ASSEMBLY INSTRUCTIONS
RiverRidge
®
Ellsworth Two Door Spacesaver
ITEM #: 06-031 White
ITEM #: 06-032 Espresso
ADULT ASSEMBLY REQUIRED
This product requires assembly by an adult because of small parts. Care should be taken
in unpacking and assembling this item to keep small parts away from children. During assembly
children should be kept away from the product due to possible risk of injury.
WARNING
SEE FULL WARNING ON PAGE 2
Young children can be seriously injured or killed if furniture tips over. Don't use
this item for a TV stand or place heavy objects on top of item. Always use
angle-braces or anchors to secure furniture to the wall.

Advertisement

loading
Need help?

Need help?

Do you have a question about the Ellsworth 06-031 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for RiverRidge Ellsworth 06-031

Summary of Contents for RiverRidge Ellsworth 06-031

  • Page 1 ASSEMBLY INSTRUCTIONS RiverRidge ® Ellsworth Two Door Spacesaver ITEM #: 06-031 White ITEM #: 06-032 Espresso ADULT ASSEMBLY REQUIRED This product requires assembly by an adult because of small parts. Care should be taken in unpacking and assembling this item to keep small parts away from children. During assembly children should be kept away from the product due to possible risk of injury.
  • Page 2 THIS SHELF UNIT WILL HOLD UP TO 25 POUNDS PER SHELF OR A TOTAL OF 75 POUNDS. DO NOT LOAD EACH SHELF WITH MORE THAN 25 POUNDS. IF LOADED WITH MORE THAN 25 POUNDS PER SHELF AS THIS MAY CAUSE DAMAGE TO THE SHELF AND MAY CAUSE SERIOUS INJURY OR DEATH.

  • Page 3: Parts List

    PARTS LIST DESCRIPTION Top Board Middle Connection Board Top Left Side Panel Top Right Side Panel Bottom Left Side Panel Bottom Right Side Panel Top Shelf Bottom Shelf Rear Bottom Cross Bar Front Top Cross Bar Small Back Panel Large Back Panel Right Side Door Left Side Door Upper Back Panel...
  • Page 4 PARTS LIST PARTS DESCRIPTION 12PCS Bolt 12PCS Lock 34PCS Wood Dowel Magnet 2PCS Magnet Plate 2PCS Plastic Anchor Screw (4x30mm) 2PCS 2PCS Knob Machine Screw (4x18mm) 2PCS 4PCS Metal Pin Screw (3x10mm) 2PCS 2PCS Screw (3x14mm) Screw (4x35mm) 4PCS 6PCS Long Machine Screw Allen Wrench...
  • Page 5 STEP 1 Screw 4 cam bolts (A) into cam bolt holes on top board (1). Insert 4 wood dowels (C) into dowel holes on top board (1). Attach magnet (D) to top board (1) by inserting 2 screws (O) through holes on magnet (D) and tighten to top board (1).
  • Page 6 STEP 3 1. Screw 2 cam bolts (A) into cam bolt holes on top left side panel (3). Insert 4 wood dowels (C) into dowel holes on top left side panel (3). STEP 4 Screw 2 cam bolts (A) into cam bolt holes on top right side panel (4). Insert 4 wood dowels (C) into dowel holes on top right side panel (4).
  • Page 7 STEP 5 Insert 8 wood dowels (C) into dowel holes on bottom left side panel (5). STEP 6 Insert 8 wood dowels (C) into dowel holes on bottom right side panel (6).
  • Page 8 STEP 7 Insert 1 screw (M) through hole on magnet plate (E) and tighten to left side door (15). Attach knob (H) to left side door (15) by inserting 1 screw (J) through hole on left side door (15) and tighten to knob (H). Insert 2 pins (K) into holes on each end of left side door (15).
  • Page 9 STEP 9 Slide small back panel (12) into grooves on top right side panel (4), top shelf (7) and bottom shelf (8). STEP 10 Attach top left side panel (3) to pre-assembled top shelf (7) and bottom shelf (8) by inserting cam bolts into cam lock holes and inserting wood dowels into dowel holes on top shelf (7) and bottom shelf (8).
  • Page 10 STEP 11 Attach both doors (14), (15) to bottom shelf (8) by inserting pins into holes on bottom shelf (8). Slide upper back panel (16) into grooves on top left side panel (3), top right side panel (4) and top board (1). Slide large back panel (13) into grooves on top left side panel (3) and top right side panel (4).
  • Page 11 STEP 13 1. Attach middle connection board (2) to bottom left side panel (5) and bottom right side panel (6), front top cross bar (11) and rear top cross bar (17) by inserting wood dowels into dowel holes on middle connection board (2). STEP 14 1.
  • Page 12 STEP 15 1. Place top portion onto middle connection board (2) by inserting wood dowels into dowel holes and cam bolts into cam lock holes on end of both top side panels (3) and (4). 2. Insert 4 cam locks (B) into cam lock holes on both top side panel (3) and (4) and rotate clockwise to secure cam bolts.

  • Page 13: Care Instructions

    ATTENTION ADULTS: Cabinet should be checked periodically for damage or loose screws/parts. Take appropriate action necessary to correct hazards such as tightening of screws and taking any damaged parts away from children. WARNING Please make sure your item is secured to the wall, per assembly instructions. CARE INSTRUCTIONS: Wipe clean with a water dampened cloth.
  • Page 14 Thank you for purchasing this RiverRidge Home item. We hope you ® enjoy it and consider purchasing other RiverRidge items. To order replacement parts at no cost to you, email customer.service@ssi-rr.com, call 1-(844)-223-5201 or order parts online at www.riverridgehome.com. Only valid in the United States.
