - TEILELISTE GRUPPO PEDALE MICRO LISTE DES PIECES DETACHEES - LISTA DE PIEZAS MICRO PEDAL UNIT Pag. 15 di 29 MIKRO PEDALSATZ GROUPE PÉDAL MICRO Tavola N°9B - Rev.
  • Page 84 LIBRAK355 LIBRAK355P LIBRAK355S LIBRAK355PS LIBRAK355WS LIBRAK355PWS       LISTA DEI COMPONENTI - LIST OF COMPONENTS - TEILELISTE GRUPPO ELETTRONICA LISTE DES PIECES DETACHEES - LISTA DE PIEZAS ELECTRONICS UNIT Pag. 16 di 29 ELEKTRONIKSATZ GROUPE ÉLECTRONIQUE Tavola N°10 - Rev.
  • Page 85 LIBRAK355 LIBRAK355P LIBRAK355S LIBRAK355PS LIBRAK355WS LIBRAK355PWS       LISTA DEI COMPONENTI - LIST OF COMPONENTS - TEILELISTE GRUPPO IMPIANTO ELETTRICO LISTE DES PIECES DETACHEES - LISTA DE PIEZAS ELECTRICAL SYSTEM UNIT Pag. 17 di 29 SATZ VON ELEKTROANLAGE GROUPE INSTALLATION ÉLECTRIQUE...
  • Page 86 LIBRAK355 LIBRAK355P LIBRAK355S LIBRAK355PS LIBRAK355WS LIBRAK355PWS    LISTA DEI COMPONENTI - LIST OF COMPONENTS - TEILELISTE IMPIANTO SERRAGGIO PNUEMATICO LISTE DES PIECES DETACHEES - LISTA DE PIEZAS PNEUMATIC TIGHTENING SYSTEM Pag. 18 di 29 ANLAGE FÜR PNEUMATISCHE AUFSPANNUNG SYSTÈME SERRAGE PNEUMATIQUE...
  • Page 87 LIBRAK355 LIBRAK355P LIBRAK355S LIBRAK355PS LIBRAK355WS LIBRAK355PWS       LISTA DEI COMPONENTI - LIST OF COMPONENTS - TEILELISTE GRUPPO PROTEZIONE RUOTA LISTE DES PIECES DETACHEES - LISTA DE PIEZAS WHEEL PROTECTION UNIT Pag. 19 di 29 SATZ FÜR RADSCHUTZ GROUPE PROTECTION ROUE Tavola N°13 - Rev.
  • Page 88 LIBRAK355 LIBRAK355P LIBRAK355S LIBRAK355PS LIBRAK355WS LIBRAK355PWS   LISTA DEI COMPONENTI - LIST OF COMPONENTS - TEILELISTE DOTAZIONE A LISTE DES PIECES DETACHEES - LISTA DE PIEZAS A EQUIPMENT Pag. 20 di 29 AUSSTATTUNG A DOTATION A Tavola N°14A - Rev. 1...
  • Page 89 LIBRAK355 LIBRAK355P LIBRAK355S LIBRAK355PS LIBRAK355WS LIBRAK355PWS   LISTA DEI COMPONENTI - LIST OF COMPONENTS - TEILELISTE DOTAZIONE B LISTE DES PIECES DETACHEES - LISTA DE PIEZAS B EQUIPMENT Pag. 21 di 29 AUSSTATTUNG B DOTATION B Tavola N°14B - Rev. 0...
  • Page 90 LIBRAK355 LIBRAK355P LIBRAK355S LIBRAK355PS LIBRAK355WS LIBRAK355PWS  LISTA DEI COMPONENTI - LIST OF COMPONENTS - TEILELISTE DOTAZIONE C LISTE DES PIECES DETACHEES - LISTA DE PIEZAS C EQUIPMENT Pag. 22 di 29 AUSSTATTUNG C DOTATION C Tavola N°14C - Rev. 2...
  • Page 91 LIBRAK355 LIBRAK355P LIBRAK355S LIBRAK355PS LIBRAK355WS LIBRAK355PWS  LISTA DEI COMPONENTI - LIST OF COMPONENTS - TEILELISTE DOTAZIONE D LISTE DES PIECES DETACHEES - LISTA DE PIEZAS D EQUIPMENT Pag. 23 di 29 AUSSTATTUNG D DOTATION D Tavola N°14D - Rev. 1...
  • Page 92 LIBRAK355 LIBRAK355P LIBRAK355S LIBRAK355PS LIBRAK355WS LIBRAK355PWS LISTA DEI COMPONENTI - LIST OF COMPONENTS - TEILELISTE CALIBRO LARGHEZZA PROFESSIONALE LISTE DES PIECES DETACHEES - LISTA DE PIEZAS PROFESSIONAL EXTERNAL DATA GAUGE Pag. 24 di 29 BERUFLICHE BREITENLEHRE CALIBRE LARGEUR PROFESSIONEL Tavola N°15 - Rev. 3...
  • Page 93 LIBRAK355 LIBRAK355P LIBRAK355S LIBRAK355PS LIBRAK355WS LIBRAK355PWS   LISTA DEI COMPONENTI - LIST OF COMPONENTS - TEILELISTE CALIBRO LARGHEZZA LISTE DES PIECES DETACHEES - LISTA DE PIEZAS WIDTH CALIPER Pag. 25 di 29 KALIBER FÜR BREITE CALIBRE LARGEUR Tavola N°16 - Rev. 3...
  • Page 94 LIBRAK355 LIBRAK355P LIBRAK355S LIBRAK355PS LIBRAK355WS LIBRAK355PWS     LISTA DEI COMPONENTI - LIST OF COMPONENTS - TEILELISTE GRUPPO LASER FISSO + ILLUMINATORE LISTE DES PIECES DETACHEES - LISTA DE PIEZAS FIXED LASER + LIGHTING DEVICE UNIT Pag. 26 di 29 FESTLASER + BELEUCHTUNG SATZ GROUPE LASER FIXE + DISPOSITIF D’ÉCLAIRAGE...
  • Page 95 LIBRAK355 LIBRAK355P LIBRAK355S LIBRAK355PS LIBRAK355WS LIBRAK355PWS LISTA DEI COMPONENTI - LIST OF COMPONENTS - TEILELISTE RUN-OUT ULTRASUONI CON SUPPORTO LISTE DES PIECES DETACHEES - LISTA DE PIEZAS ULTRASOUNDS RUN OUT WITH SUPPORT Pag. 27 di 29 ULTRASCHALLSENSOR RUN-OUT MIT TRÄGER RUN-OUT ULTRASONS AVEC SUPPORT Tavola N°18 - Rev.
  • Page 96 LIBRAK355 LIBRAK355P LIBRAK355S LIBRAK355PS LIBRAK355WS LIBRAK355PWS LISTA DEI COMPONENTI - LIST OF COMPONENTS - TEILELISTE DISPOSITIVO LASER ORE 12 LISTE DES PIECES DETACHEES - LISTA DE PIEZAS LASER DEVICE AT 12 O’ CLOCK Pag. 28 di 29 LASERVORRICHTUNG AUF 12 UHR DISPOSITIF LASER À...
  • Page 97 LIBRAK355 LIBRAK355P LIBRAK355S LIBRAK355PS LIBRAK355WS LIBRAK355PWS   LISTA DEI COMPONENTI - LIST OF COMPONENTS - TEILELISTE GRUPPO MISURATORE LARGHEZZA AUTOMATICO LISTE DES PIECES DETACHEES - LISTA DE PIEZAS AUTOMATIC MEASURING DEVICE UNIT Pag. 29 di 29 AUTOMATISCHE BREITEN-MESSVORRICHTUNG GROUPE MESUREUR AUTOMATIQUE DE LA LARGEUR Tavola N°20 - Rev.

This manual is also suitable for:

Librak355pLibrak355sLibrak355psLibrak355wsLibrak355pws

Table of Contents
