RiverRidge® ROLLING SIDE CABINET
This product requires assembly by an adult because of the small parts. Care should be
taken in unpacking and assembling this item to keep the small parts away from children.
WARNING
Young children can be seriously injured or killed, if furniture tips over.
Don't use this item for a TV stand.
Use angle-braces or anchors to secure furniture to the wall.
ASSEMBLY INSTRUCTIONS
ITEM#:06-033 White
ITEM#:06-034 Espresso
ADULT ASSEMBLY REQUIRED
Advertisement
Related Manuals for RiverRidge 06-033
Summary of Contents for RiverRidge 06-033
- Page 1 ASSEMBLY INSTRUCTIONS RiverRidge® ROLLING SIDE CABINET ITEM#:06-033 White ITEM#:06-034 Espresso ADULT ASSEMBLY REQUIRED This product requires assembly by an adult because of the small parts. Care should be taken in unpacking and assembling this item to keep the small parts away from children.
- Page 2 Send requests for missing or damaged parts replacements by email to : customer.service@ssi-rr.com or call toll free 1-(844)-223-5201 or order parts on line at www.riverridgehome.com THIS SHELF UNIT WILL HOLD UP TO 12 POUNDS PER SHELF OR A TOTAL OF 36 POUNDS. DO NOT LOAD EACH SHELF WITH MORE THAN 12 POUNDS.
-
Page 3: Parts List
PARTS LIST TOP BOARD RIGHT SIDE PANEL LEFT SIDE PANEL 2PCS MIDDLE CROSS BAR BOTTOM BOARD SHELF 2PCS BOTTOM CROSS BAR 16PCS CAM BOLT 16PCS CAM LOCK 16PCS WOOD DOWEL METAL HANDLE 2PCS SCREW 4x20mm 2PCS REAR WHEEL WITH STOPPER 2PCS FRONT WHEEL 16PCS... - Page 4 STEP1 STEP-1: 1. Screw 4 Cam Bolts (A) into the pre-threaded holes on the Top Board (1). STEP2 STEP-2: 1. Attach 2 Front Wheels (G) to Bottom Board (5) by inserting 8 Screws (H) through the holes on the Front Wheels (G) then tighten to Bottom Board (5). 2.
- Page 5 STEP3 STEP-3: 1. Screw 4 Cam Bolts (A) into the pre-threaded holes on the Right Side Panel (2). 2. Insert 8 Wood Dowels (C) into the dowel holes on the Right Side Panel (2). STEP4 STEP-4: 1. Screw 4 Cam Bolts (A) into the pre-threaded holes on the Left Side Panel (3). 2.
- Page 6 STEP 5 STEP-5: 1. Attach 1 Bottom Cross Bar (7) to Left Side Panel (3) by inserting the Cam Bolt (A) into the cam bolt holes and inserting Wood Dowels (C) into the dowel holes on the Bottom Cross Bar (7). 2.
- Page 7 STEP 7 STEP-7: 1. Attach Right Side Panel (2) to pre-assembled unit by inserting the cam bolts into cam lock holes and inserting the wood dowels into the dowel holes on the Middle Cross Bar (4) and Bottom Cross Bar (7). 2.
- Page 8 STEP 9 STEP-9: 1. Attach pre-assembled unit to Bottom Board (5) by inserting 4 Cam Bolts (A) into the cam lock holes on the Left Side Panel (2) and Right Side Panel (3), then rotate clockwise to secure the Cam Bolts in place.
- Page 9 Take appropriate action necessary to correct the hazard such as tightening of screws and taking any damaged parts away from children. Thank you for purchasing this RiverRidge® Home Products item. We hope you enjoy it, and consider purchasing other RiverRidge® items.
